Поз.
Артикул
Описание
8
FRONT AXLE BEAM ,6951998 000001
11
BOLT
14
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
17
NUT
20
STEERING KNUCKLE ,6951998 000001
20
STEERING KNUCKLE , Replaced By: A3163300120
23
BUSHING
23
BUSHING STEERING KNUCKLE,6951998 000001
26
SEAL RING STEERING KNUCKLE,6951998 000001
26
SEAL RING STEERING KNUCKLE,6951998 000001
29
THRUST WASHER INTERMEDIATE LEVER TO STEERING SUPPORT
32
NUT CYLINDER TO BEARING BRACKET AND PITMAN ARM M24X1.5
35
COTTER PINTO 000 429 16 30
38
SCREW. CAP BOLT COVER TO CASE M8X25
38
SCREW , Replaced By: N000912008202
41
NUT , Replaced By: A6753300088
41
NUT
44
GREASE NIPPLE PROTECTIVE TUBE
47
EXPANSION PLUG
50
SCREW LEFT AND RIGHT CONSOLES TO CAB
50
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
50
SCREW , Replaced By: N308676012015
53
NUT STRAP TO SUPPORT
56
PLUG TO PLUG HYDRAULIC LINE
59
KING PIN PARTS KIT,STANDARD 30 MM,6951998 000001
59
KING PIN PARTS KIT,STANDARD 30 MM
62
KINGPIN STANDARD SIZE I,6951998 000001
62
KINGPIN KINGPIN,STANDARD SIZE I 30.30 MM
65
TAPERED ROLLER BEARING STEERING KNUCKLE,6951998 000001
65
ROLLER BEARING STEERING KNUCKLE,6951998 000001
65
ROLLER BEARING STEERING KNUCKLE,6951998 000001
68
SPACER WASHER1.40 MM
68
SPACER WASHER0.90 MM
68
SPACER WASHER1.60 MM
68
SPACER WASHER1.20 MM
68
SPACER WASHER2.10 MM
68
SPACER WASHER1.50 MM
68
SPACER WASHER1.70 MM
68
SPACER WASHER1.10 MM
68
SPACER WASHER1.30 MM
68
SPACER WASHER1.00 MM
71
OIL COLLECTOR ,6951998 000001
74
RING
74
RING
77
SEAL RING
77
SEAL RING
80
SEAL HOLDER , 791606
83
SPACER RING , ELIMINATED - NO LONGER REQUIRED
86
TAPERED ROLLER BEARING
86
TAPERED ROLLER BEARING OUTSIDE
86
TAPERED ROLLER BEARING
86
TAPERED ROLLER BEARING , Replaced By: A0029819105
86
TAPERED ROLLER BEARING
89
DRUM HUB
92
WHEEL MOUNTING BOLT
95
TAPERED ROLLER BEARING , FROM CHASSIS 791607-910369 ALSO INSTALLED ON 500000-501455
95
TAPERED ROLLER BEARING DRIVE SHAFT, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
95
TAPERED ROLLER BEARING DRIVE SHAFT, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
95
TAPERED ROLLER BEARING , FROM CHASSIS 791607-910369 ALSO INSTALLED ON 500000-501455
95
TAPERED ROLLER BEARING , FROM CHASSIS 791607-910369 ALSO INSTALLED ON 500000-501455
95
TAPERED ROLLER BEARING DRIVE SHAFT, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
98
HUB CAP
98
HUB CAP STEERING INTERMEDIATE BRACKET
999
BOOT , Replaced By: A0004631396
999
JOINT , Replaced By: A0003308535
999
JOINT , Replaced By: A0003308635
999
CLAMP , Replaced By: A0009957044
999
SEAL RING , Replaced By: A0089977546
999
BUSHING , Replaced By: A3533320048
999
HUB CAP , Replaced By: A3183340025
999
SPACER WASHER , Replaced By: A3143320452
999
WHEEL MOUNTING BOLT , Replaced By: A3144020071
999
STEERING KNUCKLE , Replaced By: A3163300220, +001A3163300119
999
TIE ROD , Replaced By: A3163300603
999
STEERING KNUCKLE , Replaced By: A3163320101
999
DRUM HUB , Replaced By: A3163340304, +001A3183340025, +001A3163340182, +006A3144020071, +001A0009807502, +001A0019818305
999
DRUM HUB , Replaced By: A3163340304, +001A3183340025, +001A3163340182, +006A3144020071, +001A0009807502, +001A0019818305
999
DRUM HUB , Replaced By: A3163340304, +006A3144020071
999
DRUM HUB , Replaced By: A3163340304, +006A3144020071
999
FRONT AXLE BEAM , Replaced By: A3163310201
999
FRONT AXLE BEAM , Replaced By: A3163310201
999
KINGPIN , Replaced By: A3165860033
999
BUSHING , Replaced By: A3163320048
999
SPACER RING , ELIMINATED,NO LONGER REQUIRED
999
OIL COLLECTOR , Replaced By: A3163340182
999
SPACER RING , ELIMINATED - NO LONGER REQUIRED
999
STEERING ARM , Replaced By: A3163380207
999
STEERING ARM , Replaced By: A3163380208
999
STEERING ARM , Replaced By: A3163380305
999
STEERING ARM , Replaced By: A3163380306
999
STEERING ARM , Replaced By: A3163380707
999
STEERING ARM , Replaced By: A3163380708
999
REPAIR KIT , Replaced By: A3163300019
999
REPAIR KIT , Replaced By: A3163300119
999
HUB CAP , Replaced By: A3143340025
999
PLUG , Replaced By: N900087008000
