Поз.
Артикул
Описание
15
GREASE NIPPLE INTERMEDIATE LEVER
20
PROTECTIVE CAP
25
DRIVE FLANGE
30
UNIVERSAL JOINT CROSS , Replaced By: A3854100231
35
BEARING BUSHING
37
NEEDLE , Replaced By: A3189810287
40
EXPANSION PLUG
45
GREASE NIPPLE
50
SNAP RING2.500 MM
55
BALANCING PLATE AS REQUIRED 95 MM
60
CENTERING FLANGE PROPELLER SHAFT BEARING
65
PROTECTIVE CAP
70
NUT FOLLOWER FLANGE TO PROPELLER SHAFT
75
BRACKET INTERMEDIATE SHAFT BEARING
76
SCREW OIL TANK TO BRACKET
77
LOCK WASHER REINFORCEMENT ANGLE TO SIDE MEMBER, 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
78
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
80
RUBBER MOUNTING PROPELLER SHAFT BEARING
85
BALL BEARING PROPELLER SHAFT BEARING
90
BEARING RING , INTERMEDIATE BEARING, BALL BEARING WITH LOCK
105
UNIVERSAL JOINT YOKE , Replaced By: A3414107008
105
UNIVERSAL JOINT YOKE , 005 FROM CHASSIS A 008022,006 FROM CHASSIS A 008012,007 FROM CHASSIS A 008032,011 FROM CHASSIS A 007996,012 FROM CHASSIS A 007 992,014 FROM CHASSIS A 002945 016 FROM CHASSIS A 002940,018 FROM CHASSIS A 003198,021 FROM CHASSIS A 007997
110
GREASE NIPPLE INTERMEDIATE LEVER
120
SEAL RING , PROPELLER SHAFT WITH BOOT
125
SEAL HOLDER , PROPELLER SHAFT WITH BOOT
155
BOOT
155
BOOT
156
WIRE RING , WITH BOOT
157
LOOM TIE
158
LOOM TIE
159
CLAMP , WITH BOOT
160
SCREW , Replaced By: A3539900001
165
LOCK WASHER REINFORCEMENT ANGLE TO SIDE MEMBER, 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
170
NUT , Replaced By: N308673010001
999
GREASE NIPPLE
999
GREASE NIPPLE PROTECTIVE TUBE
999
SCREW INTERMEDIATE PIECE,ADAPTER HOUSING
999
UNIVERSAL JOINT CROSS WITH BUSHINGS, IF REQUIRED,ORDER LOCK RINGS ADDITIONALLY
999
BALL BEARING
999
UNIVERSAL JOINT YOKE , Replaced By: A3024110405
999
UNIVERSAL JOINT YOKE , Replaced By: A3024110405
999
PROPELLER SHAFT TUBE , 005 FROM CHASSIS A 008022,006 FROM CHASSIS A 008012,007 FROM CHASSIS A 008032,011 FROM CHASSIS A 007996,012 FROM CHASSIS A 007 992,014 FROM CHASSIS A 002945 016 FROM CHASSIS A 002940,018 FROM CHASSIS A 003198,021 FROM CHASSIS A 007997 NOT BALANCED
999
PROPELLER SHAFT TUBE , NOT BALANCEDNO. A 069204
999
PROPELLER SHAFT FROM INTERMEDIATE BEARING TO REAR AXLE 1790 MM,NO. A 069204
999
PROPELLER SHAFT TUBE , 005 UP TO CHASSIS A 008021,006 UP TO CHASSIS A 008011,007 UP TO CHASSIS A 008031,011 UP TO CHASSIS A 007995,012 UP TO CHASSIS A 007991,014 UP TO CHASSIS A 002944 016 UP TO CHASSIS A 002939,018 UP TO CHASSIS A 003197,021 UP TO CHASSIS A 007996 NOT BALANCED
999
PROPELLER SHAFTL2041 MM, 005 FROM CHASSIS A 008022,006 FROM CHASSIS A 008012,007 FROM CHASSIS A 008032,011 FROM CHASSIS A 007996,012 FROM CHASSIS A 007 992,014 FROM CHASSIS A 002945 016 FROM CHASSIS A 002940,018 FROM CHASSIS A 003198,021 FROM CHASSIS A 007997
999
PROPELLER SHAFT TUBE , 005 UP TO CHASSIS A 008021,006 UP TO CHASSIS A 008011,007 UP TO CHASSIS A 008031,011 UP TO CHASSIS A 007995,012 UP TO CHASSIS A 007991,014 UP TO CHASSIS A 002944 016 UP TO CHASSIS A 002939,018 UP TO CHASSIS A 003197,021 UP TO CHASSIS A 007996 NOT BALANCED
999
UNIVERSAL JOINT YOKE , Replaced By: A3414107008
999
PROPELLER SHAFT , 005 UP TO CHASSIS A 008021,006 UP TO CHASSIS A 008011,007 UP TO CHASSIS A 008031,011 UP TO CHASSIS A 007995,012 UP TO CHASSIS A 007991,014 UP TO CHASSIS A 002944 016 UP TO CHASSIS A 002939,018 UP TO CHASSIS A 003197,021 UP TO CHASSIS A 007996
999
UNIVERSAL JOINT YOKE , Replaced By: A3414107008
999
BRACKET , Replaced By: A3224100540
999
BOOT , Replaced By: A3144100080
999
BALANCING PLATE AS REQUIRED 20 MM
999
PROPELLER SHAFT , 005 UP TO CHASSIS A 008021,006 UP TO CHASSIS A 008011,007 UP TO CHASSIS A 008031,011 UP TO CHASSIS A 007995,012 UP TO CHASSIS A 007991,014 UP TO CHASSIS A 002944 016 UP TO CHASSIS A 002939,018 UP TO CHASSIS A 003197,021 UP TO CHASSIS A 007996
999
BEARING BUSHING , Replaced By: A3224100542
999
BALL BEARING , Replaced By: A3524100051
999
BOOT , Replaced By: A3524100080
999
SNAP RING2.750 MM
999
SNAP RING2.550 MM
999
SNAP RING2.700 MM
999
SNAP RING2.650 MM
999
SNAP RING2.600 MM
999
SEAL HOLDER
999
SEAL RING
999
BALANCING PLATE AS REQUIRED 60 MM
999
UNIVERSAL JOINT CROSS , Replaced By: A0414100031
999
BALANCING PLATE AS REQUIRED 190 MM
999
BALANCING PLATE AS REQUIRED 160 MM
999
DRIVE FLANGE , 005 UP TO CHASSIS A 008021,006 UP TO CHASSIS A 008011,007 UP TO CHASSIS A 008031,011 UP TO CHASSIS A 007995,012 UP TO CHASSIS A 007991,014 UP TO CHASSIS A 002944 016 UP TO CHASSIS A 002939,018 UP TO CHASSIS A 003197,021 UP TO CHASSIS A 007996
999
PROPELLER SHAFT TUBE , Replaced By: A3414101927
999
PROPELLER SHAFT TUBE , Replaced By: A3414101227
999
BALL BEARING , Replaced By: A3524100051
999
BEARING BUSHING , 005 UP TO CHASSIS A 008021,006 UP TO CHASSIS A 008011,007 UP TO CHASSIS A 008031,011 UP TO CHASSIS A 007995,012 UP TO CHASSIS A 007991,014 UP TO CHASSIS A 002944 016 UP TO CHASSIS A 002939,018 UP TO CHASSIS A 003197,021 UP TO CHASSIS A 007996
999
UNIVERSAL JOINT YOKE
999
END PIECE
999
UNIVERSAL JOINT CROSS , Replaced By: A3024100031
999
NEEDLE , Replaced By: A0009815087
