Поз.
Артикул
Описание
5
BRAKE VALVE SERVICE BRAKE KNORR
5
BRAKE VALVE SERVICE BRAKE WABCO
8
LOCKTO 345 431 70 05
11
SPRINGTO 345 431 71 05
11
SPRINGTO 345 431 70 05
11
SPRINGTO 345 431 70 05
14
PISTONTO 345 431 71 05
14
PISTONTO 345 431 70 05
17
LOCK RINGTO 345 431 71 05
17
LOCK RINGTO 345 431 71 05
17
LOCK RING
17
LOCK RING PLANETARY CARRIER
20
REPAIR KIT SMALL SCOPE TO 345 431 70 05
20
REPAIR KIT SMALL SCOPE TO 345 431 71 05
20
REPAIR KIT LARGE SCOPE TO 345 431 70 05
20
REPAIR KIT , Replaced By: A0014300460
23
WASHER TRAILER PLUG SOCKET TO BRACKET
26
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
26
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
30
ROD FROM FITTING TO CLUTCH BOOSTER
32
YOKE
35
NUT FUEL TANK TO SUPPORT
38
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
41
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
44
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
47
SCREW PLUG RELAY VALVE,CONNECTION "20",RIGHT
50
VALVE (CHECK VALVE)
50
VALVE (CHECK VALVE)
50
VALVE (CHECK VALVE)
50
VALVE (CHECK VALVE)
50
VALVE (CHECK VALVE)
50
VALVE (CHECK VALVE)
53
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
56
HOLLOW SCREW LINE CONNECTION TO TRANSMISSION
56
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
59
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
62
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
70
FITTING VALVE TO VALVE
71
VALVE (RELAY VALVE),REAR AXLE
71
VALVE (RELAY VALVE),REAR AXLE
71
VALVE (RELAY VALVE) KNORR
71
VALVE (RELAY VALVE) KNORR
71
VALVE (RELAY VALVE) WABCO
71
VALVE (RELAY VALVE) WABCO
74
REPAIR KITTO 003 429 30 44,KNORR
74
REPAIR KITTO 003 429 30 44,KNORR
74
REPAIR KIT SMALL SCOPE TO 001 429 68 44
74
REPAIR KIT SMALL SCOPE TO 001 429 68 44
74
REPAIR KITWABCO
74
REPAIR KITWABCO
74
REPAIR KITKNORR
74
REPAIR KITKNORR
77
BRACKET (RELAY VALVE)
77
BRACKET (RELAY VALVE)
78
SCREW CROSS MEMBER TO SIDE MEMBERS
79
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
80
WASHER GROUND CABLE
81
WASHER TRAILER PLUG SOCKET TO BRACKET
83
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
83
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
86
BRACKET
89
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
89
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
92
ADAPTER FITTING , Replaced By: A0004296934
95
WASHER COILED TUBE TO BRAKE LINE COUPLING SUPPORT
98
TOOTHED WASHER SENDER UNIT TO BRACKET
101
NUT BRACKET TO SIDE MEMBER
102
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
103
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
104
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
104
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
105
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
105
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
107
T-FITTING FROM CHECK VALVE TO RELAY VALVE
107
T-FITTING FROM CHECK VALVE TO RELAY VALVE
110
NUT CHECK VALVE TO AIR RESERVOIR
110
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
113
THRUST RING LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
113
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
113
THRUST RING LOCKING VALVE
113
THRUST RING CHECK VALVE TO AIR RESERVOIR
113
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
116
O-RING CHECK VALVE TO AIR RESERVOIR
116
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
119
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
122
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
126
SCREW-IN FITTING OIL LINE CONNECTION
128
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
129
SCREW PLUG RELAY VALVE,CONNECTION "20",RIGHT
132
CONNECTOR RELAY VALVE,CONNECTION "2",REAR
134
NUT LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
137
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
140
THRUST RING LOCKING VALVE
140
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
140
THRUST RING LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
143
SWITCH SUPPLY PRESSURE,5 966147
146
SCREW PLUG RELAY VALVE,CONNECTION "20",RIGHT
147
SCREW-IN FITTING OIL LINE CONNECTION
149
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
149
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
152
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
155
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
158
THRUST RING LOCKING VALVE
158
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
158
THRUST RING LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
161
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
164
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
167
SEAL RINGTO 006 997 00 72
999
ROD , Replaced By: A3842927032, +001A3849967001, +001N000934012009
