Поз.
Артикул
Описание
292
SHIFTING TUBE , 010 UP TO CHASSIS 017603 EXCEPT FOR,SEE FOOTNOTE 39,012 UP TO CHASSIS 036824 EXCEPT FOR,SEE FOOTNOTE 38
292
SHIFTING TUBE ,011450
292
SHIFTING TUBE , 000,001,004,010,016 UP TO CHASSIS 190317 EXCEPT FOR,SEE FOOTN.36,002,003,005,011,017 UP TO CHASSIS 034216 EXCEPT FOR SEEFOOTN.37 AND FOOTN.38
294
STOP LEVER FOR WARNING LAMP, 010 FROM CHASSIS 017604 ALSO INSTALLED ON,SEE FOOTNOTE 39,012 FROM CHASSIS 036825 ALSO INSTALLED ON,SEE FOOTNOTE 38 ONLY FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH
296
SCREW COVER PLATE TO COVER PLATE M 6 X 12
296
SCREW , Replaced By: N304017006018
298
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
301
GUIDE PIVOT , 000,001,004,010,016 UP TO CHASSIS 190317 EXCEPT FOR,SEE FOOTN.36,002,003,005,011,017 UP TO CHASSIS 034216 EXCEPT FOR SEEFOOTN.37 AND FOOTN.38
303
SEAL RING
305
WASHER
307
LOCK
310
PIN
312
SPRING
314
BOOT , 000,001,004,010,016 UP TO CHASSIS 190317 EXCEPT FOR,SEE FOOTN.36,002,003,005,011,017 UP TO CHASSIS 034216 EXCEPT FOR SEEFOOTN.37 AND FOOTN.38
316
SHIFT LEVER , 000,001,004,010,016 UP TO CHASSIS 190317 EXCEPT FOR,SEE FOOTN.36,002,003,005,011,017 UP TO CHASSIS 034216 EXCEPT FOR SEEFOOTN.37 AND FOOTN.38
318
SHIFT LEVER , ONLY FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH
321
ELECTRIC CABLE WITH TERMINAL, ONLY FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH
323
SHIFT LEVER WITH CONTACT RING, ONLY FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH
325
NUT , ONLY FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH
327
LOCK , ONLY FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH
329
COVER , ONLY FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH
331
SPRING , ONLY FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH
333
WASHER , ONLY FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH
335
RUBBER PAD
337
COVER
339
KNOB , UP TO CHASSIS: 000,002,010 007280 015 004403 100,102,103,110,112 017470 115 007978
339
KNOB. BRACKET
343
BEARING BRACKET
345
NEEDLE BEARING
347
BUSHING , 040898
350
LEVER
353
BUSHING
356
SPACER RING
359
SPRING WASHER LICENSE PLATE TO BRACKET
363
NUT BALL PIVOT TO LEVER
366
PIN , 040898
369
SWITCH BACK-UP LIGHT, UP TO TRANSMISSION 365563 EXCEPT FOR, SEE FOOTNOTE 6
372
COVER
375
LEVER
375
LEVER , Replaced By: A1112601381
378
NEEDLE BEARING
381
SEAL RING
384
WASHER
387
SPRING WASHER PULL ROD TO BRAKE INTERMEDIATE LEVER
390
LOCK PLATE INTERMEDIATE BEARING
393
LOCK WASHER TAIL LAMP TO BRACKET
396
NUT
396
NUT , Replaced By: N304032008006
399
LEVER
401
SCREW COVER PLATE TO BRACKET
404
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
407
SHAFT
409
SEAL RING
411
SPRING WASHER PULL ROD TO BRAKE INTERMEDIATE LEVER
413
LEVER
415
BALL SOCKET
417
NUT POWER CYLINDER
420
BALL SOCKET
422
BALL SOCKET
446
BRACKET FOR SWITCH, 010 FROM CHASSIS 017604 ALSO INSTALLED ON,SEE FOOTNOTE 39,012 FROM CHASSIS 036825 ALSO INSTALLED ON,SEE FOOTNOTE 38 ONLY FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH
448
SWITCH TO SWITCH OFF WARNING LAMP, 012,10/50,20/60 WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH FROM CHASSIS 036826 ALSO INSTALLED ON,SEE FOOTNOTE 073 010,10/50,20/60 WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH FROM CHASSIS 017604 ALSO INSTALLED ON,SEE FOOTNOTE 072 ONLY FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH
450
GUIDE SLEEVE TO SWITCH OFF WARNING LAMP, 010 FROM CHASSIS 017604 ALSO INSTALLED ON,SEE FOOTNOTE 39,012 FROM CHASSIS 036825 ALSO INSTALLED ON,SEE FOOTNOTE 38 ONLY FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH
452
PIN TO SWITCH OFF WARNING LAMP, 010 FROM CHASSIS 017604 ALSO INSTALLED ON,SEE FOOTNOTE 39,012 FROM CHASSIS 036825 ALSO INSTALLED ON,SEE FOOTNOTE 38 ONLY FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH
454
SPRING TO SWITCH OFF WARNING LAMP, 010 FROM CHASSIS 017604 ALSO INSTALLED ON,SEE FOOTNOTE 39,012 FROM CHASSIS 036825 ALSO INSTALLED ON,SEE FOOTNOTE 38 ONLY FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH
456
PIN TO SWITCH OFF WARNING LAMP, 010 FROM CHASSIS 017604 ALSO INSTALLED ON,SEE FOOTNOTE 39,012 FROM CHASSIS 036825 ALSO INSTALLED ON,SEE FOOTNOTE 38 ONLY FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH
458
LOCK TRANSMISSION CASE,TOP
460
NUT TO SWITCH OFF WARNING LAMP, 010 FROM CHASSIS 017604 ALSO INSTALLED ON,SEE FOOTNOTE 39,012 FROM CHASSIS 036825 ALSO INSTALLED ON,SEE FOOTNOTE 38 ONLY FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH
462
SHIFTING TUBE
464
BEARING COVER BOTTOM
466
RUBBER RING
468
WASHER
471
LOCK
473
BEARING
475
BUSHING
477
BEARING COVER TOP
479
COVER PLATE
481
BOOT
483
BOOT BOTTOM,042 014258
485
SCREW COVER PLATE TO BRACKET
487
SPRING WASHER LICENSE PLATE TO BRACKET
489
WASHER , UP TO TRANSMISSION: 023 766040 UP TO CHASSIS: 009860
489
WASHER COVER PLATE TO COVER PLATE
491
SHIFT LEVER
493
SCREW
495
BUSHING
497
WASHER
499
NUT
501
KNOB
503
PULL ROD ,067753
505
END PIECE ,042 014258
507
BUSHING
509
NUT
511
WASHER , UP TO TRANSMISSION: 023 766040 UP TO CHASSIS: 009860
511
WASHER COVER PLATE TO COVER PLATE
513
NUT
999
SPRING WASHER , ON SPECIAL REQUEST, FLOOR SHIFT
999
SCREW , Replaced By: N304017010055
999
CABLE CONNECTOR ,760894
999
SHEET METAL SCREW SWITCH TO JACKET TUBE, 010 FROM CHASSIS 017604 ALSO INSTALLED ON,SEE FOOTNOTE 39,012 FROM CHASSIS 036825 ALSO INSTALLED ON,SEE FOOTNOTE 38 ONLY FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH
999
LOCK PLATE
999
SEAL RING , ON SPECIAL REQUEST, FLOOR SHIFT
999
NUT BRACKET TO SUPPORT AND TO END PIECE
999
NUT , Replaced By: N304032008006
999
SCREW , Replaced By: N304017010050
999
SCREW CLUTCH TO FLYWHEEL
999
SCREW YOKE TO SHIFTING TUBE
999
SCREW LEVER TO SHAFT
999
SCREW SELECTOR LEVER TO SELECTOR FINGER
999
SCREW , Replaced By: N000933006194
999
RIVET , ON SPECIAL REQUEST, FLOOR SHIFT
999
SPRING WASHER STEERING COLUMN BRACKET TO CAB
999
LOCK WASHER , 010 UP TO REAR AXLE 009905,012 UP TO REAR AXLE 026069
999
WASHER
999
COTTER PIN LEVER TO ROD
999
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
999
SPACER WASHER 0.50 MM
999
SPACER WASHER 0.25 MM
999
SPACER WASHER AS REQUIRED 0.10 MM, UP TO TRANSMISSION: 023 766040 UP TO CHASSIS: 009860
999
YOKE , ON SPECIAL REQUEST, FLOOR SHIFT
999
SHIFTING FINGER , ON SPECIAL REQUEST, FLOOR SHIFT
999
TRANSMISSION CASE COVER , ON SPECIAL REQUEST, FLOOR SHIFT
999
GUIDE PLATE , ON SPECIAL REQUEST, FLOOR SHIFT
999
SHIFTING FORK 1ST AND 2ND SPEED
999
THRUST WASHER 4.50 MM
999
THRUST WASHER 4.40 MM
999
THRUST WASHER AS REQUIRED 4.30 MM
999
THRUST WASHER AS REQUIRED 4.20 MM
999
THRUST WASHER 4.10 MM
999
THRUST WASHER 4.00 MM
999
THRUST WASHER 3.90 MM
999
GASKET , 040898
999
TRANSMISSION CASE COVER , 040898, Replaced By: A1112602314, +001A1102600437, +001A1369970830, +001N007603018103
999
GUIDE PLATE , 040898
999
WASHER , 000420
999
WASHER ,000252
999
KNOB , Replaced By: A1112680842
999
GEAR 38 TEETH, 3RD SPEED, 014 UP TO TRANSMISSION 163395 NOT INSTALLED ON 128601-128710,021/023 UP TO TRANSMISSION 004870
999
GEAR , 014 UP TO TRANSMISSION 063030,021/023 UP TO TRANSMISSION 000100, Replaced By: A1102620212, +001A1112600324
999
COUNTERSHAFT , 014 UP TO TRANSMISSION 063030,021/023 UP TO TRANSMISSION 000100, Replaced By: A1112600324, +001A1102620212
999
BUSHING INTERLOCK PIN, 184087, 309.030-035,051-059 192298, 309.050 182066, 309.1
999
SNAP RING 2.05 MM
999
SNAP RING , Replaced By: A1369940935
999
PRESSURE SPRING , ON SPECIAL REQUEST, FLOOR SHIFT
999
INTERLOCK PLUG , Replaced By: A3442657044
999
PRESSURE SPRING INTERLOCK PIN, 184087, 309.030-035,051-059 192298, 309.050 182066, 309.1556499
999
PIN , ON SPECIAL REQUEST, FLOOR SHIFT
999
SPACER WASHER 0.30 MM
999
SPACER WASHER 0.3 MM
999
SPACER WASHER 0.2 MM
999
SPACER WASHER 0.20 MM
999
SCREW , ON SPECIAL REQUEST, FLOOR SHIFT
999
THRUST WASHER AS REQUIRED
999
THRUST WASHER , Replaced By: A1202622062
999
THRUST WASHER AS REQUIRED
999
THRUST WASHER , Replaced By: A1202621862
999
THRUST WASHER , NOT USED
999
THRUST WASHER , Replaced By: A1202621562
999
THRUST WASHER 4.50 MM
999
THRUST WASHER , Replaced By: A1202621362
999
SYNCHRONIZER RING 3RD AND 4TH SPEED
999
GASKET
999
SPACER TUBE
999
SPACER TUBE , NO LONGER AVAILABLE
999
WASHER 0.30 MM, ON SPECIAL REQUEST, FLOOR SHIFT
999
WASHER 0.20 MM, ON SPECIAL REQUEST, FLOOR SHIFT
999
WASHER0.5 MM, 10/50,12/52 UP TO CHASSIS 096085, 20/60,22/62 UP TO CHASSIS 095140
999
WASHER1.0 MM, 10/50,12/52 UP TO CHASSIS 096085, 20/60,22/62 UP TO CHASSIS 095140
999
REPAIR KIT TRANSMISSION CASE FRONT COVER
999
KNOB LIGHT IVORY-COLORED, 000,001,004,010,016 UP TO CHASSIS 130558, 100,101,104,110 UP TO CHASSIS 225648 ON SPECIAL REQUEST
999
COVER
999
PIN ,042 007201042 014258
999
GUIDE PIVOT , ONLY FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH
999
SHAFT
999
GUIDE PIVOT , 010 UP TO CHASSIS 000755,012 UP TO CHASSIS 001722 NOT FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH, Replaced By: A1112680539, +001A1862680273, +001A1869906940
999
SEAL , ON SPECIAL REQUEST, FLOOR SHIFT
999
PIN , ON SPECIAL REQUEST, FLOOR SHIFT
999
GEAR 1ST SPEED, 014 UP TO TRANSMISSION 163395 NOT INSTALLED ON 128601-128710,021/023 UP TO TRANSMISSION 004870
999
GASKET , NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
SHIFTING ROD , ONLY FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH
999
SHIFTING ROD
999
SHIFTING ROD , ONLY FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH
999
SHIFTING ROD , ONLY FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH
999
SHIFTING ROD , ONLY FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH
999
BEARING BRACKET , 040898
999
SHIFTING ROD
999
TRANSMISSION CASE COVER TOP, 000,001,004,010,016,100,101,104,110,116 FROM TRANSMISSION 490816, 002,003,005,011,017 FROM TRANSMISSION 021531
999
BEARING BRACKET , Replaced By: A1112603794
999
LEVER
999
BEARING BRACKET , 010 UP TO CHASSIS 010678,012 UP TO CHASSIS 021914, Replaced By: A1112602994, +001A1112681050, +001A1112680251
999
TRANSMISSION WITH BELL HOUSING
999
TRANSMISSION WITH BELL HOUSING, NOT FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH
999
BEARING BRACKET ,006613, Replaced By: A1112602894, +001A1112681050, +001A1112680251
999
TRANSMISSION WITH BELL HOUSING, ONLY FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH
999
DRIVE SHAFT WITH SYNCHRONIZING CONE, FROM TRANSMISSION 001553 ONLY FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH
999
TRANSMISSION CASE COVER , Replaced By: A1112603214, +001A1102600437
999
TRANSMISSION WITH BELL HOUSING, ONLY FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH
999
TRANSMISSION CASE COVER , 105925, Replaced By: A1112600621, +001A1112610279
999
TRANSMISSION CASE COVER , NOT FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH NO LONGER AVAILABLE,INSTEAD:GASKET KIT 111 586 01 26, Replaced By: A1112602314, +001A1102602314, +001A1219970130, +001N007603018103
999
DRIVE SHAFT , UP TO TRANSMISSION 001552 ONLY FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH, Replaced By: A1112600620, +001A1112620423
999
TRANSMISSION CASE , UP TO TRANSMISSION 044 001193, Replaced By: A1112600411, +004N000931012162
