Поз.
Артикул
Описание
384
PIPE ELBOW LEFT
395
HOSE INTAKE PIPE TO AIR CLEANER
395
HOSE FROM AIR CLEANER TO CAB CONSOLE
406
CLAMP , Replaced By: N000000000678
406
CLAMP HOSE TO AIR CLEANER AND CAB CONSOLE 130-150X13 MM, Replaced By: N000000005892
406
CLAMP HOSE TO CAB CONSOLE AND TO ENGINE CONNECTION
417
BRACKET , Replaced By: A6255283140, +001A0019874340
417
BRACKET CLAMP TO PIPE ELBOW
439
SHIM CLAMP TO PIPE ELBOW
450
BRACKET CLAMP TO PIPE ELBOW,RIGHT
450
BRACKET CLAMP TO PIPE ELBOW,LEFT
450
CLAMP , Replaced By: A6255281640, +002N000961012500, +001N071550110052, +002N913004012008
450
CLAMP , Replaced By: A6255281540, +002N000961012500, +001N071555110025, +002N913004012008
461
SCREW , Replaced By: N304017008027
461
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
463
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
474
SCREW PIPE CLAMP
474
SCREW , Replaced By: N304017008021
476
WASHER , Replaced By: N000125008443
476
WASHER EXHAUST MUFFLER TO STRAP
476
WASHER SUPPORTING RAIL TO SUPPORT,5 429712
478
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
478
NUT , Replaced By: N913004008001
478
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
481
CLAMP EXHAUST PIPE
489
SCREW BRACKET TO CROSS CONNECTION STRUT
489
SCREW , Replaced By: N308676012012
489
SCREW , Replaced By: N304017008034
489
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
492
NUT , Replaced By: N913004008001
492
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
492
NUT SUPPORT TO SIDE MEMBER
492
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
503
HOSE FROM AIR INTAKE PIPE TO ENGINE
503
HOSE , Replaced By: A0020944082
506
HOSE CLAMP FROM AIR CLEANER TO TRANSVERSE INTAKE PIPE, Replaced By: A0019951910
506
CLAMP FROM AIR CLEANER TO TRANSVERSE INTAKE PIPE, TO BE ADAPTED DURING ASSEMBLY
999
BRACKET CLAMP TO PIPE ELBOW,RIGHT
