Поз.
Артикул
Описание
10
SHIFT LEVER
10
SHIFT LEVER , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 481833, Replaced By: A3182601939
10
SHIFT LEVER
15
BOOT SHIFT LEVER UPPER PART
16
BOOT SHIFT LEVER LOWER PART
22
HANDLE (GEARSHIFT LEVER KNOB)
28
NUT SHIFT LEVER HANDLE TO SHIFT LEVER
40
SHIFT CASE 3RD AND 4TH SPEED,AND REVERSE
44
BUSHING SHIFTING ROD
48
BUSHING SHIFTING ROD
53
BEARING LOWER PART
57
GROOVED PIN
62
STUD
67
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
70
NUT
75
BRACKET SHIFT CASE
75
BRACKET SHIFT CASE
80
SLIDE SHIFT CASE
84
SPRING SHIFT CASE
88
BEARING UPPER PART
92
COVER ADDITIONAL CLUSTER GEARBOX GV80
96
BOOT
100
SHIFTING ROD SHIFT CASE,4 479472
102
SHIFTING ROD FROM SHIFT CASE TO TRANSMISSION,4 479473
102
SHIFTING ROD FROM SHIFT CASE TO TRANSMISSION,4 479473
105
BUSHING SHIFT CASE
109
BOOT SHIFT CASE
114
SNAP RING , NOT USED
118
SNAP RING SHIFT CASE
120
SHIFTING ROD ,4 479473
121
SCREW BRACKET TO FRAME SIDE MEMBER
122
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
123
CLAMPING PIECE SHIFTING TUBE TO TRANSMISSION
127
SCREW , Replaced By: N304017010047
127
SCREW CONNECTOR TO REAR SHIFTING ROD
135
SHIFTING ROD REAR,4 479472
135
SHIFTING ROD REAR,4 479472
142
SCREW SHIFTING TUBE TO TRANSMISSION
145
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
148
NUT
999
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
STRAP165 MM, UP TO CHASSIS 772045 EXCEPT FOR:500000-599999 ORDER BY THE METER
999
LOOM TIE HAND PUMP
999
BALL PIVOT
999
SCREW CONNECTOR TO REAR SHIFTING ROD
999
SCREW BRACKET TO BELL HOUSING
999
SCREW STRAP TO BRACKET
999
WASHER RADIATOR TO RUBBER MOUNTING
999
WASHER , Replaced By: N000125010532
999
REPAIR KIT SHIFTING PARTS,949462
999
COVER CAB SEALING
999
SPRING , ONLY USED ON DUMP TRUCK ASSEMBLIES
999
GASKET CONNECTION FLANGE
999
SEAL RING
999
PISTON
999
VALVE
999
GASKET CASE PART I TO CASE PART II
