Поз.
Артикул
Описание
9
LINE FUEL LINE TO FUEL PUMP
10
LINE FUEL PIPE FROM VALVE TO DELIVERY PUMP AND TO CONTROL MODULE
10
VALVE FUEL LINE TO FUEL PUMP
11
LINE DELIVERY PUMP TO SEPARATION POINT
11
LINE DELIVERY PUMP TO SEPARATION POINT LUK 0014603080/ 0024600880/ 0034605080,*0000043*0030467 RECOMMENDED FOR TAKING ON STOCK BEFORE ORDERING, NOTE INSTALLED TANDEM PUMP
11
LINE DELIVERY PUMP TO SEPARATION POINT
11
LINE DELIVERY PUMP TO SEPARATION POINT
11
LINE DELIVERY PUMP TO SEPARATION POINT
11
LINE DELIVERY PUMP TO SEPARATION POINT ZF 0014605180/0024600780/3980,*0030467 RECOMMENDED FOR TAKING ON STOCK BEFORE ORDERING, NOTE INSTALLED TANDEM PUMP
14
LINE SEPARATION POINT FOR FILTER,*0030468
14
LINE SEPARATION POINT FOR FILTER,*0030467
14
LINE SEPARATION POINT FOR FILTER
14
LINE SEPARATION POINT FOR FILTER,*0225131
14
LINE , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 023217 RECOMMENDED FOR TAKING ON STOCK, Replaced By: A5420701032
14
LINE ,*0225131, Replaced By: A5420704532
17
LOOM TIE LINE MOUNTING 280 MM
17
LOOM TIE LINE MOUNTING
20
LINE FUEL FILTER TO FUEL FEED DUCTS,*0030468*0225130
20
LINE FUEL FILTER TO FUEL FEED DUCTS
20
LINE FUEL FILTER TO FUEL FEED DUCTS,*0030447
20
LINE FUEL FILTER TO FUEL FEED DUCTS
20
LINE , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 022095 RECOMMENDED FOR TAKING ON STOCK, Replaced By: A5410704632
20
LINE ,*0225131, Replaced By: A5410700335
21
CONNECTOR ,*0030468*0225130
53
LINE RETURN LINE,FROM FILTER TO TANK
53
FUEL LINE RETURN LINE,FROM FILTER TO TANK
53
LINE RETURN LINE,FROM FILTER TO TANK
53
LINE , Replaced By: A5410704332
53
LINE , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 022844, Replaced By: A5410704332
56
VALVE
56
VALVE
56
VALVE , Replaced By: A3760980057
56
VALVE
56
VALVE ON INTAKE RADIATOR-CONTROL MODULE, FROM ENG.559827
57
LINE FUEL RETURN DUCT,REAR RIGHT TO DISTRIBUTOR FITTING
58
LINE FUEL RETURN DUCT,REAR LEFT TO DISTRIBUTOR FITTING
59
CONNECTOR LINE CONNECTION
60
FITTING FUEL RETURN DUCT,REAR LEFT AND RIGHT TO DISTRIBUTOR FITTING
62
UNION NUT RETURN LINE
68
SCREW. BANJO BOLT AIR RESERVOIR,CONNECTION: "33",4 872664
68
HOLLOW SCREW FUEL FEED,AT WATER SEPARATOR
69
HOLLOW SCREW FUEL FEED,AT WATER SEPARATOR
69
SCREW. BANJO BOLT AIR RESERVOIR,CONNECTION: "33",4 872664
69
HOLLOW SCREW LINE TO OIL RADIATOR
74
SCREW. BANJO BOLT AIR RESERVOIR,CONNECTION: "33",4 872664
74
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
74
HOLLOW SCREW. SCREW GOVERNOR-PRESSURE/MODULATION-PRESSURE MEASURING CONNECTION,012578
74
HOLLOW SCREW AT SOLENOID VALVE
74
HOLLOW SCREW GOVERNOR-PRESSURE/MODULATION-PRESSURE MEASURING CONNECTION,012578, Replaced By: N000000004895
74
HOLLOW SCREW FUEL FEED,AT WATER SEPARATOR
87
HOLLOW SCREW AT SOLENOID VALVE
87
HOLLOW SCREW FUEL LINE LEADING TO FUEL PUMP
88
SEALING RING FUEL LINE TO UNIT PUMP AND CYLINDER HEAD
89
SEALING RING OIL PRESSURE GAUGE SENDER UNIT
90
SEALING RING OIL PRESSURE GAUGE SENDER UNIT
92
SEALING RING OIL PRESSURE GAUGE SENDER UNIT
98
SEALING RING OIL PRESSURE GAUGE SENDER UNIT
101
SEALING RING OIL PRESSURE GAUGE SENDER UNIT
101
SEALING RING FUEL LINE TO UNIT PUMP AND CYLINDER HEAD
103
SEALING RING OIL PRESSURE GAUGE SENDER UNIT
105
SCREW PLUG RELAY VALVE,CONNECTION "20",RIGHT
106
BRANCH-OFF FITTING FUEL LINE TO CONTROL UNIT
107
CLAMP FUEL LINES,019450
107
CLAMP
107
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
107
CLAMP COOLING WATER LINE TO FIRE WALL
107
CLAMP BATTERY CABLE MOUNTING
110
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL M8X16 MM
110
HEXAGON HEAD BOLT CONTROL ARM, LINKAGE ADJUSTER ON BEARING BRACKET M8X12
110
HEXAGON HEAD BOLT LINE MOUNTING M8X18
110
SCREW STOP TO BATTERY CASE
110
STUD BOLT
110
SCREW CLAMP ON BRACKET
110
HEXAGON HEAD BOLT. SCREW ON STOP M 8X50
110
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
110
SCREW , Replaced By: N000000000436
111
NUT FUEL LINE FIXTURE
111
HEXAGON NUT BRACKET TO FRAME
112
SPACER RING BRACKET TO TIMING CASE COVER
113
CLAMPING PIECE FUEL LINE FIXTURE
113
CLAMPING PIECE FUEL LINE FIXTURE
113
CLAMPING PIECE , Replaced By: A5419950248
116
STUD BOLT OIL PAN TO CYLINDER CRANKCASE M 8X40
116
STUD BOLT
116
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
119
LOOM TIE187 X 3.6 MM
122
LOOM TIE LINE MOUNTING
122
LOOM TIE LINE MOUNTING 280 MM
125
CLAMP. EXTENDABLE SPACER BREATHER LINE
130
BRACKET FUEL LINE ON TIMING CASE COVER,LEFT
