Поз.
Артикул
Описание
51
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
51
HOSE , Replaced By: A0009872827
53
FITTING , Replaced By: A0029906171
53
FITTING (PARTS KIT),LINE RUPTURE
55
UNION NUT LINE CONNECTION, Replaced By: N000000006239
55
UNION NUT LINE CONNECTION
59
GLAND , Replaced By: A0019901967
59
SEAL CONE LINE CONNECTION
63
BANJO UNION FROM BULKHEAD FITTING TO PRESSURE REGULATOR
67
SLEEVE LINE CONNECTION
71
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
107
LOOM TIE LINE MOUNTING
111
CLIP ,303365
111
CLIP
119
INSULATING HOSE AIR DEHYDRATOR, ORDER BY THE METER
123
GROMMET
127
PLASTIC SECTION CABLE HARNESS TO ROOF RAIL
683
RESERVOIR COMPRESSED AIR,5 295503
683
RESERVOIR , Replaced By: A0034321201
683
RESERVOIR , Replaced By: A0004324301
687
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
691
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
691
THRUST RING CHECK VALVE TO AIR RESERVOIR
695
O-RING CHECK VALVE TO AIR RESERVOIR
699
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
703
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
707
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
711
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
711
THRUST RING CHECK VALVE TO AIR RESERVOIR
715
O-RING CHECK VALVE TO AIR RESERVOIR
719
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
723
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
727
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
727
TEST CONNECTION
727
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
727
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
731
VALVE. DRAIN VALVE DRAIN
731
VALVE DRAIN, Replaced By: A0004322107
731
VALVE DRAIN, Replaced By: A0004322407
733
RING DRAIN VALVE TO 000 432 08 07, NOT USED
735
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
735
THRUST RING CHECK VALVE TO AIR RESERVOIR
739
O-RING CHECK VALVE TO AIR RESERVOIR
743
SCREW PLUG , Replaced By: N000908022011
743
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
747
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
747
THRUST RING CHECK VALVE TO AIR RESERVOIR
751
O-RING CHECK VALVE TO AIR RESERVOIR
999
SEAL RING , Replaced By: A0049970248
999
PRESSURE REGULATORWABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
PRESSURE REGULATOR , Replaced By: A0024314306
999
PRESSURE REGULATOR ,5 148812, Replaced By: A0024314306
999
PRESSURE REGULATOR , Replaced By: A0024314906
999
PRESSURE REGULATOR , Replaced By: A0024313406
999
PRESSURE REGULATOR , Replaced By: A0024314906
999
SPRING , Replaced By: A0009935205
