Поз.
Артикул
Описание
10
PITMAN ARM STEERING GEAR
10
PITMAN ARM
10
PITMAN ARM
10
PITMAN ARM
10
PITMAN ARM
10
PITMAN ARM STEERING GEAR
10
PITMAN ARM
10
PITMAN ARM , Replaced By: A9454630101
20
DRAG LINK FROM PITMAN ARM TO FRONT AXLE I
20
DRAG LINK FROM PITMAN ARM TO FRONT AXLE I
20
DRAG LINK FROM PITMAN ARM TO FRONT AXLE I
20
DRAG LINK FROM PITMAN ARM TO FRONT AXLE I
30
DRAG LINK END R.H. THREAD
30
DRAG LINK ENDEHRENREICH
40
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER, TO 002 460 14 05, 15 05,K 226468
40
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER
40
CLAMP DRAG LINK END TO DRAG LINK EHRENREICH
40
CLAMP CLAMP, ONE-HOLE
50
HEXAGON HEAD BOLTM10X1X50
50
SCREW STRUT TO FRAME M 12X62
55
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
55
NUT REINFORCEMENT TO BRACKET
80
STEERING ARM LEFT STEERING KNUCKLE
80
STEERING ARM FRONT AXLE I
80
STEERING ARM LEFT STEERING KNUCKLE
80
STEERING ARM FRONT AXLE,RIGHT
85
SCREW STEERING ARM TO STEERING KNUCKLE M24X1.5X100
105
DRAG LINK FROM PITMAN ARM TO FRONT AXLE I, REPAIR IMPOSSIBLE
105
DRAG LINK FROM PITMAN ARM TO INTERMEDIATE LEVER I TRW, REPAIR IMPOSSIBLE, Replaced By: A0034603105
430
DRAG LINK FROM INTERMEDIATE LEVER I TO INTERMEDIATE LEVER II, Replaced By: A6624602205
430
DRAG LINK FROM INTERMEDIATE LEVER I TO INTERMEDIATE LEVER II, REPAIR IMPOSSIBLE
430
DRAG LINK FROM STEERING INTERMEDIATE BRACKET I TO STEERING INTERMEDIATE BRACKET II
430
DRAG LINK FROM INTERMEDIATE LEVER I TO INTERMEDIATE LEVER II
450
DRAG LINK ENDEHRENREICH
450
DRAG LINK END R.H. THREAD EHRENREICH
450
DRAG LINK END R.H. THREAD
450
DRAG LINK END R.H. THREAD
450
DRAG LINK END L.H. THREAD
460
CLAMP DRAG LINK END TO DRAG LINK EHRENREICH
460
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER
460
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER, TO 002 460 14 05, 15 05,K 226468
465
SCREW STRUT TO FRAME M 12X62
470
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
500
DRAG LINK FROM STEERING INTERMEDIATE BRACKET II TO FRONT AXLE II
500
DRAG LINK FROM INTERMEDIATE LEVER III TO INTERMEDIATE LEVER IV
500
DRAG LINK FROM STEERING INTERMEDIATE BRACKET III TO STEERING INTERMEDIATE BRACKET IV
500
DRAG LINK FROM STEERING INTERMEDIATE BRACKET II TO STEERING INTERMEDIATE BRACKET III
500
DRAG LINK FROM STEERING INTERMEDIATE BRACKET II TO STEERING INTERMEDIATE BRACKET III
500
DRAG LINK FROM STEERING INTERMEDIATE BRACKET II TO FRONT AXLE II
500
DRAG LINK FROM STEERING INTERMEDIATE BRACKET II TO STEERING INTERMEDIATE BRACKET III
500
DRAG LINK FROM STEERING INTERMEDIATE BRACKET II TO STEERING INTERMEDIATE BRACKET III
500
DRAG LINK FROM STEERING INTERMEDIATE BRACKET II TO FRONT AXLE II
500
DRAG LINK FROM STEERING INTERMEDIATE BRACKET II TO STEERING INTERMEDIATE BRACKET III
570
BALL JOINT L.H. THREAD
570
DRAG LINK END R.H. THREAD
570
DRAG LINK END R.H. THREAD
570
DRAG LINK END L.H. THREAD
570
DRAG LINK END R.H. THREAD
570
DRAG LINK END L.H. THREAD TO A 662 463 12 15
570
BALL JOINT R.H. THREAD
570
DRAG LINK END R.H. THREAD
570
BALL JOINT L.H. THREAD TRW
570
DRAG LINK END L.H. THREAD EHRENREICH
570
DRAG LINK ENDEHRENREICH
580
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER
580
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER, TO 002 460 14 05, 15 05,K 226468
580
CLAMP CLAMP, ONE-HOLE
580
CLAMP DRAG LINK END TO DRAG LINK EHRENREICH
585
HEXAGON HEAD BOLTM10X1X50
585
SCREW STRUT TO FRAME M 12X62
590
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
590
NUT REINFORCEMENT TO BRACKET
710
STEERING ARM LEFT STEERING KNUCKLE
710
STEERING ARM FRONT AXLE II,LEFT
710
STEERING ARM LEFT STEERING KNUCKLE
