Поз.
Артикул
Описание
5
GLOVE COMPARTMENT
5
GLOVE COMPARTMENT
8
RIVET
11
GLOVE COMPARTMENT LID OUTSIDE PART,NO.9045I NO.5070I NO.8310I NO.8320I NO.8411I NO.6121I NO.3111I NO.7095I
14
GLOVE COMPARTMENT LID INSIDE PART
17
FASTENER GLOVE COMPARTMENT LID
20
FASTENER , Replaced By: A1246800684
20
FASTENER LESS KEY, STATE LOCK NUMBER WHEN ORDERING
21
SCREW HANDLE TO GLOVE COMPARTMENT LID
23
FASTENER GLOVE COMPARTMENT LID INTERIOR PART
26
SCREW HANDLE TO GLOVE COMPARTMENT LID
29
STOP GLOVE COMPARTMENT LID INTERIOR PART
29
STOP GLOVE COMPARTMENT LID INTERIOR PART
32
PIN LOCK TO GLOVE COMPARTMENT LID
35
SHAFT GLOVE COMPARTMENT LID LOCKING MECHANISM
38
SPRING GLOVE COMPARTMENT LID
41
BAND GLOVE COMPARTMENT LID WITH DAMPER
44
BRACKET GLOVE COMPARTMENT LID WITH DAMPER
47
SCREW HANDLE TO GLOVE COMPARTMENT LID
50
HINGE GLOVE COMPARTMENT LID TO INSTRUMENT PANEL
53
WASHER , Replaced By: N009021005205
53
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
56
NUT HINGE TO GLOVE COMPARTMENT LID,F 078641
59
SHEET METAL SCREW
62
TAPPING SCREW GLOVE COMPARTMENT LID INTERIOR PART B 3.5X16
65
SCREW WASHER TO STEERING COLUMN BRACKET M 4X10,4 231945
66
LOCK HINGE TO GLOVE COMPARTMENT LID,F 078641
68
TREENAIL
71
SCREW
74
LOCKING CAP
77
CLIP HOUSING WITH TRAY TO INSTRUMENT PANEL
80
LOCK GLOVE COMPARTMENT LID TO INSTRUMENT PANEL
83
SHEET METAL SCREW BRACKET TO FIRE WALL
86
GROMMET GLOVE COMPARTMENT LID TO INSTRUMENT PANEL
