Поз.
Артикул
Описание
352
DRAG LINK FROM STEERING INTERMEDIATE BRACKET II TO STEERING INTERMEDIATE BRACKET III, COMPONENT PARTS NOT AVAILABLE
352
DRAG LINK FROM STEERING SUPPORT II TO STEERING SUPPORT III EHRENREICH, COMPONENT PARTS NOT AVAILABLE
352
DRAG LINK FROM STEERING SUPPORT II TO STEERING SUPPORT III LEMFOERDER, COMPONENT PARTS NOT AVAILABLE
360
NUT DRAG LINK END M 24X1.5
360
NUT DRAG LINK TO LEVER
360
NUT , Replaced By: N000937024002
364
COTTER PIN DRAG LINK TO LEVER
368
STEERING SUPPORT INTERMEDIATE LEVER III
368
STEERING SUPPORT INTERMEDIATE LEVER II
376
SCREW SUPPORT TO SIDE MEMBER M 14X45
376
SCREW REAR SPRING REAR BRACKET AND STRUT TO SIDE MEMBER
376
SCREW STEERING SUPPORT TO FRAME M 14X50
376
SCREW MOUNTING TO SIDE MEMBER M 14X85
376
SCREW STEERING SUPPORT TO FRAME M 14X55
376
SCREW , Replaced By: N308676014012
384
NUT STEERING SUPPORT TO FRAME
384
NUT , Replaced By: N910113014000
392
INTERMEDIATE LEVER"III"
392
STEERING INTERMEDIATE ARM STEERING SUPPORT III
400
GREASE NIPPLE INTERMEDIATE LEVER
400
GREASE NIPPLE
400
GREASE NIPPLE , Replaced By: N071412008102
408
SEAL RING INSIDE
408
SEAL RING INSIDE TO 622 463 01 10
416
THRUST WASHER , Replaced By: A6574630162
416
THRUST WASHER INSIDE
424
NEEDLE BEARING INSIDE AND OUTSIDE
432
SPACER TUBE INSIDE
440
THRUST WASHER , Replaced By: A6574630062
440
THRUST WASHER OUTSIDE
448
SEAL RING INSIDE AND OUTSIDE TO 622 463 01 10
448
SEAL RING OUTSIDE TO 622 463 01 10
456
NUT INTERMEDIATE LEVER TO STEERING SUPPORT
456
NUT , Replaced By: N910113018004
464
CAP STEERING SUPPORT
472
DRAG LINK FROM STEERING SUPPORT II TO STEERING SUPPORT III
472
DRAG LINK FROM STEERING SUPPORT II TO STEERING SUPPORT III LEMFOERDER
472
DRAG LINK TUBE FROM STEERING INTERMEDIATE BRACKET III TO STEERED AXLE LEMFOERDER
472
DRAG LINK FROM STEERING SUPPORT II TO STEERING SUPPORT III EHRENREICH
480
BOOT
488
DRAG LINK END , Replaced By: A0014607848
488
DRAG LINK END L.H. THREAD TRW, Replaced By: A0024600348
488
DRAG LINK END , Replaced By: A0014601448, +001A0019905451
488
BALL JOINT L.H. THREAD TRW
488
DRAG LINK END , Replaced By: A0014602348, +001A0019905451
488
DRAG LINK END , Replaced By: A0014602348
496
DRAG LINK END , Replaced By: A0014607748
496
DRAG LINK END R.H. THREAD
496
DRAG LINK END R.H. THREAD
496
DRAG LINK END R.H. THREAD EHRENREICH
496
DRAG LINK END , Replaced By: A0014600848
496
DRAG LINK END , Replaced By: A0014602248
496
DRAG LINK END , Replaced By: A0014602248
496
DRAG LINK END , Replaced By: A0014601248, +001A0019905451
504
BOOT DRAG LINK END
512
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER
512
CLAMP DRAG LINK END TO DRAG LINK EHRENREICH
520
SCREW COLLAR DRAG LINK END TO DRAG LINK
528
HEXAGON HEAD BOLT. SCREW CLAMP TO DRAG LINK
528
SCREW , Replaced By: N308676012017
528
SCREW , Replaced By: N308676012017
536
NUT , Replaced By: N910113012003
536
NUT SUPPORT TO SIDE MEMBER
536
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
544
NUT DRAG LINK TO LEVER
544
NUT , Replaced By: N000937024002
552
COTTER PIN DRAG LINK TO LEVER
560
NUT DRAG LINK END M 24X1.5
