Поз.
Артикул
Описание
14
FUEL TANK150 L,093523
14
FUEL TANK LESS SENDER UNIT 190L,093522
14
FUEL TANK LESS SENDER UNIT 270 L,075828
18
COVER FUEL TANK
26
SCREW LEVER TO SHAFT
27
SEAL RING SENDER UNIT AND COVER TO FUEL TANK
28
SCREW COVER PLATE TO COVER PLATE M 6 X 12
29
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
30
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
31
GASKET SENDER UNIT AND COVER TO FUEL TANK
31
GASKET FUEL GAUGE SENDER UNIT TO FUEL TANK
33
FILLER CAP FUEL-OIL TANK,075828
34
GASKET
34
GASKET
36
CONNECTOR ,075828
37
SEAL RING ,075828
38
BOOT ,075828
57
SENDER UNIT FUEL GAUGE
65
SCREW , Replaced By: N304017005002
65
SCREW LEVER TO SHAFT
68
SEAL RING SENDER UNIT AND COVER TO FUEL TANK
71
STRAP
71
STRAP
74
PAD FUEL TANK TO SUPPORT, ORDER BY THE METER
74
PAD FUEL TANK TO SUPPORT, ORDER BY THE METER
77
SCREW VALVE TO BRACKET
80
WASHER BRACKET TO LEFT SIDE MEMBER
83
NUT , Replaced By: N304032008006
999
BOOT , Replaced By: A0004710181
999
FUEL FILLER CAPTO 612 470 05 04,612 470 06 04,093523
