Поз.
Артикул
Описание
15
FLANGE CONNECTOR
30
HOSE FROM FLANGE TO VALVE
45
CLAMP , Replaced By: N000000000667
45
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
60
VALVE (SOLENOID VALVE),5 232740
75
BRACKET SOLENOID VALVE
90
SCREW BRACKET MOUNTING
105
NUT , Replaced By: N913002004001
105
NUT ATTACHMENT, MARKER LIGHT
120
SCREW CONSOLE TO SIDE MEMBER
120
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
126
WASHER COVER PLATE TO FRAME
126
WASHER BRACKET TO SIDE MEMBER
135
NUT SUPPORT TO SIDE MEMBER
150
HOSE , Replaced By: A6255060335
150
HOSE , FIRST EXHAUST STOCK OF OLD PARTS FROM IDENT NO.5 561857-5 738672, Replaced By: A3095061023
150
HOSE , Replaced By: A3098321023
150
HOSE FROM VALVE TO FEED LINE
165
CLAMP , Replaced By: N000000000667
165
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
180
LINE HEATING PIPE
180
LINE HEATING PIPE
240
ANGLE LINE MOUNTING
255
CLAMP FEED LINE TO THERMOSTAT
270
SCREW , Replaced By: N304017006016
270
SCREW PUMP TO BRACKET
285
NUT , Replaced By: N913004006001
285
NUT PUMP TO BRACKET
315
CLAMP FEED LINE TO THERMOSTAT
330
SCREW COVER PLATE TO BRACKET
345
NUT , Replaced By: N913004006001
345
NUT PUMP TO BRACKET
360
HOSE HEATING, ADDITIONAL WATER PUMP,HEATER UNIT,HEAT EXCHANGER
375
CLAMP , Replaced By: N000000000667
375
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
390
HOSE FROM HEATING LINE TO HEATING LINE
420
LINE (HEATING PIPE)
705
HOSE FROM FLANGE TO HEATING PIPE
735
HOSE FROM EXPANSION TANK TO WATER PUMP
756
HOSE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
765
BRACKET HOSE
780
SCREW , Replaced By: N304017006018
780
SCREW COVER PLATE TO COVER PLATE M 6 X 12
795
WASHER , Replaced By: N009021006208
795
WASHER COMPRESSED AIR LINE TO BRACKET
810
NUT , Replaced By: N913004006001
810
NUT PUMP TO BRACKET
825
SCREW , Replaced By: N308676012012
825
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
825
SCREW , Replaced By: N304017008021
825
SCREW PIPE CLAMP
845
NUT SUPPORT TO SIDE MEMBER
845
NUT , Replaced By: N913004008001
845
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
999
NUT , Replaced By: N910113014001
999
NUT COMBINATION CYLINDER TO BEARING BRACKET
999
NUT BRACKET TO SIDE MEMBER
999
HOSE FROM BUBBLE SEPARATOR TO HEATING PIPE 18X27 MM, ORDER BY THE METER
999
SCREW SHACKLE TO CONSOLE
999
SCREW BRACKET TO SPRING BRACKET AND TO CROSS MEMBER,5 953233K 027550
999
SCREW HAND PUMP TO BRACKET
999
BRACKET HOSE
999
BRACKET , Replaced By: A6205244040
999
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
999
HOSE FROM HEATING PIPE AT ENGINE TO HEATING PIPE AT RADIATOR
999
FLANGE , Replaced By: A6205060261
999
LINE HEATING AND BREATHING
999
LINE HEATING AND BREATHING
999
LINE HEATING AND BREATHING
999
HOSE FROM HEATING LINE TO HEATING LINE
999
LINE HEATING PIPE, NOT USED
999
LINE HEATING AND BREATHING
999
LINE ,5 071491, Replaced By: A6175001072, +001A6175012782, +001A6175060235
999
ANGLE , Replaced By: A3604280243
999
BRACKET HEATING PIPE TO FAN SHROUD BRACKET
