Поз.
Артикул
Описание
9
LINE AIR COMPRESSOR,PRESSURE REGULATOR, DEHYDRATOR 15X1.5 MM, LENGTH AVAILABLE: 3000 MM
12
CLAMP , Replaced By: A6739950001
12
CLAMP DELIVERY AND SUCTION LINES TO STEERING
18
SCREW CLAMP TO BRACKET, Replaced By: N007985006581
18
SCREW CLAMP TO BRACKET
24
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
24
WASHER COMPRESSED AIR LINE TO BRACKET
30
NUT PUMP TO BRACKET
30
NUT , Replaced By: N913004006001
42
BRACKET BATTERY CABLE MOUNTING,5 193595
48
SCREW , Replaced By: N304017008034
54
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
54
NUT , Replaced By: N913004008001
106
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
109
BANJO UNION BRAKE POWER REGULATOR W/RELAY VALVE, CONNECTION: "40"
112
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
121
LEVER (CONTROL LEVER)
124
LEVER WIRE CABLE TO ENGINE CONTROL LEVER
127
BALL PIVOT , Replaced By: A3129910120
127
BALL PIVOT LEVER
130
SCREW BRACKET ON LOAD SENSOR
133
NUT , Replaced By: N913004006001
133
NUT PUMP TO BRACKET
134
ANGLE LINE MOUNTING
134
BRACKET , Replaced By: A3604280243
135
LOOM TIE LINE MOUNTING
136
LINE , Replaced By: A0004291601
136
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
136
LINE , Replaced By: A0004291601
139
UNION NUT LINE CONNECTION, Replaced By: N000000006243
139
NUT LINE CONNECTION
142
TUBE FROM HIGH PRESSURE HOSE TO STEERING
142
LINE , Replaced By: A0005516156
142
LINE , Replaced By: A0005516156
145
BRACKET DELIVERY AND RETURN LINES,5 529813
148
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
STUD BOLT ENGINE MOUNTING TO CONSOLE M 12X1.5X40
999
STUD BOLT ENGINE MOUNTING TO CONSOLE M 12X1.5X60
999
LINE FROM HOSE TO OIL PUMP,5 416698
999
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
999
BRACKET , Replaced By: A3552711140
999
SHIM CROSS MEMBER TO SUPPORT
999
STRUT FRONT SPRING REAR BRACKET,5 313280
999
CROSS MEMBER FRONT SPRING REAR BRACKET NO.2
999
SUPPORTING ARM REAR
999
SUPPORT , Replaced By: A3962420002
999
CROSS MEMBER TRANSMISSION MOUNTING
999
FLANGE
999
RUBBER MOUNTING REAR
999
RUBBER MOUNTING REAR
999
RUBBER MOUNTING REAR
999
RUBBER MOUNTING FRONT
999
RUBBER MOUNTING FRONT
999
ENGINE SUPPORT RIGHT REAR,4 829648
999
BRACKET , Replaced By: A3875015820
999
LINE , Replaced By: A0004291601
999
STRUT , Replaced By: A3873100353
999
CROSS MEMBER FRONT SPRING REAR BRACKET NO.2
999
SUPPORTING ARM BELL HOUSING,4 753306
999
RUBBER MOUNTING REAR
999
RUBBER MOUNTING REAR
999
RUBBER MOUNTING REAR
999
RUBBER MOUNTING ADJUSTABLE,FRONMT
999
RUBBER MOUNTING
