Поз.
Артикул
Описание
10
OPERATING UNIT COMAND, A 00190920061030807 NO LONGER AVAILABLE
10
CONTROL COMAND
10
OPERATING UNIT COMAND, FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. A 00175420060626, Replaced By: A2408208889
10
OPERATING UNIT COMAND, A 00115720040916 FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. A 00179720060907 STATE IDENT NO. WHEN ORDERING PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A2408208989
10
CONTROL COMAND, A 00115720040916 FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. A 00187120060930 STATE IDENT NO. WHEN ORDERING, Replaced By: A2408209089
10
CONTROL COMAND, FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. A 00225820071120, Replaced By: A2408209189
10
OPERATING UNIT COMAND, A 00190920061030807 FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. A 00240920080516 STATE IDENT NO. WHEN ORDERING PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A2408700489
10
CONTROL COMAND, A 00190920061030807 FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. A 00240920080516 STATE IDENT NO. WHEN ORDERING, Replaced By: A2408700589
10
OPERATING UNIT COMAND, A 00190920061030807 FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. A 00255120081020 NOTE COND. RETURN VIA SYREK SETTLEMENT IN GERMANY. PLEASE ALSO ORDER AS REPLACEMENT PART. PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A2408700789
10
OPERATING UNIT COMAND, A 00190920061030807 FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. A 00255120081020, Replaced By: A2408700889
10
CONTROL COMAND, A 00190920061030807 FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. A 00269920090420, Replaced By: A2409060000
10
CONTROL COMAND COMAND USA, A 00115720040916 A 00212220070531808 NOTE COND. RETURN VIA SYREK SETTLEMENT IN GERMANY. PLEASE ALSO ORDER AS REPLACEMENT PART. STATE IDENT NO. WHEN ORDERING
10
CONTROL COMAND, A 00190920061030807
10
OPERATING UNIT COMAND COMAND ECE, A 00115720040916 A 00212220070531808 STATE IDENT NO. WHEN ORDERING PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
12
HOUSING CONTROL UNIT, SOUND AMPLIFIER 6-PIN MQS, MOST,N40/3
12
PLUG HOUSING CONTROL UNIT, SOUND AMPLIFIER 4-PIN MQS,N40/3
14
REP.SET CONTACT0.75 MM2 MQS, CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED. SEE WIS FOR REPAIR INSTRUCTIONS.SOLDER CONNECTOR SLEEVES:TOTAL WIRE CROSS-SECTION: A 001 546 99 41GREEN0.7 -2.4 MM2 A 002 546 00 41RED2.0 -4.0 MM2 A 002 546 01 41BLUE 3.5 -8.0 MM2 A 002 546 11 41YELLOW 7.5 - 12.0 MM2 BUTT JOINT: A 002 546 13 41 0.5 MM2 A 002 546 14 41 0.8 MM2 A 002 546 15 41 1.3 MM2 A 002 546 16 41 2.0 MM2
14
REP.SET CONTACT. CABLE HARNESS
15
RING CONTROL PANEL, LEFT
15
RING CONTROL PANEL, LEFT
16
RING CONTROL PANEL, LEFT
17
ORNAMENTAL RING CONTROL PANEL, RIGHT, A 00115720040916
17
ORNAMENTAL RING CONTROL PANEL, RIGHT
20
HEXALOBULAR BOLT LIGHT SWITCH M4X6
22
BRACKET OPERATING MODULE, LEFT
22
BRACKET OPERATING MODULE, RIGHT
26
HEXAGON NUT. NUT ELECTRIC CABLE TO ALTERNATOR
30
BRACKET COMAND OPERATING MODULE
40
SHEET METAL SCREW BRACKET TO SUPPORT
50
CLIP FASTENER. SPRING NUT
55
OPERATING INSTRUCTIONS IN FINNISH, A 00171020060322
55
OPERATING INSTRUCTIONS IN GERMAN, A 00171020060322
55
OPERATING INSTRUCTIONS IN SPANISH, A 00171020060322
55
OPERATING INSTRUCTIONS IN ITALIAN, A 00171020060322
55
OPERATING INSTRUCTIONS IN SWEDISH, A 00171020060322
55
OPERATING INSTRUCTIONS IN FRENCH, A 00171020060322
55
OPERATING INSTRUCTIONS IN DUTCH, A 00171020060322
55
OPERATING INSTRUCTIONS IN ENGLISH, A 00171020060322
55
OPERATING INSTRUCTIONS IN RUSSIAN, A 00171020060322
55
OPERATING INSTRUCTIONS IN PORTUGUESE, A 00171020060322
55
OPERATING INSTRUCTIONS IN DANISH, A 00171020060322
