Поз.
Артикул
Описание
110
LOCKING MECHANISM RIGHT
110
LOCKING MECHANISM LEFT
113
LEVER LEFT
113
LEVER RIGHT
116
PULL RIGHT
116
PULL LEFT
119
PIN RIGHT
119
PIN LEFT
122
SCREW
125
SCREW UPPER PANELLING
128
SCREW SUPPORT TO CYLINDER CRANKCASE
131
NUT ALTERNATOR,TERMINAL B+
173
HOUSING
176
COVERING. COVER REAR BACKREST, TOP, LEFT
179
COVERING RIGHT,NO.9B51I NO.5076I NO.8F20I NO.8F30I .......I NO.7101I NO.9B51I NO.9B51I NO.9B51INO.9B51I NO.9B51I .......I NO.9B51I .......I NO.9B51I
182
SCREW
185
TAKE-UP DEVICE BELT LOCK BRACKET,LEFT
185
TAKE-UP DEVICE BELT LOCK BRACKET,RIGHT,NO.9B51I NO.5076I NO.8F20I NO.8F30I .......I NO.7101I NO.9B51I NO.9B51I NO.9B51INO.9B51I NO.9B51I .......I NO.9B51I .......I NO.9B51I
188
SCREW FASTENING MOUNTING RIGHT
191
BACKREST ADJUSTER LEFT
191
BACKREST ADJUSTER LEFT,A 659700 , X 010311
191
BACKREST ADJUSTER RIGHT
194
SCREW LEFT REAR BACKREST
197
SCREW RIGHT REAR BACKREST
200
COVERING ,NO.9B51I NO.5076I NO.8F20I NO.8F30I .......I NO.7101I NO.9B51I NO.9B51I NO.9B51INO.9B51I NO.9B51I .......I NO.9B51I .......I NO.9B51I
200
COVERING ,NO.9B51I NO.5076I NO.8F20I NO.8F30I .......I NO.7101I NO.9B51I NO.9B51I NO.9B51INO.9B51I NO.9B51I .......I NO.9B51I .......I NO.9B51I
212
GUIDE ,NO.7C45
215
GUIDE LEFT,HEADREST, NO.7C45 INO.5076 INO.8F20 INO.8F30 INO.3112 INO.7101 INO.7C45 INO.7C45 INO.7C45 I
218
SUPPORT
221
SPRING
224
PIN ,A 554982 , X 005476
224
PIN ,A 554981 , X 005475
227
BUSHING
230
PLATE , NO LONGER AVAILABLE
233
SCREW
236
COVERING
239
CLIP REINFORCEMENT TO PANELLING
242
FOLDING ARMREST IMITATION LEATHER,NO.9B50I NO.5B29I NO.8G01I NO.8G06I .......I NO.7D03I I
242
FOLDING ARMREST LEATHER
242
FOLDING ARMREST FABRIC,NO.9B52I NO.5B34I .......I NO.8G09I .......I NO.7D01I NO.9B52I NO.9B52I NO.9B52I
245
HOUSING ,NO.9B51I NO.9B51I NO.9B51I NO.9B51I NO.9B51I NO.9B51I NO.9B63I NO.9B64I NO.9B62I
248
BRACKET REAR BACKREST DETENT
250
PLATE REAR BACKREST DETENT
251
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
254
SCREW
257
NUT BATTERY CABLE
999
BACKREST ADJUSTER CHILD'S SEAT, RIGHT
999
BACKREST ADJUSTER CHILD'S SEAT, LEFT
