Поз.
Артикул
Описание
5
PLASTIC PIPE AERATION, ORDER BY THE METER
5
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
8
FITTING (PARTS KIT),LINE RUPTURE
11
UNION NUT LINE CONNECTION
14
GLAND LINE CONNECTION
17
SLEEVE LINE CONNECTION
18
HOSE LEAK LINE, ORDER BY THE METER
23
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
23
BANJO UNION HEATING CONNECTION,K 169122
23
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
29
ELBOW FITTING HOSE WIDTH, 6 MM,TO M22
29
ELBOW FITTING , Replaced By: A0049905371
29
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
30
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
31
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
32
CONNECTOR HOSE WIDTH, 6 MM,TO M16
32
CONNECTOR , Replaced By: A0029905478
38
CONNECTOR HOSE WIDTH, / I.D., 6 MM
38
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION
41
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
44
CONNECTOR DISTRIBUTOR TO CAB
44
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION
47
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
47
SEAL RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0019875046
47
SEAL RING
48
ELBOW FITTING HOSE WIDTH, 8 MM, TO M 16
50
LOCK RING LINE CONNECTION
50
SEAL RING , Replaced By: A0009940747
53
LOCK LINE CONNECTION
53
LOCK , Replaced By: A0009945448
56
REPAIR KIT COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
56
REPAIR KIT , Replaced By: A0309971748
