Поз.
Артикул
Описание
5
SOLENOID VALVE (3/2-WAY SOLENOID VALVE)
5
VALVE (3/2-WAY SOLENOID VALVE) ENGINE SHUT-OFF EKS, REPAIR IMPOSSIBLE
5
VALVE (3/2-WAY SOLENOID VALVE) ENGINE SHUT-OFF WABCO
8
SCREWM6X12 TX30
11
SEAL RINGBOSCH
14
RESERVOIR , Replaced By: A0004300503
14
RESERVOIR
17
HEXAGON HEAD BOLT. SCREW FRONT EXHAUST PIPE TO BRACKET
20
VALVE DRAIN VALVE
23
THRUST RING CHECK VALVE TO AIR RESERVOIR
26
SEAL RING20.3X2.4
29
VALVE , Replaced By: A0044293144
36
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
39
PLASTIC PIPE AERATION, ORDER BY THE METER
41
HOSE DELIVERY LINE TO POWER CYLINDER
47
FITTINGM12X1.5/M14X1.5
50
ELBOW FITTING
51
ELBOW FITTINGL6
53
REDUCTION FITTINGM14X1.5/M12X1.5
62
SEAL RING RIGHT SPRING-LOAD ACCUMULATOR 10X2.2
113
FITTING12X1.5/M16X1.5 RAUFOSS
119
FITTING8X1/M16X1.5 RAUFOSS
132
ELBOW FITTINGP5/12X1.5/90GR
134
ELBOW FITTINGP5/8X1MM/90GR
148
FITTINGP5/M16X1.5
161
FITTINGM16X1.5/M16X1.5 RAUFOSS
165
FITTINGM22X1.5/M16X1.5/M22X1.5 RAUFOSS
185
FITTINGM16X1.5/M16X1.5
192
PLUG WITH O-RING M16X1.5
195
REDUCER WITH O-RING M16X1.5/M12X1.5
222
T-FITTINGM16X1.5/M16X1.5/M16X1.5
230
PIPE BENDM12X1.5/M12X1.5 RAUFOSS
231
PIPE BENDM16X1.5/M16X1.5
233
PIPE BENDM22X1.5/M16X1.5 RAUFOSS
261
NUT WITH O-RING M12X1.5 RAUFOSS
262
NUT WITH O-RING M16X1.5 RAUFOSS
263
NUT WITH O-RING M22X1.5 RAUFOSS
292
DISTRIBUTOR8XM16X1.5 RAUFOSS
433
PIPE10MM
433
LINE BENT 10MM
436
UNION NUT
439
GLAND
454
LINE BENT 8MM
454
PIPE8MM
457
NUTM 14 X 1,5AL
460
CUTTING RINGBS8
483
BRACKET
486
SCREW PIPE ELBOW TO BRACKET M8X12
486
SCREW SPEED SENSOR TO REAR AXLE
504
HEXAGON HEAD BOLT. SCREW 3/2-WAY VALVE TO BRACKET M 8X100
504
HEXALOBULAR BOLT SOLENOID VALVE TO BRACKET M8X100
507
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
513
CLAMP LINE MOUNTING 10/15, Replaced By: N000000007511
513
CLAMP , Replaced By: N916016010211
513
CLAMP10/15
516
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
516
CLAMP ,K 147121, Replaced By: N000000000319
516
CLAMP LINE MOUNTING 8/15
519
SCREW BRACKET AND CLAMP M6X20
525
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
525
NUT , Replaced By: N913023006001
999
LOOM TIE LINE MOUNTING 280 MM
999
CABLE STRAP7.8X465
