Поз.
Артикул
Описание
5
FRAME WITH DRAFT DEFLECTOR, USED W/STEEL VERSION
5
FRAME WITH DRAFT DEFLECTOR, USED W/GLASS VERSION
5
FRAME NON-MAGNETIC SLIDING ROOF WITH AUTO PILOT SYSTEM
5
FRAME , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO.: A 139106, Replaced By: A1407801629
5
FRAME , Replaced By: A1407801729
8
BAFFLE DRAFT DEFLECTOR,A 141900
8
BAFFLE DRAFT DEFLECTOR,A 141901
9
SPRING AT BOTTOM FRAME, FOR DEFLECTOR
11
MOUNTING AT FRAME, FOR DRAFT DEFLECTOR,A 141900
11
MOUNTING RIGHT,A 141901
11
MOUNTING LEFT,A 141901
14
SCREWTO 000 820 07 51
14
SCREW , Replaced By: A0009900729
14
SCREW MOUNTING TO DEFLECTOR,A 141900, Replaced By: N000000003307
17
GUIDE ,A 004653, Replaced By: A1407820731, +001A1407820831
17
GUIDE ,A 004653, Replaced By: A1407820831, +001A1407820731
17
GUIDE ON FRAME,LEFT,A 004654
17
GUIDE ON FRAME,RIGHT,A 004654
20
PLASTIC PAD , Replaced By: A1266900018
20
TREENAIL (WATER DEFLECTOR) ON FRONT PANEL PILLAR, A 444048 F 494601
23
NUT RETAINER BOTTOM FRAME
29
SLIDING RAIL FRONT LEFT
29
SLIDING RAIL FRONT RIGHT
29
SLIDING RAIL ,A 219230, Replaced By: A1407821126, +001A1407820313, +001A1407821226
29
SLIDING RAIL , Replaced By: A1407821226, +001A1407820313, +001A1407821126
35
SCREW
41
SCREW
41
SCREW
44
BRACKET CABLE HARNESS MOUNTING
44
BRACKET , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO.: A 197266, Replaced By: A1407822514
47
SEAL BETWEEN TOP AND BOTTOM FRAMES
50
PAD
50
PAD BETWEEN ROOF PANELLING AND BOTTOM FRAME
53
PAD BOTTOM FRAME
56
RAIL FRONT
59
RAIL LEFT
59
RAIL RIGHT
59
RAIL LEFT
59
RAIL RIGHT
62
RAIL REAR
65
HOSEWASSERABLAUF HINTEN 250 MM
65
HOSE WATER DRAIN,FRONT 1420 MM
68
RAIL
68
COVER RAIL ,A 219230, Replaced By: A1407820313, +001A1407821126, +001A1407821226
68
COVER RAIL , Replaced By: A1407800813
71
CLIP COVER RAIL TO BOTTOM FRAME,FRONT
74
RIVET MOUNTING RAIL TO REINFORCEMENT FRAME
77
SCREW MOUNTING RAIL TO REINFORCEMENT FRAME
80
SCREW FRAME TO REINFORCEMENT FRAME
83
LOCK FRAME TO REINFORCEMENT FRAME
86
PAD
89
CLAMP
89
CLAMP , Replaced By: A0009955244
95
NUT RETAINER , Replaced By: A3229900091
98
SCREW , 183 003776 190 004444
