Поз.
Артикул
Описание
5
FOLDING TOP ,F 111030NO.9B09 I NO.9B26 INO.5B09INO.5B26INO.8G09I NO.8G26 I NO.9B85I I
5
FOLDING TOP ,F 091721F 111029NO.9B09 I NO.9B26 INO.5B09INO.5B26INO.8G09I NO.8G26 I NO.9B85I I
5
FOLDING TOP ,F 091720NO.9B09 I NO.9B26 INO.5B09INO.5B26INO.8G09I NO.8G26 I NO.9B85I I
11
LEVER FOLDING TOP SUPPORT,F 111029
11
FOLDING TOP GUIDE , Replaced By: A1297700560
11
GUIDE , Replaced By: A1297700560
11
LEVER , Replaced By: A1297700560
17
FOLDING TOP GUIDE , Replaced By: A1297700560
17
BUSHING ,F 0040587/92
20
BUSHING ,F 111029
20
BUSHING FOLDING TOP SUPPORT,F 111030
23
SCREW GUIDE TO LEVER,F 111029
26
PIN LEVER TO FOLDING TOP SUPPORT,F 111030
26
PIN LEVER TO FOLDING TOP SUPPORT,F 111029
29
LOCK PLATE LEVER TO BRACKET
32
FOLLOWER SWITCH CONTROL TO FOLDING TOP RAIL, LEFT,F 097565
35
BUSHING BETWEEN INSIDE AND OUTSIDE BOWS,F 111030YAP 1857/96N 80355
35
BUSHING BETWEEN INSIDE AND OUTSIDE BOWS,F 111029
38
BUSHING PILLAR TAKE-UP DEVICE,YAP 1857/96N 80355
38
BUSHING MAIN GUIDE TAKE-UP DEVICE,YAP 1857/96N 80355
41
BUSHING ,7/92
44
BUSHING ON BOW,OUTSIDE,YAP 1857/96N 80355
47
DAMPER ,F 111029
50
DAMPER ,F 111030
53
PIN ,F 111030
56
GUIDE LEFT,F 111030
56
GUIDE RIGHT,F 111030
56
GUIDE RIGHT,F 111029
56
GUIDE LEFT,F 111029
59
LEVER
62
SPRING WASHER TRANSVERSE CONNECTING PIPE TO CHARGING AIR CONNECTING PIPE
65
CLIP GUIDE TO LEVER AND TO PILLAR
65
LOCK GUIDE TO LEVER AND TO PILLAR,F 111030
68
WASHER GUIDE TO LEVER AND TO PILLAR,F 111030
71
GUIDE ON FOLDING TOP RAIL,RIGHT
71
GUIDE ON FOLDING TOP RAIL,LEFT
71
GUIDE ON FOLDING TOP RAIL,LEFT,F 017510
71
GUIDE ON FOLDING TOP RAIL,LEFT,F 017511
71
GUIDE ON FOLDING TOP RAIL,RIGHT,F 017510
71
GUIDE ON FOLDING TOP RAIL,RIGHT,F 017511
71
GUIDE ,F 017510, Replaced By: A1297703641
71
GUIDE ,F 017510, Replaced By: A1297703541
71
GUIDE , Replaced By: A1297703041
71
GUIDE , Replaced By: A1297702941
71
GUIDE , Replaced By: A1297704441
71
GUIDE , Replaced By: A1297704341
74
DAMPER FOR GUIDE,ON FOLDING TOP RAIL
77
BUSHING FOR GUIDE,ON FOLDING TOP RAIL & PILLAR
80
NUT PROPELLER SHAFT TO TRANSMISSION, INTERMEDIATE BEARING,AND REAR AXLE,082596
83
SCREW MAIN GUIDE TO PILLAR
86
WASHER MAIN GUIDE TO PILLAR
86
WASHER BETWEEN FOLDING TOP GUIDE AND FOLDING TOP RAIL
89
SCREW FOLDING TOP RAIL TO FOLDING TOP MAIN GUIDE,F 012884
89
SCREW GUIDE TO FOLDING TOP RAIL & TO PILLAR,F 012883
92
WASHER FOLDING TOP RAIL TO FOLDING TOP MAIN GUIDE
94
RAIL FABRIC RETAINING RAIL,LEFT
94
RAIL FABRIC RETAINING RAIL,RIGHT
95
PAD BETWEEN FABRIC RETAINING RAIL & B-PILLAR
98
HINGE PART FABRIC RETAINING RAIL,LEFT,F 090317
98
HINGE PART FABRIC RETAINING RAIL,RIGHT,F 090317
98
HINGE PART FABRIC RETAINING RAIL,RIGHT,F 090316
98
HINGE PART , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. F 090761, Replaced By: A1297700817
98
HINGE PART , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. F 090761, Replaced By: A1297700717
98
HINGE PART FABRIC RETAINING RAIL,LEFT,F 090316
101
SCREW
104
SLIDE FABRIC RETAINING RAIL TO FOLDING TOP PILLAR,TOP,F 090316
107
SLIDE FABRIC RETAINING RAIL,RIGHT,F 090317F 111029
107
SLIDE FABRIC RETAINING RAIL,LEFT,F 090317F 111029
110
SLIDE FABRIC RETAINING RAIL LEFT AND RIGHT,F 111030
113
INTERMEDIATE PIECE FABRIC RETAINING RAIL LEFT AND RIGHT,F 111030
116
COMBINATION BOLT FABRIC RETAINING RAIL TO FOLDING TOP PILLAR,TOP
119
PIN , Replaced By: A1299912201
119
PIN , Replaced By: A1299911901
122
SCREW PILLAR TO FOLDING TOP SUPPORT,LEFT,F 091720
122
SCREW PILLAR TO FOLDING TOP SUPPORT,LEFT,F 091720
125
SCREW GUIDE TO FOLDING TOP PILLAR
128
CLAMPING SLEEVE BRACING WIRE TO PILLAR BRACKET,F 111029
131
BRACKET BRACING WIRE TO PILLAR BRACKET,F 111029
134
NUT , Replaced By: N910112006001
134
NUT , Replaced By: N913023006001
134
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
137
WASHER , Replaced By: N009021006208
137
WASHER COMPRESSED AIR LINE TO BRACKET
140
SCREW PIVOT TO FOLDING TOP RAIL
266
PAD BETWEEN FOLDING TOP SUPPORT AND BODY
269
COMBINATION BOLT FOLDING TOP TO BODY
272
SCREW STEERING COLUMN JACKET TUBE TO BODY
293
PLATE FOLDING TOP TO FOLDING TOP CASE BOTTOM,RIGHT
293
PLATE FOLDING TOP TO FOLDING TOP CASE BOTTOM BOTTOM,LEFT
296
HOUSING IN FOLDING TOP CASE BOTTOM CABLE CONDUIT,LEFT
296
HOUSING IN FOLDING TOP CASE BOTTOM CABLE CONDUIT,RIGHT
297
PLATEVERDECKKASTENBODEN
299
HOSE WATER DRAIN
302
OUTLET LEFT
302
OUTLET RIGHT
302
OUTLET , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO.: F 015664, Replaced By: A1297700462
302
OUTLET , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. F 015664, Replaced By: A1297700362
302
OUTLET , Replaced By: A1297700162
999
CLIP LEVER TO FOLDING TOP SUPPORT, NOT USED
999
FOLDING TOP TIGHTENER ON FOLDING TOP FRONT RAIL AND ON PILLAR,RIGHT,F 062963
999
FOLDING TOP TIGHTENER ,F 062963
999
BELT
