Поз.
Артикул
Описание
60
SPRING LEFT CUSHION FRAME
110
COVER LEFT CUSHION FRAME, 9116QFT461A3160 BLACK DULL
115
FIXTURE WARNING TRIANGLE,LEFT
117
TAPPING SCREW CONTROL UNIT TO FIRE WALL
120
LOCK. SHEET METAL NUT PLATE TO FRAME,V 202043
120
NUT RETAINER
125
COVER RIGHT SEAT CUSHION
250
BUSHING LEFT REAR BACKREST
260
CLEVIS LEFT REAR BACKREST
290
SPRING LEFT REAR BACKREST
300
PIN LEFT REAR BACKREST
310
SECURING LEFT BACKREST FRAME
330
BACKREST ADJUSTER RIGHT REAR BACKREST LINKE SEITE
330
BACKREST ADJUSTER RIGHT REAR BACKREST
340
SPRING BACKREST ADJUSTER LEFT RECHTE SEITE
340
SPRING BACKREST ADJUSTER RIGHT
350
HEXALOBULAR BOLT CATCH ON BACKREST FRAME, RIGHT M10X25
360
COVER, BACKREST FRAME LEFT BACKREST, 9116QFT463A2118 BLACK DULL
365
COVER, BACKREST FRAME REAR BACKREST, 9116QFT463A2118 BLACK DULL
370
BRACKET SEAT COVER MOUNTING,LONGITUDINAL
370
BRACKET SEAT COVER MOUNTING,LONGITUDINAL
375
TAPPING SCREW CONTROL UNIT TO FIRE WALL
380
CLIP
382
SHEET METAL SCREW AIR BAFFLE TO AIR DUCT 4.2X25
450
EDGE GUARD LEFT BACKREST FRAME
455
HANDLE RIGHT
460
RELEASE HANDLE LEFT BACKREST FRAME, 9051QFT463A2100 BLACK
460
RELEASE HANDLE
465
COVER LEFT CUSHION FRAME
470
COVER COVER TO BACKREST FRAME, LEFT
470
COVER RIGHT BACKREST FRAME
475
COVER LEFT, BETWEEN COVER AND BACKREST FRAME
480
TAPPING SCREW CONTROL UNIT TO FIRE WALL
510
BRACKET REAR SEAT BENCH
520
HEXALOBULAR BOLT CATCH ON BACKREST FRAME, RIGHT M10X25
530
NUT IN CASE OF SUBSEQUENT INSTALLATION
535
SCREW MOUNTING OF INSTRUMENT PANEL
540
WASHER BOOT TO CAB FLOOR
545
NUT IN CASE OF SUBSEQUENT INSTALLATION
550
SENSOR MAT CHILD SEAT RECOGNITION
550
SWITCH CHILD SEAT RECOGNITION, FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. A 76502520130222 L 03261020130228 V 00224420130228, Replaced By: A2128703110
