Поз.
Артикул
Описание
5
LINE FROM MASTER CYLINDER TO ADAPTER FITTING, 000 193701 003 097469 086 006508 093 007717 102,103 209243 183 013349 190 020074 193 000014 200 006559 283 001514 INAPPLICABLE TO ANTI-LOCK BRAKING SYSTEM (ABS)
5
LINE FROM DISTRIBUTOR TO REAR RIGHT BRAKE HOSE
8
LINE , Replaced By: A1234206528
8
LINE FROM DISTRIBUTOR TO REAR HEIGHT CONTROL VALVE
26
LINE FROM HEIGHT CONTROL VALVE TO LEFT SPRING-LOAD ACCUMULATOR
29
LINE FROM MASTER CYLINDER TO REAR BRAKE PRESSURE REGULATOR
32
LINE , UP TO CHASSIS: 017 062832, FEDERAL, EXCEPT FOR: 059499,060650,061519,061527,062799. 017 062926, CALIFORNIA, EXCEPT FOR 048629,060112,062772 114 029141, EXCEPT FOR: 002250,003131,016950,026317,026334,026513,027268,027269,027272,027281,027513,027518,027822,027824, 028251,029032,029113,029121,029128. 117 10/50 102742, EXCEPT FOR: 098668,099672,100535,100850,100851,101663,102380,102507,102622,102708,102717. 117 12/52 102758, EXCEPT FOR: 088215,099223,099235,099370,099371,099673,100542,101165,101171,101246,102475,102643,102651,102724.
32
LINE FROM HYDRAULIC UNIT TO LEFT FRONT WHEEL, ONLY APPLICABLE TO ANTI-LOCK BRAKING SYSTEM (ABS)F039532 TO BE ADAPTED DURING ASSEMBLY
38
CONNECTOR , F 102744 ALSO INSTALLED IN F 104063
38
CONNECTOR , Replaced By: A0004282630
53
BRAKE HOSE , 000 158336 003 079229 007 064177 083 004327 086 003286 093 004196 ALSO INSTALLED ON 002924,002958,002959,002981,003004,003013,003017,003025,003114,003171,003282-003298,003300-003332. 102,103 150315 105 165148 183 007371 ALSO INSTALLED ON 003196,003355,003552,003818,003865,004180,004186-004202,004204,004207-004220,004222-004375. 190 011093 ALSO INSTALLED ON 006378,006494,006605,006668,006953,007353-007383,007386-007421.
59
RETAINING SPRING BRAKE HOSE TO BRACKET
62
CLAMP
62
CLAMP BRAKE LINE TO LEFT FRONT WHEELHOUSE PANEL, F 102744
80
BRACKET , Replaced By: A6674280840
95
CLAMP
98
SHIM , Replaced By: A2023280084
98
SHIM BRAKE LINE TO LEFT FRONT WHEELHOUSE PANEL
