Поз.
Артикул
Описание
5
BRAKE VALVE SERVICE BRAKE WABCO
5
BRAKE VALVE SERVICE BRAKE KNORR
8
LOCK RINGTO 345 431 71 05
8
LOCKTO 345 431 70 05
11
SPRINGTO 345 431 71 05
11
SPRINGTO 345 431 70 05
11
SPRINGTO 345 431 70 05
14
PISTONTO 345 431 71 05
14
PISTONTO 345 431 70 05
17
LOCK RINGTO 345 431 71 05
20
LOCK RING
23
LOCK RING PLANETARY CARRIER
26
REPAIR KIT , Replaced By: A0014300460
26
REPAIR KIT LARGE SCOPE TO 345 431 70 05
26
REPAIR KIT SMALL SCOPE TO 345 431 71 05
26
REPAIR KIT SMALL SCOPE TO 345 431 70 05
29
GASKET BRAKE SHOE WITH LINING
32
NUT BATTERY CASE
35
SPRING WASHER BRAKE SHOE WITH LINING
72
ROD FROM FITTING TO CLUTCH BOOSTER
74
YOKE
77
HEXAGON NUT. NUT BRACKET TO SIDE MEMBER M 12X1,5
80
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
83
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
86
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
89
SWITCH EXHAUST BRAKE,K 251255
89
SWITCH TWO-CIRCUIT BRAKE VALVE
92
SCREW PLUG
95
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
98
VALVE (QUICK BREATHER VALVE) VARGA
101
REPAIR KITTO A 364 429 70 44
104
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
107
SEAL RINGTO 006 997 00 72
110
SCREW PLUG
113
ELBOW FITTING DIAPHRAGM CYLINDER,CONNECTION: "1,11"
116
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
119
THRUST RING LOCKING VALVE
119
THRUST RING LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
119
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
122
NUT LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
125
BRACKET QUICK-RELEASE VALVE
128
BOLT. SCREW QUICK-RELEASE VALVE TO BRACKET
131
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
ROD , Replaced By: A3844207074
