Поз.
Артикул
Описание
125
SHOCK ABSORBER
125
SHOCK ABSORBER
125
SHOCK ABSORBER , Replaced By: A3443267200
125
SHOCK ABSORBER
125
SHOCK ABSORBER
125
SHOCK ABSORBER
135
RUBBER MOUNTING004 326 01 00
140
SPACER TUBE
141
BRACKET LEFT SHOCK ABSORBER
141
BRACKET RIGHT SHOCK ABSORBER
142
SCREW BRACKET TO SPRING SADDLE M 14X1.5X110
143
SCREW BRACKET TO REAR SPRING SADDLE COUNTER PLATE
144
LOCK WASHER SUPPORT TO SIDE MEMBER
145
SCREW ,511930, Replaced By: A3459908601, +002N913004020000
145
SCREW SHOCK ABSORBER TO CROSS MEMBER,511931
145
SCREW SHOCK ABSORBER TO CROSS MEMBER,511931
150
NUT BALL PIVOT TO STEERING ARM
150
NUT , Replaced By: N913004020003
150
NUT , Replaced By: N913004020003
150
NUT DRAG LINK TO STEERING ARM AND PITMAN ARM
155
COTTER PINROCKINGER TYP 260 G140
160
RUBBER MOUNTING
160
STOP
165
SCREW BUFFER TO BRACKET
170
WASHER GROUND CABLE
175
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
178
SCREW CROSS MEMBER TO SIDE MEMBERS
180
SCREW SHOCK ABSORBER TO BOTTOM BRACKET
185
LOCK SHOCK ABSORBER TO BOTTOM BRACKET
230
STAY
231
STAY
235
RUBBER MOUNTING
240
SCREW BUFFER TO BRACKET
245
NUT BRACKET TO SIDE MEMBER,XB209706
250
SCREW CROSS MEMBER TO SIDE MEMBERS
255
NUT ANGLE TO SIDE MEMBER
394
ELBOW FITTING
398
BRAKE HOSE
999
PLATE , Replaced By: A6953257031
999
CONSOLE SPRING LOAD ACCUMULATOR CYLINDER
999
U-BOLT REAR SPRING TO REAR AXLE 390 MM
999
SPACER
999
REAR SPRING 6-LEAF,WITH 6-LEAF HELPER SPRING,KB860814
999
FITTING LOCKING VALVE
999
SCREW SHOCK ABSORBER TO BOTTOM BRACKET
999
SPACER
999
REAR SPRING 9-LEAF,WITH 6-LEAF HELPER SPRING, 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
999
DRAG LINK
999
U-BOLT REAR SPRING TO REAR AXLE, NOT USED
999
BRAKE HOSE , Replaced By: A0024280735
999
BUSHING , Replaced By: A3443267250
999
SPACER TUBE , Replaced By: A3140720253
