Поз.
Артикул
Описание
133
LINE FROM BRAKE MASTER CYLINDER TO LEFT FRONT WHEEL, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS 588185
134
LINE , USED WITH HYDRAULIC BRAKE,UP TO CHASSIS 588185
134
LINE , Replaced By: A3454203528
135
LINE FROM BRAKE MASTER CYLINDER TO RIGHT FRONT WHEEL, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS 588185
135
LINE , Replaced By: A3454203628
136
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
136
UNION SCREW , Replaced By: A0004280072
137
CONNECTOR OIL DELIVERY LINE
137
CONNECTOR
138
HOSE
138
HOSE , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
139
CLAMP LINE TO HOSE
139
LOOM TIE
140
SCREW VALVE TO STEERING LOCK
141
NUT MODULE TO HOUSING
142
BRACKET BRACKET TO FENDER BRACKET
142
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT, TO BE ADAPTED DURING ASSEMBLY
143
SCREW , Replaced By: N304017010040
144
LOCK WASHER , Replaced By: N912004010102
145
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
146
CLAMP , Replaced By: N916016006201
146
CLAMP SENSOR CABLE TO FRONT AXLE
146
CLAMP COMPRESSED AIR LINE TO COMPRESSED AIR LINE
147
SCREW CABLE TO ALTERNATOR
148
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
149
NUT
180
BRAKE HOSE
180
BRAKE HOSE
182
BRACKET. LOCK , Replaced By: A6525040038
183
BRACKET ,A 009531
184
SCREW CLUTCH TO FLYWHEEL M8X18,4 188090-4 277323
185
LOCK WASHER RAIL TO BATTERY SUPPORT
186
NUT LEVER TO SHIFTING SHAFT
188
LINE , Replaced By: A3454203828
188
LINE FROM MASTER CYLINDER TO REAR AXLE, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS 588185
189
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
189
UNION SCREW , Replaced By: A0004280072
198
BRACKET , Replaced By: A3184280240
200
SCREW BRACKET TO INTAKE MANIFOLD
202
LOCK WASHER RAIL TO BATTERY SUPPORT
203
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
203
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
204
CLAMP COMPRESSED AIR LINE TO COMPRESSED AIR LINE
204
CLAMP , Replaced By: N916016006201
204
CLAMP SENSOR CABLE TO FRONT AXLE
207
SCREW CABLE TO ALTERNATOR
207
SCREW CABLE TO ALTERNATOR
208
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
210
NUT PUMP TO BRACKET
211
BRACKET LINE MOUNTING
212
CLAMP COMPRESSED AIR LINE MOUNTING
213
SCREW COMPRESSED AIR LINE MOUNTING
214
LOCK WASHER PLUG SOCKET
215
NUT TACHOGRAPH TO BRACKET
216
BRAKE HOSE , Replaced By: A0024280735
216
BRAKE HOSE , Replaced By: A0024280735
225
BRACKET. LOCK , Replaced By: A6525040038
226
BRACKET , THE OLD PART MUST NO LONGER BE INSJTALLED, Replaced By: A3834280140
227
SCREW BRACKET TO INTAKE MANIFOLD
228
LOCK WASHER RAIL TO BATTERY SUPPORT
229
NUT LEVER TO SHIFTING SHAFT
230
DISTRIBUTOR REAR AXLE
230
VERTEILERSTUCK. DISTRIBUTOR REAR AXLE,4 478330
231
SCREW POWER CYLINDER TO BEARING BRACKET
232
LOCK WASHER RAIL TO BATTERY SUPPORT
237
LINE , Replaced By: A3454204228
237
LINE FROM DISTRIBUTOR TO LEFT REAR WHEEL
238
LINE , Replaced By: A3454204328
238
LINE FROM DISTRIBUTOR TO WHEEL CYLINDER 6X0.7 MM
239
UNION SCREW , Replaced By: A0004280072
239
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
240
HOSE BRAKE LINE TO REAR AXLE,4 644238
241
CLAMP BRAKE LINE MOUNTING
242
LOCK WASHER RAIL TO BATTERY SUPPORT
243
SCREW BRACKET TO DISC WHEEL M 8X16,D 315831
999
CLAMP , Replaced By: N916017011001
999
THRUST RING BUTT SCREW CONNECTION
999
SLEEVE LINE CONNECTION
999
BANJO UNION HOSE WIDTH, / I.D., 6/14 MM
999
SEAL RING , Replaced By: N007603012121
999
HOLLOW SCREW
999
UNION NUT BUTT SCREW CONNECTION
999
UNION NUT LINE CONNECTION, Replaced By: N000000006239
999
UNION NUT LINE CONNECTION
999
UNION NUT
999
NUT BRACKET TO SIDE MEMBER,XB209706
999
LOCK WASHERROCKINGER TYP 59 G140,59 G150
999
HOSE CLAMP. CLAMP COMPRESSED AIR HOSE TO COMPRESSED AIR LINE
999
NUT ELECTRONIC ACCELERATOR PEDAL
999
NUT CHECK VALVE TO AIR RESERVOIR
999
GREASE NIPPLE PROTECTIVE TUBE
999
GREASE NIPPLE INTERMEDIATE LEVER
999
INSULATING HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
999
INSULATING HOSE
999
INSULATING HOSE COMPRESSED AIR HOSE 8X0.7 MM
999
SEAL RINGTO 002 430 41 01,27 01,045 430 00 01
999
SEAL RING LINE CONNECTION
999
SEAL RINGTO 006 997 00 72
999
SEALING RING. SEAL RING ENGINE BREATHING
999
TOOTHED WASHER LINE CONNECTION TO FIRE WALL,684146
999
CONNECTION FITTING ,880809
999
GLAND LINE CONNECTION
999
GLAND , Replaced By: A0019901967
999
GLAND LINE CONNECTION
999
TURNBUCKLE , Replaced By: A3859960034
999
SCREW REAR CROSS MEMBER AND GUSSET PLATES TO SIDE MEMBERS M 12X30
999
SCREW ENGINE TO ENGINE FRONT SUPPORT
999
NUT LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
999
NUT , Replaced By: N000936012005
999
NUT , Replaced By: N308675012000
999
NUT PULL ROD
999
NUT SPRING BOLT
999
HEX. NUT. NUT FUEL TANK TO CONSOLE,167609
999
SCREW , Replaced By: N304017010002
999
SCREW CLAMP TO BRACKET
999
SCREW STRAP TO BRACKET
999
LOCK RING
999
LOCK RING
999
LOCK RING SHACKLE TO BEARING BRACKET,965965
999
EXPANSION PLUG
999
NUT ,100570
999
SPRING WASHER CAB FLOOR
999
LOCK WASHER SUPPORT TO SIDE MEMBER
999
LOCK WASHER PROPELLER SHAFT TO REAR AXLES I AND II
999
WASHER
999
WASHER SUPPORT TO FRAME,D 127794
999
WASHER GROUND CABLE
999
WASHER TRAILER PLUG SOCKET TO BRACKET
999
WASHER PLUG SOCKET TO BRACKET
999
WASHER LINE MOUNTING,HB746632684146
999
COTTER PIN STRAP TO SUPPORT
999
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
999
REPAIR KIT , Replaced By: A0004205555
999
CUPTO 000 431 34 14
999
SPRINGTO 000 431 34 14
999
SPRINGTO 345 431 72 14
999
SPRING , Replaced By: A0014316493
999
RODTO 000 431 34 14
999
CUPTO 000 431 34 14
999
ROD , Replaced By: A0004312892
999
SPRING RETAINER , Replaced By: A3454317189
999
PROTECTIVE CAP , Replaced By: A0004301808
999
CUP , Replaced By: A0004318083
999
PISTONTO 345 431 72 14
999
SEAL RING , Replaced By: A0049978045
999
SPACER WASHER , Replaced By: A0049978045
999
FILTER BOTTOMTO 345 431 72 14
999
COVER , Replaced By: A0004312892
999
AIR CLEANER , Replaced By: A0004313934
999
EXPANSION PLUG BRAKE SHAFT TO BEARING BRACKET
999
BRAKE LINING REPAIR SIZE II 17.7 MM, NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT FOR THE NEW PART NO.,SEE STANDARD VERSION
999
BRAKE LINING REPAIR SIZE I 16.7 MM, NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT FOR THE NEW PART NO.,SEE STANDARD VERSION
999
STOP WASHER BRAKE SHAFT TO BEARING BRACKET
999
BRAKE LINING STANDARD 15.7 MM, NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT FOR THE NEW PART NO.,SEE STANDARD VERSION
999
BRAKE LINING , Replaced By: A3454217210
999
BRAKE LINING , Replaced By: A3454217110
999
BRAKE LINING , Replaced By: A3454217010
999
BRAKE SHOE , FOR THE NEW PART NO.,SEE STANDARD VERSION
999
BRAKE SHOE , Replaced By: A3024202019, +002A3604212410, +016A3079900197
999
BRAKE SHOE , Replaced By: A3024202119, +002A3604231310, +016A3079900197
999
ROD FROM BRAKE SHAFT TO BRAKE LEVER
999
ROD FROM BRAKE SHAFT TO BRAKE LEVER
999
BEARING BRACKET , Replaced By: A3454207178
999
SCREW
999
FITTING LINE CONNECTION TO FIRE WALL,684146
999
BRACKET HAND BRAKE VALVE
999
LOOM TIE. CLAMP COMPRESSED AIR LINE TO BRAKE CYLINDER
999
LOOM TIE , Replaced By: A3459978890
999
SEAL RING
999
WASHERTO 344 430 73 01,002 430 27 01
999
CUPTO 344 430 73 01,002 430 27 01
999
SPRING RETAINERTO 345 431 72 14
999
WASHERTO 002 430 71 01
999
T-FITTING ,627034
999
DISTRIBUTOR MASTER CYLINDER TO BRAKE VALVE,548520, 031,032,033,034
999
HOLLOW SCREW DISTRIBUTOR TO MASTER CYLINDER
999
DISTRIBUTOR BRAKE MASTER CYLINDER TO 344 430 78 01, 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
999
BRAKE LINING REPAIR SIZE II 17.70 MM,FRAS-LE, UP TO REAR AXLE 111016 FROM REAR AXLE SEE SPARE PARTS LIST 816
999
BRAKE LINING REPAIR SIZE I 16.70 MM,FRAS-LE, UP TO REAR AXLE 111016 FROM REAR AXLE SEE SPARE PARTS LIST 816
999
BRAKE LINING STANDARD 15.70 MM,FRAS-LE, UP TO REAR AXLE 111016 FROM REAR AXLE SEE SPARE PARTS LIST 816
999
BRAKE LINING REPAIR SIZE II 17.50 MM,LONAFLEX, UP TO REAR AXLE 111016 FROM REAR AXLE SEE SPARE PARTS LIST 816
999
BRAKE LINING REPAIR SIZE I 16.50 MM,LONAFLEX, UP TO REAR AXLE 111016 FROM REAR AXLE SEE SPARE PARTS LIST 816
999
BRAKE LINING STANDARD 15.50 MM,LONAFLEX, UP TO REAR AXLE 11016,FROM REAR AXLE SEE SPARE PARTS LIST 816
999
BRAKE LINING REPAIR SIZE II 17.70 MM,FRAS-LE, UP TO FRONT AXLE 2219487,FROM FRONT AXLE 2219488 SEE SPARE PARTS LIST 732.7
999
BRAKE LINING REPAIR SIZE I 16.70 MM,FRAS-LE, FROM UP TO FRONT AXLE 2219487, FROM FRONT AXLE 2219488 SEE SPARE PARTS LIST 815
999
BRAKE LINING STANDARD 15.70 MM,FRAS-LE, FROM UP TO FRONT AXLE 2219487, FROM FRONT AXLE 2219488 SEE SPARE PARTS LIST 815
999
BRAKE LINING REPAIR SIZE II 17.5 MM
999
BRAKE LINING REPAIR SIZE I 16.5 MM
999
BRAKE LINING STANDARD 15.50 MM LONALFEX, FROM UP TO FRONT AXLE 2219487, FROM FRONT AXLE 2219488 SEE SPARE PARTS LIST 815
999
BRAKE SHOELONAFLEX
999
BEARING BRACKET
999
BRAKE SHOE , Replaced By: A3024202119, +001A3644230310
999
LINE FROM T-FITTING TO RELAY VALVE 15X1,5 MM, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS 588185
999
SEAL RING ,100570
999
CLAMP
999
SWITCH RELAY VALVE,CONNECTION "2",RIGHT
999
ELBOW FITTING , Replaced By: A3454307779
999
CUP
999
CLAMP COMPRESSED AIR LINE TO BRACKET
999
SEAL RING
