Поз.
Артикул
Описание
5
ACCELERATOR PEDAL
11
JOINT ,B 859430
14
CLIP
17
LEVER ACCELERATOR PEDAL
17
LEVER ACCELERATOR PEDAL
20
BEARING PEDAL LEVER TO FRONT PANEL, FROM IDENT NO. 941506, P 000001 ALSO INSTALLED ON 899081-941503 ONLY WITH OM601/OM602 ENGINE
23
FITTED WASHER ACCELERATOR PEDAL BEARING,B 838714,J 003392
26
LOCK RINGTO 000 553 37 01,000 553 39 01,
29
SCREW , Replaced By: N304017006020
29
SCREW , Replaced By: N304017006034
29
SCREW COVER PLATE TO COVER PLATE M 6 X 10
29
SCREW LICENSE PLATE TO BRACKET
32
SPRING WASHER LICENSE PLATE TO BRACKET
35
BRACKET FRONT FLOOR
38
SCREW COVER PLATE TO COVER PLATE M 6 X 12
41
SERRATED WASHER BRACKET TO CAB FLOOR,4 411811
44
NUT BALL PIVOT TO LEVER
47
SHIM
50
SCREW , Replaced By: N304017006020
50
SCREW LICENSE PLATE TO BRACKET
53
SERRATED WASHER BRACKET TO CAB FLOOR,4 411811
56
SPRING LEVER,823342
56
SPRING
59
STOP
62
SEAL RING KICK-DOWN SWITCH
65
LOCK PLATE PIN TO CLUTCH SLAVE CYLINDER BOOT, Replaced By: N006799005004
65
CIRCLIP PIN TO CLUTCH SLAVE CYLINDER BOOT
68
RUBBER BUFFER WIRE CABLE TO FIRE WALL, FROM IDENT NO. 941506, P 000001 ALSO INSTALLED ON 899081-941503 ONLY WITH OM601/OM602 ENGINE
71
WIRE CABLE
71
WIRE CABLE
71
WIRE CABLE
71
WIRE CABLE
74
BRACKET WIRE CABLE TO ENGINE
77
SCREW COVER PLATE TO COVER PLATE M 6 X 12
80
SPRING WASHER LICENSE PLATE TO BRACKET
83
CLAMP LINE TO SIDE MEMBER
86
SCREW BATTERY CABLE MOUNTING AND MAIN CABLE HARNESS MOUNTING
86
SCREW , Replaced By: N007985005157
89
SPRING WASHER ALTERNATOR CONNECTION D+
92
LOOM TIE , Replaced By: A1169970890
95
CLAMP LINE MOUNTING
98
CONNECTOR BOWDEN CABLE TO BRACKET
101
CLAMP
101
CLAMP , Replaced By: A0009955244
999
PAD , 000 112328 003 056792 007 046654 083 000998 086 000712 093 000557 102,103 091560 105 115062 183 001323 190 001262
