Поз.
Артикул
Описание
322
LINE FROM VALVE TO BRAKE HOSE 1500 MM
322
LINE FROM MASTER CYLINDER TO FRONT AXLE TEST CONNECTION 2600 MM
322
LINE FROM MASTER CYLINDER TO FRONT AXLE TEST CONNECTION 2600 MM
322
LINE1750 MM, UP TO IDENT NO. 721608 EXCEPT FOR:500001-599999
322
LINE1750 MM, UP TO IDENT NO. 721608 EXCEPT FOR:500001-599999
322
LINE FROM DISTRIBUTOR TO VALVE 3000 MM
322
LINE FROM TEST CONNECTION TO RIGHT FRONT WHEEL 2200 MM,4 478329
329
LINE FROM DISTRIBUTOR TO BRAKE HOSE ON REAR AXLE 415 MM,4 478330
329
LINE FROM VALVE TO CONNECTION FITTING 1500 MM, TO BE ADAPTED DURING ASSEMBLY
329
LINE FROM VALVE TO CONNECTION FITTING 1500 MM, TO BE ADAPTED DURING ASSEMBLY
329
LINE FROM VALVE TO CONNECTION FITTING 1500 MM, TO BE ADAPTED DURING ASSEMBLY
330
LINE FROM FITTING TO CLUTCH BOOSTER 3000 MM
331
LINE FROM FAN SHROUD BRACKET TO FITTING 2500 MM
332
BRAKE HOSE AT REAR AXLE
333
BRAKE HOSE
333
BRAKE HOSE
334
INTERMEDIATE PIECE CLUTCH HOSE,K 172342
335
BRACKET OIL LINE MOUNTING
336
SCREW COVER PLATE TO BRACKET
337
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
338
NUT , Replaced By: N913004006001
338
NUT PUMP TO BRACKET
341
CLAMP , Replaced By: A3604300143
341
CLAMP , Replaced By: N916016008200
341
CLAMP ,K 147121, Replaced By: N000000000319
342
SCREW COVER PLATE TO BRACKET
342
SCREW CONNECTOR
343
NUT , Replaced By: N913004006001
343
NUT PUMP TO BRACKET
344
TUBE. BUSHING CAB FLOOR COVERING
450
BRACKET COMPRESSED AIR LINE TO FOUR-CIRCUIT PROTECTIVE VALVE,5 720506
451
BRACKET LINE MOUNTING
452
SCREW , Replaced By: N304017008021
452
SCREW PIPE CLAMP
453
NUT , Replaced By: N913004008001
453
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
455
CLAMP , Replaced By: N916016008200
455
CLAMP ,K 147121, Replaced By: N000000000319
456
SCREW , Replaced By: N000000001146
456
SCREW CLAMP MOUNTING M 6X16
457
NUT , Replaced By: N913004006001
457
NUT PUMP TO BRACKET
458
TUBE. BUSHING CAB FLOOR COVERING
459
CLAMP , Replaced By: A3604300143
459
CLAMP , Replaced By: N916016008200
459
CLAMP ,K 147121, Replaced By: N000000000319
460
SCREW CONNECTOR
460
SCREW , Replaced By: N304017008034
460
SCREW BRACKET TO CROSS CONNECTION STRUT
461
SCREW COVER PLATE TO BRACKET
462
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
463
NUT , Replaced By: N913004006001
463
NUT PUMP TO BRACKET
464
NUT , Replaced By: N913004008001
464
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
478
LINE FROM TEST CONNECTION TO LEFT FRONT WHEEL BRAKE HOSE 1400 MM
480
LINE FROM TEST CONNECTION TO RIGHT WHEEL CYLINDER 700 MM,4 644237
999
HOLLOW SCREW , Replaced By: N915036012101
999
HOLLOW SCREW , Replaced By: N915036010100
999
NUT , Replaced By: N910113010000
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
NUT STRAP TO BRACKET
999
NUT SPARE WHEEL CARRIER TO SIDE MEMBER
999
SCREW BRACKET TO SIDE MEMBER
999
SCREW LICENSE PLATE TO BRACKET
999
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
999
FITTING , Replaced By: A0009905070
999
FITTING , Replaced By: A0009907771
999
FITTING , Replaced By: A0019972372
999
FITTING , Replaced By: A0029971172
999
NUT CHECK VALVE TO AIR RESERVOIR
999
ELBOW FITTING CHECK VALVE TO AIR RESERVOIR
999
GREASE NIPPLE PROTECTIVE TUBE
999
SEAL RING LINE CONNECTION
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
FITTING , Replaced By: A0019909871
999
NUT , Replaced By: N308673016001
999
NUT L.H. THREAD
999
SCREW HAND PUMP TO BRACKET
999
SCREW , Replaced By: N304017010002
999
SCREW END PIECE TO EXHAUST PIPE M 10X25
999
SCREW , Replaced By: N304017006020
999
EXPANSION PLUG
999
WASHER BEARING BRACKET TO CROSS MEMBER,4 225365
999
WASHER BUMPER BRACKET TO COUPLING MOUTH
999
ADHESIVE FOIL GUIDE SIGN
999
CLAMP LINE MOUNTING
999
CONSOLE , Replaced By: A3164300111
999
BRACKET , Replaced By: A3604292940
999
BRACKET , Replaced By: A3604292940
999
SCREW , Replaced By: N900170012001, +001N913001012000
999
BALL CUP BRAKE INTERMEDIATE SHAFT BEARING
999
BRACKET , Replaced By: A3184280240
999
BRACKET , Replaced By: A3464296040
999
SEAL RING
999
SEAL HOLDER
999
CONSOLE , Replaced By: A3224320215, +002N913004012000
999
SHIM RESERVOIR
999
SPRING (RELEASE SPRING)
999
BRACKET ,4 373946
999
BRACKET , Replaced By: A3812710540
999
BRACKET BRAKE BOOSTER,4 282708
999
BRACKET ,4 282708 051,052,053,054,065,066,067,070,072 UP TO CHASSIS 4 383113,056,057,058,059,090,092 UP TO CHASSIS 4 373946 EXCEPT FOR 4 365508, 4 367796,4 368182,4 368578,4 368976,4 369331, Replaced By: A3184313940, +001A3184314040
999
CONSOLE , Replaced By: A3604301311, +001A3604300040
999
BRACKET MASTER CYLINDER TO BRAKE BOOSTER,4 373946
999
BRACKET BRAKE LEVER ASSEMBLY TO FIRE WALL,4 373946
999
BRACKET CONSOLE TO FRAME SIDE MEMBER,4 373946
999
ANGLE , Replaced By: A4220980239
999
BEARING BRACKET BRAKE INTERMEDIATE SHAFT,4 819869
999
REPAIR KIT , Replaced By: A3164201138
999
REPAIR KIT , Replaced By: A3164201038
999
THRUST SHACKLE , Replaced By: A3164230144
999
PROTECTIVE CAP , Replaced By: A0004210887
999
RETAINER , Replaced By: A3164210277
999
PIVOT PIN , Replaced By: A3164200082
999
ADJUSTER , Replaced By: A3165860142
999
BRAKE SHOE , Replaced By: A3164200519, +001A3164211610, +001A3184210288, +010N007338008310
999
ADJUSTER , Replaced By: A3165860042
999
BRAKE SHOE , Replaced By: A3164200519, +001A3164211510, +001A3184210288, +010N007338008310
999
ADJUSTER , Replaced By: A3164200938, +002A3164210277, +002N000934010014, +002N007976010002
999
BRAKE SHOE , Replaced By: A3164200519, +001A3164211410, +001A3184210288, +010N007338008310
999
ADJUSTER , Replaced By: A3164200838, +002A3164210277, +002N000934010014, +002N007967010002
999
BRAKE SHOE , Replaced By: A3164200619
999
BRAKE SHOE ,1 598538, Replaced By: A3164200619, +001A3184210288
999
BRAKE SHOE , Replaced By: A3164200619, +001A3184210288
999
BLEEDER VALVE , Replaced By: A0004310265
999
SPRING ,556500 ALSO INSTALLED ON 553210,556146
999
REPAIR KIT , Replaced By: A3144200267
999
BRACKET ,4 282707
999
BRACKET
999
BEARING BRACKET BRAKE INTERMEDIATE SHAFT,4 819868
999
BEARING BRACKET , Replaced By: A3144201978
999
BUSHING
999
SPACER WASHER2.0 MM, 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
999
BRACKET , Replaced By: A6205244040
999
SEAL RINGTO 000 431 21 14,BOSCH, WITH BOSCH CHARACTERISTIC NUMBER 723
999
WHEEL BRAKE CYLINDER , WITH OFFSET BLEEDER CONNECTION WITH 8-MM,OR 10-MM,MOUNTING SCREWS EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 847617, Replaced By: A0044206818
999
CHAIN LOCK LINKTO 001 431 09 14,4 282708
999
SEAL RINGTO 000 429 28 95,GRAU
999
SEAL RING22.3X2.4 MM,GRAU
999
SEAL RINGTO 000 431 77 14,KNORR
999
SEAL RING , Replaced By: A0179974148
999
FITTING , Replaced By: A0029906171
999
SEAL RINGTO 000 431 24 14
999
WHEEL BRAKE CYLINDER , WITH 8-MM,OR 10-MM,MOUNTING SCREWS, Replaced By: A0074202018
999
BRAKE MASTER CYLINDER , Replaced By: A0034309401
999
REPAIR KITTO 001 430 56 81,001 430 57 81
999
VALVE. REPAIR KIT HAND BRAKE LEVER TO 001 430 65 81
999
BRAKE MASTER CYLINDER ,4 2827078 000001-8 001702
999
REPAIR KITTO 001 431 65 14,000 431 24 14
999
LOOM TIE ,4 809255
999
SEAL RING
999
REPAIR KIT , Replaced By: A0034303181
999
REPAIR KITTO BOSCH
999
REPAIR KIT , Replaced By: A0004301109
999
REPAIR KIT , Replaced By: A0004201071
999
REPAIR KITTO 000 431 13 16,4 2827084 383113 EXCEPT FOR 4 366280,4 366695,4 367047.
999
REPAIR KITKNORR
999
REPAIR KIT , Replaced By: A0035860143
999
REPAIR KITTO 000 431 56 14,001 431 13 14,WABCO
999
REPAIR KIT , Replaced By: A0004302108
999
PRESSURE REGULATORBOSCH
999
PRESSURE REGULATOR , Replaced By: A0024314306
999
VALVE , Replaced By: A0024319306
999
BRAKE BOOSTER ASSEMBLY , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 847617, Replaced By: A0014318614
999
VALVE , Replaced By: A0034295344
999
REPAIR KIT , Replaced By: A0004301407
999
REPAIR KIT , Replaced By: A0004301107
999
REPAIR KIT , Replaced By: A0034201724
999
REPAIR KIT , Replaced By: A0025861443
999
REPAIR KIT WHEEL CYLINDER SCHAEFER, FROM REAR AXLE K 029 515,EXCEPT FOR K 029 516,K 029 517 LESS THRUST PIN,USE 000 423 10 88 THRUST PIN
999
REPAIR KITTO 001 429 20 44,BOSCH
999
VALVE , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0024312906
999
BRAKE CYLINDER , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 847617, Replaced By: A0014318614
999
PRESSURE REGULATOR , Replaced By: A0024316006
999
PRESSURE REGULATOR , EXHAUST STOCK OF OLD PARTS FROM CHASSIS 4 208908-5 148812, Replaced By: A0024315906
999
PRESSURE REGULATORWABCO
999
VALVE , Replaced By: A0024310406
999
VALVE , Replaced By: A0014318406
999
PRESSURE REGULATOR ,5 148812, Replaced By: A0024314306
999
PRESSURE REGULATOR"WABCO",486597
999
GASKET , Replaced By: A0004311980
999
SEAL RING86X2 MM,GRAU
999
SEAL RING28X2 MM,GRAU
999
PRESSURE REGULATOR , Replaced By: A0024314906
999
SEAL RINGTO 000 431 77 14,KNORR,4 415092
999
PROTECTIVE CAPTO BOSCH
999
BRAKE CYLINDER , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 847617, Replaced By: A0014318614
999
BRAKE CYLINDER , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 847617, Replaced By: A0014318614
999
PROTECTIVE CAPTO WABCO
999
CUP , Replaced By: A0004312786
999
PRESSURE REGULATOR , Replaced By: A0024313406
999
PRESSURE REGULATOR , Replaced By: A0024314906
999
VALVE PARKING BRAKE KNORR
999
VALVE , Replaced By: A0024300381
999
VALVE , Replaced By: A0014306581
999
VALVE , Replaced By: A0034291644
999
PLUG
999
HANDLETO 001 430 08 81,BOSCH
