Поз.
Артикул
Описание
1
CALIPER LEFT,LESS PAD ASSEMBLIES, TEVES, IN PAIRS OPTIONAL W/000 421 73 98,BENDIX, FROM CHASSIS: 010 094997 110 244251
6
PISTON , 005,007,008,015,017 203606 011 014721
7
DOWEL PIN TEVES
8
SPRING , 005,007,008,015,017 203606 011 014721
9
PROTECTIVE PLATE
10
BLEEDER VALVE
11
PROTECTIVE CAP , Replaced By: A0004217187
11
PROTECTIVE CAP ,5 962906
16
TS BRAKE PAD , Replaced By: A0014207720
16
BRAKE PAD. TS BRAKE PAD PARTS KIT
20
REPAIR KIT MAKE"TEVES"
22
SCREW
23
LOCK
26
BRAKE DISC , 068408
27
SCREW
28
PROTECTIVE PLATE
29
COMBINATION BOLT
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
RIVET CRAMP TO BODY
999
SCREW COVER PLATE TO COVER PLATE M 6 X 10
999
SCREW APPARATUS PLATE M 6X45
999
WASHER
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
999
SHEET METAL SCREW BRACKET TO CAB 4,2X13
999
SHEET METAL SCREW VALVE TO WINDOW SILL
999
SHEET METAL SCREW
999
NUT BALL PIVOT TO LEVER
999
SCREW , Replaced By: N304017006034
999
SCREW , Replaced By: N304017006027
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
COTTER PIN
999
COTTER PIN
999
COTTER PIN
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE
999
BRAKE HOSE
999
CALIPER RIGHT,LESS LINING BENDIX
999
CALIPER LEFT,LESS LINING BENDIX
999
BRAKE HOSE , Replaced By: A1264280335
999
LINE FROM MASTER CYLINDER TO HOSE 3865 MM
999
LINE FROM BRAKE MASTER CYLINDER TO DISTRIBUTOR, 055235
999
LINE , UP TO CHASSIS: 017 062832, FEDERAL, EXCEPT FOR: 059499,060650,061519,061527,062799. 017 062926, CALIFORNIA, EXCEPT FOR 048629,060112,062772 114 029141, EXCEPT FOR: 002250,003131,016950,026317,026334,026513,027268,027269,027272,027281,027513,027518,027822,027824, 028251,029032,029113,029121,029128. 117 10/50 102742, EXCEPT FOR: 098668,099672,100535,100850,100851,101663,102380,102507,102622,102708,102717. 117 12/52 102758, EXCEPT FOR: 088215,099223,099235,099370,099371,099673,100542,101165,101171,101246,102475,102643,102651,102724.
999
LINE FROM DISTRIBUTOR TO REAR LEFT BRAKE HOSE
999
CALIPER , Replaced By: A1264201583
999
CALIPER , Replaced By: A1264201483
999
CALIPER RIGHT,LESS LINING TEVES
999
SCREW LINES UNDER FUEL TANK
999
LOCK
999
BRAKE SHOE
999
CLAMP BRAKE CABLE TO REAR FLOOR
999
SPRING
999
LINE FROM VACUUM PUMP TO BRAKE BOOSTER, FROM CHASSIS: 010 105672 UP TO CHASSIS: 017 062832, FEDERAL, EXCEPT FOR: 059499,060650,061519,061527,062799. 017 062926, CALIFORNIA, EXCEPT FOR 048629,060112,062772 114 029141, EXCEPT FOR: 002250,003131,016950,026317,026334,026513,027268,027269,027272,027281,027513,027518,027822,027824, 028251,029032,029113,029121,029128. 117 10/50 102742, EXCEPT FOR: 098668,099672,100535,100850,100851,101663,102380,102507,102622,102708,102717. 117 12/52 102758, EXCEPT FOR: 088215,099223,099235,099370,099371,099673,100542,101165,101171,101246,102475,102643,102651,102724.
999
PROTECTIVE PLATE , FOR SUBSEQUENT INSTALLATION, ON BAD ROAD CONDITIONS
999
PROTECTIVE PLATE REAR WHEEL BRAKE,RIGHT
999
BRAKE CABLE , 000,002,010,100,102,103,112 UNTIL PRODUCTION STOP UP TO CHASSIS: 005,017,041250 015 255760 105,107,108,117,119 073304 110 442020 114 009171 115 270762, Replaced By: A1154202785, +001A1145860142
999
BRAKE CABLE , 000,002,010,100,102,103,112 UNTIL PRODUCTION STOP UP TO CHASSIS: 005,017,041250 015 255760 105,107,108,117,119 073304 110 442020 114 009171 115 270762, Replaced By: A1154202785, +001A1145860142
999
SHACKLE
999
REPAIR KIT TURNBUCKLE, 002124
999
REPAIR KIT , UP TO CHASSIS: 005,017,041250 015 255760 105,107,108,117,119 073304 110 442020 114 009171 115 270762, Replaced By: A1145860142, +001A1154202785
999
PIN , Replaced By: A1145860142, +001A1154202785
999
CONNECTOR , Replaced By: A1145860142, +001A1154202785
999
CYLINDER PIN. PIN
999
LEVER , Replaced By: A1145860142, +001A1154202785
999
PAD
999
BRAKE MASTER CYLINDERBENDIX
999
REPAIR KIT BRAKE MASTER CYLINDER TEVES, 003 108238 007 096405 086 007334 093 009958 102,103 282291 105 257306 183 017326 190 023305 193 004949 280 002153 283 006728
999
SENDER UNIT TEVES, REAR SUPPLY CHAMBER, UP TO CHASSIS: 005,017 009971 015 215193 105,107,108,117,119 017585 110 413856 115 218099
999
REPAIR KIT BRAKE MASTER CYLINDER BENDIX
999
REPAIR KIT
999
REPAIR KIT CALIPER BENDIX
999
REPAIR KIT BENDIX, 005,007,008,015,017 203606 011 014721
999
RESERVOIR TEVES, THREE-CHAMBER, FROM CHASSIS: 017 009972 117 017586 UP TO CHASSIS: 017 062832, FEDERAL, EXCEPT FOR: 059499,060650,061519,061527,062799. 017 062926, CALIFORNIA, EXCEPT FOR 048629,060112,062772 114 029141, EXCEPT FOR: 002250,003131,016950,026317,026334,026513,027268,027269,027272,027281,027513,027518,027822,027824, 028251,029032,029113,029121,029128. 117 10/50 102742, EXCEPT FOR: 098668,099672,100535,100850,100851,101663,102380,102507,102622,102708,102717. 117 12/52 102758, EXCEPT FOR: 088215,099223,099235,099370,099371,099673,100542,101165,101171,101246,102475,102643,102651,102724.
999
BRAKE BOOSTER ASSEMBLYBENDIX, 000 113165 003 057447 007 046962 083 001048 086 000765 093 000620 102,103 092824 105 116296 183 001423 190 001361
999
CALIPER RIGHT,TEVES,LESS LINING, IN PAIRS OPTIONAL WITH, 000,001,004,010,016 FROM CHASSIS 189499,002,003,005,011,017 FROM CHASSIS 033000,100,101,104,110,116 FROM CHASSIS 355414
999
CALIPER RIGHT,BENDIX,LESS LINING, IN PAIRS OPTIONAL WITH
999
CALIPER LEFT,BENDIX,LESS LINING, IN PAIRS OPTIONAL WITH
999
DOWEL PINBENDIX
999
DOWEL PIN , Replaced By: A0009912660, +001A0004210573
999
DOWEL PIN , Replaced By: A0009912660, +001A0004210573
999
RUBBER RING SIGNAL LAMP TO ROOF
999
SEAL RINGBENDIX
999
RESERVOIR
999
FILLER CAP BUTTRESS THREAD
999
STRAINER
999
PROTECTIVE CAPTO 001 430 36 30,002 430 27 30
999
FILLER CAP TEVES
999
CONNECTOR
999
PISTONBENDIX
999
PISTON
999
SPRINGBENDIX, 020 107901 023 132308 026,028 067357 030 026099 033 054139 120 151587 123,125 115960 130,132 137346
999
SPRING
999
LOCKBENDIX
999
PROTECTIVE PLATE
999
LOCK , Replaced By: A0004210573
999
LOCK , Replaced By: A0004210573
999
SHIM , ONLY AGAINST BRAKE SQUEALING
999
BLEEDER VALVEBENDIX
