Поз.
Артикул
Описание
53
GROMMET HOSE THRU ENGINE COMPARTMENT PARTITION PANEL
56
HOSE FROM ENGINE TO HEAT EXCHANGER
56
HOSE FROM ENGINE TO HEAT EXCHANGER, TO BE ADAPTED DURING ASSEMBLY
56
HOSE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. A 155557, Replaced By: A1408302496
56
HOSE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. A 155557, Replaced By: A1408301696
56
HOSE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. A 155557, Replaced By: A1408301696
56
PIPE LINE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. A 155557, Replaced By: A1408301696
59
HOSE , Replaced By: A1408321188
59
HOSE FROM ENGINE TO HEAT EXCHANGER
71
HOSE VEHICLE HEATING, RETURN,LEFT
74
HOSE VEHICLE HEATING, RETURN,RIGHT
77
GROMMET AT CROSS MEMBER BELOW WINDSHIELD, FOR HEAT EXCHANGER AND WINDSHIELD
82
HOSE RETURN
83
HOSE VEHICLE HEATING, RETURN
86
HOSE WINDSHIELD-WASHER/WINDSHIELD HEATING
95
HOSE VEHICLE HEATING, RUN-ON COOLING
98
HOSE CLAMP LINE MOUNTING
98
CLAMP , Replaced By: A0059970190
110
PIPE LINE
113
HOSE , Replaced By: A1408301096
113
HOSE WINDSHIELD HEATING, RETURN
116
GROMMET HOSE THRU ENGINE COMPARTMENT PARTITION PANEL
125
HOSE FROM THERMO-VALVE TO PANE WASHER RETURN
128
HOSE CLAMP LINE MOUNTING
128
CLAMP , Replaced By: A0059970190
149
PIPE LINE RETURN, FROM HEAT EXCHANGER TO WATER VALVE
152
GROMMET PIPE LINE THRU PARTITION PANEL
155
SHEET METAL SCREW BRACKET TO CAB FLOOR
158
WASHER VALVE TO BRACKET
170
PIPE LINE RETURN, PANE WASHER WATER HEATING
173
PIPE LINE FEED, PANE WASHER WATER HEATING
176
BRACKET REFRIGERANT LINE TO PARTITION PANEL
177
BRACKET WINDSHIELD WASHER PIPE LINE AND BRAKE LINE TO PARTITION PANEL
179
BRACKET , Replaced By: A6674280840
179
BRACKET BRAKE LINE TO FIRE WALL
182
BRACKET LINE MOUNTING,5 473495
185
BRACKET WINDSHIELD WASHER PIPE LINE AND BRAKE LINE TO PARTITION PANEL
185
BRACKET , Replaced By: A0008321214
188
HOSE FEED, PANE WASHER WATER HEATING
190
CLAMP ELECTRIC CABLE TO BRAKE HOSE
192
CLAMP COMPRSSED AIR LINE TO SUBSTRUCTURE
194
HOSE RETURN, PANE WASHER WATER HEATING
206
HEATER UNIT WINDSHIELD HEATING, BELOW WINDSHIELD
209
INTERMEDIATE LAYER PARTS KIT 2.2 MM
209
INTERMEDIATE LAYER PARTS KIT 1.2 MM
212
GROMMET AT CROSS MEMBER BELOW WINDSHIELD
213
CLIP AT CROSS MEMBER BELOW WINDSHIELD
215
VALVE WINDSHIELD HEATING
263
CLAMP
323
HOSE CLAMP LINE MOUNTING
323
HOSE CLAMP8-16
323
CLAMP PRESSURE REGULATOR
323
CLAMP , Replaced By: N000000000667
323
CLAMP , Replaced By: A0059970190
323
CLAMP , Replaced By: A0059970190
323
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
