Поз.
Артикул
Описание
5
HEATING PAD BACKREST AND SEAT CUSHION
5
HEATING PAD REAR SEAT BACKREST & CUSHION, USED WITH VELOURS TRIM
5
HEATING PAD REAR SEAT BACKREST & CUSHION, USED WITH IMITATION LEATHER TRIM
5
HEATING PAD REAR SEAT BACKREST & CUSHION, USED WITH LEATHER & AMARETTA TRIM, IN CASE OF SOFT LEATHER TRIM,HEATING CUSHION IS SOWN INTO SEAT COVER, SEE SA'S 56819, 56821, 56822
5
HEATING PAD , Replaced By: A0008203798
8
PLUG HOUSING
8
PLUG HOUSING
11
COVER
14
PLUG PIN
14
ROUND PIN BUSHING LIGHT SWITCH 2,5 MM
14
PLUG PIN ADDITIONAL CABLE TO SERIES CABLE
26
CLIP COVER TO PAD
32
ELECTRIC CABLE REAR SEAT, 126.021 027852 022,023 095773 032,033 048980 036,037 037124 043 008026 044 007397 120 051146
32
ELECTRIC CABLE REAR SEAT, 126.021 027852 022,023 095773 032,033 048980 036,037 037124 043 008026 044 007397 120 051146
32
CABLE HARNESS REAR SEAT, 126.021 027853 022,023 095774 032,033 048981 036,037 037125 043 008027 044 007398 120 051147
62
PIN BUSHING HOUSING , 10/20 UP TO CHASSIS 4 411810,50/60 UP TO CHASSIS 4 414810
65
COVER , 10/20 UP TO CHASSIS 4 411810,50/60 UP TO CHASSIS 4 414810
68
PIN BUSHING HOUSING SEAT HEATER RELAY, 8-POLE
71
COVERTO 006 545 81 28
86
ROUND PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2.5 MM2
116
CONNECTOR SEAT HEATER SWITCH, 7-POLE, 107.042 011569 ALSO INSTALLED ON 010107,010328,010378,011305,011341,011348,011356,011418,011426,011434,011436,011444,011454,011455, 011464,011472,011473,011476,011480,011494,011496,011503,011504,011513,011514,011518,011519,011520, 011526,011528,011531,011533,011535,011537,011538,011539,011541-011567. 107.045 009132 ALSO INSTALLED ON 004581,007703,008068,008344,008400,008401,008455,008627,008724,008836,008842,008885,008911,008920, 008925,008958,008967,008989,008994,009001,009100,009128. 107.046 009987 ALSO INSTALLED ON 000518,000621,000841,000897,000899,000921,000933,000936,000938,000940,000942,000944,000956,000964, 000967,000970,000974-000985.
119
PIN BUSHING HOUSINGTO 000 821 26 26
122
ROUND PIN BUSHING4 MM2
125
LOOM TIE , UP TO CHASSIS: 108.012 UNTIL PRODUCTION STOP 108.016 042417 108.018,019 043374 109.016 002452
134
CLIP PLUG TO REAR PILLAR
137
CLIP MAIN CABLE HARNESS BRANCH-OFF BETWEEN STARTING MOTOR & REAR CABLE CONNECTOR
137
CLIP VACUUM LINE TO FLOOR,LEFT & RIGHT FRONT PANEL PILLARS
140
BRACKET REAR SEAT HEATER,RIGHT,A 394304
140
BRACKET REAR SEAT HEATER,LEFT,A 394304
143
BRACKET REAR SEAT HEATER,LEFT AND RIGHT,A 394305
146
SHEET METAL SCREW BRACKET TO CAB FLOOR
155
BRACKET REAR SEAT HEATER CONTROL,A 368214
158
RELAY SEAT HEATER CONTROL
164
SHEET METAL SCREW ALARM UNIT TO STRUT
164
SHEET METAL SCREW PRE-GLOW TIME RELAY TO STEERING COLUMN JACKET TUBE CONSOLE
173
SHEET METAL SCREW. TAPPING SCREW BRACKET MOUNTING 3.9X13
