Mercedes N006799005002 - ШАЙБА

400 SE USA 140.042
75 REAR LID - 030 REAR LID LATCH-TYPE LOCK, REAR LID ATTACHMENT PARTS IL. 2
  • Поз.
    Артикул
    Описание
  • 5
    BEARING BRACKET , UP TO END OF MODEL YEAR'96
  • 5
    BEARING BRACKET , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. A 107503 OWING TO A CHANGE OF DESIGN IN THE CASE OF THE NEW BEARING BRACKET, THE SHUTTER GUIDES WERE ELIMINATED WITHOUT A SUBSTITUTION AND CAN NO LONGER BE INSTALLED, Replaced By: A1402670437
  • 8
    BRACKET LIGHT GUIDE
  • 11
    SHAFT , A 242084 A 328810 EXCEPT CODE 807 ALSO INSTALLED IN VEHICLE FROM A 328811 WITH CODE 806
  • 11
    SHAFT , A 242083
  • 14
    LIGHT GUIDE
  • 17
    SUPPORT LIGHT GUIDE, A 328810 EXCEPT CODE 807 ALSO INSTALLED IN VEHICLE FROM A 328811 WITH CODE 806
  • 20
    PIN SUPPORT ON SHIFT SHAFT
  • 23
    LOCK PLATE PIN TO CLUTCH SLAVE CYLINDER BOOT, Replaced By: N006799005004
  • 26
    YOKE , A 242083
  • 26
    YOKE , Replaced By: A1402600253
  • 27
    SHIFT LEVER , A 242084 A 328810 EXCEPT CODE 807 ALSO INSTALLED IN VEHICLE FROM A 328811 WITH CODE 806
  • 29
    SPRING YOKE TO SHIFTING SHAFT, A 242083
  • 30
    SPRING
  • 32
    PIN YOKE TO SHIFTING SHAFT, A 242083
  • 33
    PIN BRACKET TO SHIFT LEVER,K 032407
  • 35
    LOCK PLATE PIN TO CLUTCH SLAVE CYLINDER BOOT, Replaced By: N006799005004
  • 38
    BUSHING YOKE TO SHIFTING SHAFT, A 242083
  • 39
    BUSHING BRACKET TO SHIFT LEVER,K 032407
  • 41
    WASHER SUPPORT ON SHIFT SHAFT
  • 47
    SWITCH SUPPORT ON SHIFT SHAFT
  • 50
    SHIFTING SEGMENT 1ST SPEED, UP TO END OF MODEL YEAR'95
  • 92
    INDICATOR SLOTTED GATE LIGHTING
  • 92
    INDICATOR ,A 004652, Replaced By: A1405401149, +001A1402670226
  • 104
    GUIDE SHUTTER TO 140 267 01 37 / 03 37, A 328810 EXCEPT CODE 807 ALSO INSTALLED IN VEHICLE FROM A 328811 WITH CODE 806
  • 107
    GUIDE SHUTTER, A 328810 EXCEPT CODE 807 ALSO INSTALLED IN VEHICLE FROM A 328811 WITH CODE 806
  • 110
    SHUTTER , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. A 004652, Replaced By: A1402670226
  • 110
    SHUTTER
  • 113
    SLOTTED GATE , UP TO END OF MODEL YEAR'95
  • 116
    KNOB SELECTOR LEVER HANDLE WITH LEATHER COVER,BLACK, A 242083
  • 116
    HANDLE GEAR SELECTOR LEVER W/LEATHER FINISH, FROM MODEL YEAR'95 A 242083NO.9045I NO.5070I NO.8310I NO.8310I NO.8F94I ------ I NO.3111I NO.7102I
  • 117
    HANDLE SELECTOR LEVER HANDLE WITH LEATHER COVER,BLACK, A 242084 ORDER ADDITIONALLY: BADGE FOR SELECTOR LEVER HANDLE
  • 117
    HANDLE SELECTOR LEVER HANDLE WITH LEATHER COVER, SAFFRON, A 242084 ORDER ADDITIONALLY: BADGE FOR SELECTOR LEVER HANDLE
  • 117
    HANDLE SELECTOR LEVER HANDLE WITH LEATHER COVER,MEDIUM RED, A 242084 ORDER ADDITIONALLY: BADGE FOR SELECTOR LEVER HANDLE
  • 117
    HANDLE SELECTOR LEVER HANDLE WITH LEATHER COVER,GREY, A 242084
  • 117
    HANDLE SELECTOR LEVER HANDLE WITH LEATHER COVER, MUSHROOM, A 242084
  • 117
    HANDLE SELECTOR LEVER HANDLE WITH LEATHER COVER,BLUE, A 242084 ORDER ADDITIONALLY: BADGE FOR SELECTOR LEVER HANDLE
  • 118
    GUMMED LABEL BADGE FOR SELECTOR LEVER HANDLE, A 242084
  • 119
    GASKET BEARING BRACKET TO TUNNEL
  • 122
    SCREW
  • 167
    SOCKET LAMP WITH SOCKET 12 V
  • 170
    COVERING , A 328810 EXCEPT CODE 807 ALSO INSTALLED IN VEHICLE FROM A 328811 WITH CODE 806
  • 176
    SHIFTING ROD , UP TO END OF MODEL YEAR'95
  • 179
    END PIECE
  • 182
    BUSHING
  • 182
    BUSHING FROM LEVER TO VALVE BODY ASSEMBLY
  • 185
    NUT
  • 188
    BUSHING RANGE SELECTOR LEVER
  • 188
    BUSHING GEAR SELECTOR LEVER
  • 191
    LOCK
  • 191
    PIN LOCK SHIFTING ROD
