Поз.
Артикул
Описание
5
AIR INTAKE PIPE TO OIL BATH AIR CLEANER,4 1972178 000001
5
HOSE ,4 197216, Replaced By: A3145280508, +002A3145280060
10
SEAL RING TO OIL BATH AIR CLEANER,4 1972178 000001
15
CLAMP HOSE 70-90X13 MM
15
CLAMP , Replaced By: N000000000674
20
AIR CLEANER OIL BATH MANN & HUMMEL
20
AIR CLEANER , Replaced By: A0070941502
26
FILTER BOWL LOWER PART
30
FILTER ELEMENT
34
GASKET INSIDE
38
GASKET OUTSIDE
39
FASTENER
40
SCREW END PIECE TO EXHAUST PIPE M 10X25
42
NUT STRAP TO BRACKET
42
NUT , Replaced By: N910113010000
43
CONSOLE CAB SUSPENSION,681569
44
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
45
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
46
NUT BRACKET TO SUPPORT AND TO END PIECE
50
BRACKET AIR CLEANER,701361-965592
55
RUBBER BUFFER OIL BATH AIR CLEANER MOUNTING,701361-965592
55
RUBBER BUFFER OIL BATH AIR CLEANER MOUNTING,701361-965592
60
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
65
NUT
66
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
66
NUT , Replaced By: N913004008001
67
SCREW END PIECE TO EXHAUST PIPE M 10X25
67
SCREW END PIECE TO EXHAUST PIPE M 10X25
67
SCREW HEATING PIPE TO BRACKET M 10X30
67
SCREW BRACKET TO CROSS CONNECTION STRUT
67
SCREW , Replaced By: N304017008034
68
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
68
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
69
NUT AIR CLEANER ELEMENT
69
NUT BRACKET TO SUPPORT AND TO END PIECE
69
NUT
80
HOSE FROM AIR CLEANER TO AIR INTAKE PIPE,035923
80
HOSE OIL BATH AIR CLEANER,611434035922
80
HOSE OIL BATH AIR CLEANER TO BRACKET AT FIRE WALL,611433 ORDER BY THE METER
86
CLAMP HOSE 70-90X13 MM
86
CLAMP HOSE 70-90X13 MM
86
CLAMP , Replaced By: N000000000674
100
AIR INTAKE PIPE
100
AIR INTAKE PIPE
100
AIR INTAKE PIPE , Replaced By: A3095280608
100
AIR CLEANER INTAKE MUFFLER,611434035922
100
AIR CLEANER ,611433, Replaced By: A3140900204, +001A3140900082
103
SCREW PIPE CLAMP
103
SCREW , Replaced By: N304017008021
104
WASHER EXHAUST MUFFLER TO STRAP
104
WASHER , Replaced By: N000125008443
105
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
106
NUT
114
HOSE FROM AIR INTAKE PIPE TO ENGINE,4 657299
114
HOSE , Replaced By: A3140940882, +001A3140100878
114
BOOT INTAKE PIPE TO CAB,035922
114
BOOT , Replaced By: A3140940291
118
CLAMP HOSE 70-90X13 MM
118
CLAMP , Replaced By: N000000000674
122
EXPANSION PLUG BREATHER HOSE THRU FLOOR PLATE,775095
122
EXPANSION PLUG TO PLUG THE FREE HOLES FOR TELL-TALE LAMP
125
GROMMET ENGINE COVERING
130
PLUG FIRE WALL,RIGHT
132
CAP STARTER PILOT, 808268
134
FAN SHROUD AIR INTAKE,4 755510
134
FAN SHROUD AIR INTAKE,4 755509
134
FAN SHROUD AIR INTAKE,4 755509
138
SCREW IN CASE OF SUBSEQUENT INSTALLATION
143
LOCK WASHER BRACKET TO STEERING COLUMN END
148
WASHER BOOT TO CAB FLOOR
148
WASHER , Replaced By: N000433005304
999
HOSE , Replaced By: A3140941082
999
HOSE , Replaced By: A3140941082
999
BRACKET AIR CLEANER,035922
999
BRACKET AIR CLEANER,035923701360
