Поз.
Артикул
Описание
5
RADIATOR , Replaced By: A6555000403
5
RADIATOR , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 752618, Replaced By: A6555002103
5
RADIATOR , Replaced By: A6525014501
5
RADIATOR , Replaced By: A6525014501
5
RADIATOR , Replaced By: A6525016501
5
RADIATOR , Replaced By: A6525016501
5
RADIATOR WITH SCREW FITTING
7
SCREW WATER DRAIN
7
SCREW , Replaced By: A0005000085
7
SCREW WATER DRAIN
9
SCREW PLUG WATER DRAIN
11
GASKET COOLING WATER DRAIN TO 656 500 00 03
11
SEAL RINGTO 000 553 03 05,000 553 18 05,
13
LOCK
15
SUPPORT RADIATOR,LEFT,K 096750
15
SUPPORT RADIATOR,LEFT,K 096749
17
SCREW CONSOLE TO SIDE MEMBER
19
NUT SUPPORT TO SIDE MEMBER
21
RUBBER MOUNTING RADIATOR
23
SCREW , Replaced By: N304017010028
23
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
23
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
23
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
25
WASHER , Replaced By: N000125010532
25
WASHER RADIATOR TO RUBBER MOUNTING
27
SPRING WASHER STEERING COLUMN BRACKET TO CAB
29
FAN SHROUD RADIATOR
31
DETENT FAN SHROUD TO RADIATOR
32
LOCK , Replaced By: N912002008003
32
LOCK PULL TO FASTENER
35
BOOT FAN SHROUD TO FAN RING
45
TANK COOLING WATER EXPANSION
46
RADIATOR CAP , Replaced By: A0005016415
46
RADIATOR CAP FILLER NECK
47
SEAL RING
48
RADIATOR CAP
50
RADIATOR CAP CENTRAL
50
RADIATOR CAP CENTRAL
53
GASKET O.D., 52 MM
56
GASKET O.D., 37 MM
59
DRAIN PIPE
62
SENDER UNIT COOLING WATER LEVEL INDICATOR
65
PLATE FROM EXPANSION TANK TO RADIATOR 40X40 MM
65
PLATE FROM EXPANSION TANK TO RADIATOR
68
BRACKET. LOCK , Replaced By: A6525040038
68
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
71
HOSE FROM EXPANSION TANK TO ENGINE
74
CLAMP , Replaced By: N916017011001
74
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
110
BRACKET , NOT USED
128
SCREW PUMP TO BRACKET
128
SCREW , Replaced By: N304017006016
140
WASHER COMPRESSED AIR LINE TO BRACKET
140
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
149
NUT RETAINER LICENSE PLATE TO BRACKET
149
NUT RETAINER , Replaced By: A0019906791
152
SCREW DE-AERATION LINE TO RADIATOR
152
SCREW , Replaced By: A6739900032
155
CLAMP OIL-DIPSTICK GUIDE TUBE TO BRACKET
158
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
158
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
158
NUT , Replaced By: N913004008001
999
WASHER , Replaced By: N000125006421
999
SCREW GUIDE TUBE BRACKET TO RADIATOR
