Поз.
Артикул
Описание
10
TRIM BUMPER REAR TOP, TO BE PAINTED PRIOR TO INSTALLATION 9999QFT166L9000 COLORLESS
10
TRIM BUMPER REAR TOP, TO BE PAINTED PRIOR TO INSTALLATION 9999QFT166L9000 COLORLESS
20
TRIM BUMPER REAR BOTTOM, L 00301720131130 M 00301720131130 A 20131014 TO BE PAINTED PRIOR TO INSTALLATION 9999QFT166L9000 COLORLESS
20
TRIM BUMPER REAR BOTTOM
25
COVER TRAILER HITCH REAR BOTTOM, A 20131014
26
SCREW-AND-WASHER ASSEMBLY SERVICE FLAP M6X20
27
CLIP PANELING MOUNTING, RIGHT
30
COVER TOWING EYE TOWING EYE
35
LOCK NUT BRACKET TO RIGHT FRONT SIDE MEMBER ST 4.8/2.5-5.0 MM
37
SHEET METAL SCREW BRACKET TO FIRE WALL
40
REBOUND STRAP FLAP FOR TOW HOOK
50
BASIC MOUNTING FOR BUMPER CENTRAL
55
NUT-AND-WASHER ASSEMBLY EVAPORATOR HOUSING TO CROSSMEMBER M6
60
MOLDING STEP CENTRAL TOP
70
BASIC MOUNTING FOR BUMPER RIGHT
70
BASIC MOUNTING FOR BUMPER LEFT
120
REAR REFLECTOR REAR LEFT
120
REAR REFLECTOR REAR RIGHT
130
ORNAMENTAL MOLDING CHROME
135
ORNAMENTAL MOLDING CHROME
140
COVER TOWING EYE CHROME
145
CHECK STRAP TOWING EYE
150
BRACKET LEFT, L 00148920130531 M 00148920130531 A 20130501
150
BRACKET RIGHT, L 00148920130531 M 00148920130531 A 20130501
160
BOLT LOWER SUPPORT M6X19
160
SCREW-AND-WASHER ASSEMBLY SERVICE FLAP M6X20
180
BRACKET REAR RIGHT
180
BRACKET REAR LEFT
190
RIVET COVERING TO SIDE MEMBER
200
RADAR SENSOR LEFT AND RIGHT OUTSIDE, PART MUST BE CHECKED AFTER INSTALLATION FOR CURRENT FLASHWARE
200
RADAR SENSOR LEFT AND RIGHT OUTSIDE, PART MUST BE CHECKED AFTER INSTALLATION FOR CURRENT FLASHWARE, Replaced By: A0009052604
200
RADAR SENSOR PROXIMITY-CONTROLLED CRUISE CONTROL, PART MUST BE CHECKED AFTER INSTALLATION FOR CURRENT FLASHWARE
220
INSULATION LEFT AND RIGHT REINFORCEMENT, A 06067720070521
230
MOUNTING RAIL RIGHT
230
MOUNTING RAIL LEFT
235
MOUNTING CLAMP BUMPER LOWER SECTION, J 53092220070910808
240
NUT GUIDE AT REAR FENDER, J 53092220070910808
250
PLASTIC NUT. NUT
260
TREENAIL GUIDE AT REAR FENDER
270
TREENAIL GUIDE AT REAR FENDER
280
BOLT BUMPER MOUNTING BELOW REAR PANEL DOOR 5X21
330
WHEEL HOUSE COVERING REAR LEFT, A 14162320121005
330
WHEEL HOUSE COVERING REAR RIGHT, A 14162320121005
340
RIVET COVERING TO SIDE MEMBER
350
BRACKET REAR BUMPER, BOTTOM
355
COVER BUMPER AREA REAR CENTRAL
360
RIVET COVERING TO SIDE MEMBER
370
PLASTIC NUT. NUT
380
RIVET COVERING TO SIDE MEMBER
400
ELECTRICAL WIRING HARNESS PARKTRONIC SYSTEM, REAR
400
ELECTRICAL WIRING HARNESS PARKTRONIC SYSTEM, REAR
410
SENSOR CENTRAL, TO BE PAINTED PRIOR TO INSTALLATION
420
SPACER RING PARKTRONIC SYSTEM
450
ELECTRICAL WIRING HARNESS BLIND SPOT ASSISTANT
