Поз.
Артикул
Описание
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
ELECTRICAL WIRING HARNESS . , BM375.850, WHEN ORDERING, SPECIFY THE VARIANT NUMBER XVK.. ...... FROM VEDOC STATE IDENT NO. WHEN ORDERING
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
8
RECEPTACLE HOUSING. PIN BUSHING HOUSING21 PIN
8
RECEPTACLE HOUSING. PIN BUSHING HOUSING 18-POLE,GREY X1,X2,X3, ST1,ST2, INEVENT OF REPAIR, REPLACE CONNECTOR COMPLETELY
11
CONTACT BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 1.0-2.5 MM2
11
CONTACT BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 0.5-1.0 MM2
14
PLUG HOUSING PLUG CONNECTION,WIRING HARNESS FOR DRIVER + CO-DRIV. DOOR/INSTR. SUPPORT X22,X23, 18PIN
14
PLUG HOUSING PLUG CONNECTION,WIRING HARNESS FOR ROOF/INSTRUMENT SUPPORT X124, X125, 21 PIN
17
FLAT PLUG LESS DETENT,BUT WITH CATCH FOR HOUSING 0.5-1.0 MM2
17
FLAT PLUG LESS DETENT,BUT WITH CATCH FOR HOUSING 1.0-2.5 MM2
20
RECEPTACLE HOUSING. PIN BUSHING HOUSING LIGHT SWITCH 15 PIN
20
PIN BUSHING HOUSING AUTSIDE REARVIEW MIRROR ADJUSTMENT SWITCH 12 PIN, INEVENT OF REPAIR, REPLACE CONNECTOR COMPLETELY
20
RECEPTACLE HOUSING. PIN BUSHING HOUSING 18-POLE,GREY X1,X2,X3, ST1,ST2, INEVENT OF REPAIR, REPLACE CONNECTOR COMPLETELY
23
CONTACT BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 1.0-2.5 MM2
23
CONTACT BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 0.5-1.0 MM2
26
PLUG HOUSING STEERING COLUMN MOUNTED SWITCH 15 PIN
26
PLUG HOUSING PLUG CONNECTION,WIRING HARNESS FOR DRIVER + CO-DRIV. DOOR/INSTR. SUPPORT X22,X23, 18PIN
26
PLUG HOUSING PLUG CONNECTION,WIRING HARNESS FOR DRIVER + CO-DRIV. DOOR/INSTR. SUPPORT X22,X23, 12PIN
29
FLAT PLUG LESS DETENT,BUT WITH CATCH FOR HOUSING 1.0-2.5 MM2
29
FLAT PLUG LESS DETENT,BUT WITH CATCH FOR HOUSING 0.5-1.0 MM2
44
PIN BUSHING HOUSING VOLTAGE TRANSFORMER 6 PIN
45
PIN BUSHING HOUSING VOLTAGE TRANSFORMER 6 PIN
53
CONTACT BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 0.5-1.0 MM2
53
CONTACT BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 1.0-2.5 MM2
56
PLUG HOUSING 14-POLE
59
CLAMPING RING DIAGNOSIS PLUG SOCKET
59
CONTACT SPRING LESS DETENT,BUT WITH CATCH FOR HOUSING 1.0-2.5 MM2
59
CAP DIAGNOSIS PLUG SOCKET
59
ROUND PIN BUSHING
60
PLUG SOCKET DIAGNOSIS BOX X13, 16PIN
61
CONTACT SPRING LESS DETENT,BUT WITH CATCH FOR HOUSING 0.5-1.0 MM2
62
PIN BUSHING HOUSING BIPOLAR
65
PIN BUSHING HOUSING UNIPOLAR
71
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 0.5-1.0 MM2
71
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2.5 MM2
71
FEMALE DISCONNECT WITH DETENT AND WITH CATCH FOR HOUSING 2.5-4.0 MM2
71
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 4-6 MM2
71
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2.5-4.0 MM2, Replaced By: A0009827926
74
PARTS KIT PLUG CONNECTION,TACHOGRAPH SENSOR X36, 4PIN, TO BE ADAPTED DURING ASSEMBLY
77
PLUG HOUSING 4-POLE
80
CORE BUNDLE SEALING1.0-2.5 MM2
80
NUT. CLAMPING RING
80
GASKET. BLIND PLUG
80
CONTACT PIN0.5-1.0 MM2
80
CONTACT PIN1.0-2.5 MM2
80
WIRE SEAL GREY 0.5-1.0 MM2
83
BOOT 180 DEGREE OUTLET WITH VARIABLE CLAMPING
86
PLUG HOUSING PLUG CONNECTION,MIRRORS ON DRIVERS AND CO-DRIVERS DOORS X24,X25, 6PIN
87
PLUG HOUSING CONNECTOR, UNDERCARRIAGE/WAISTRAIL WIRING HARNESS X86, X118, 9 PIN
89
FLAT PLUG LESS DETENT,BUT WITH CATCH FOR HOUSING 1.0-2.5 MM2
89
FLAT PLUG LESS DETENT,BUT WITH CATCH FOR HOUSING 0.5-1.0 MM2
102
PLUG SOCKET TOLL CONTROL UNIT PREINSTALLATION 8 PIN, TOLL COLLECT, X157
103
BUSHING CONTACT TOLL CONTROL UNIT PREINSTALLATION 0.75 - 1.0 MM2
104
PLUG HOUSING CONNECTOR, UNDERCARRIAGE/WAISTRAIL WIRING HARNESS X86, X118, 9 PIN
105
FLAT PLUG LESS DETENT,BUT WITH CATCH FOR HOUSING 0.5-1.0 MM2
105
FLAT PLUG LESS DETENT,BUT WITH CATCH FOR HOUSING 1.0-2.5 MM2
128
CABLE HARNESS SHIFT AID
128
CABLE HARNESS SHIFT AID X93 -B88/B89
195
ELECTRIC CABLE ADAPTER LINE FOR TOLL COLLECT
210
ELECTRIC CABLE STOP LAMP AND CLUTCH SWITCH GLOBAL COCKPIT EPB2, X208 - S4/S85/S89
215
PIN BUSHING HOUSING9 PIN
220
CONTACT BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 0.5-1.0 MM2
220
CONTACT BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 1.0-2.5 MM2
225
PIN BUSHING HOUSING PIN BUSHING 5.3 MM
230
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 0.5-1.0 MM2
240
CABLE HARNESS REVOLVING BEAM SIGNAL LAMP, TO BE SELF-PREPARED
240
CABLE HARNESS REVOLVING BEAM SIGNAL LAMP, TO BE SELF-PREPARED
245
PIN BUSHING HOUSING. PLUG HOUSING FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH
250
PLUG FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH 2.5 MM2
255
PIN BUSHING HOUSING PIN BUSHING 5.3 MM
260
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2.5 MM2
265
GROMMET FOGLAMP
