Поз.
Артикул
Описание
5
CRANKSHAFT , 900 383887 940 383887 942 10/50,20/60 000921 946 10/50,20/60 001733 947 10/50,20/60 000833 991 383887 994 383887
5
CRANKSHAFT
5
CRANKSHAFT , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A6020311801
11
PIN , 911 10/50,20/60 010630 911 12/52,22/62 002533 912 10/50,20/60 016254 912 12/52,22/62 002626
17
WOODRUFF KEY CRANKSHAFT GEAR AND HUB ON CRANKSHAFT
17
WOODRUFF KEY
23
CRANKSHAFT GEAR
23
CRANKSHAFT GEAR
29
HUB PULLEY, 942 10/50,20/60 001739 942 12/52,22/62 000057 946 10/50,20/60 002441 947 10/50,20/60 001047
35
CYLINDRICAL PIN
41
WASHER HUB TO CRANKSHAFT
47
SCREW CROSS MEMBER TO REINFORCEMENTS AND TO SIDE MEMBERS M 18X50
47
SCREW , Replaced By: A0069903701
53
PULLEY , 940 10/50,20/60 349109 942 10/50,20/60 000454 946 10/50,20/60 000719 947 10/50,20/60 000159
59
VIBRATION ABSORBER VIBRATION ABSORBER
59
VIBRATION ABSORBER VIBRATION ABSORBER
65
COMBINATION BOLT VIBRATION ABSORBER AND PULLEY TO HUB M 8X28
74
FLYWHEEL
74
INTERMEDIATE GEAR ,058426
83
RING GEAR
83
RING GEAR
95
SCREW FOLLOWER DISC,WASHER AND FLYWHEEL TO CRANKSHAFT
95
SCREW , ONLY REPLACEABLE BY THE SET 942 10/50,20/60 001861 942 12/52,22/62 000070 946 10/50,20/60 002563 947 10/50,20/60 001055 962 10/50,20/60 033526 962 12/52,22/62 020794 993 10/50,20/60 000290, Replaced By: A1119901112
95
SCREW FLYWHEEL TO CRANKSHAFT
95
SCREW , Replaced By: A0019909112
101
SPACER RING
101
SPACER RING
101
SPACER RING , Replaced By: A1110310251
107
COVER RING
113
BALL BEARING
113
GROOVED BALL BEARING
119
CRANKSHAFT BEARING PARTS KIT,STANDARD 58.00 MM, WHEN ORDERING, PLEASE STATE ADDITIONAL CODE: 52BLUE, 54YELLOW, 56RED
119
CRANKSHAFT BEARING PARTS KIT,REPAIR SIZE I 57.75 MM
119
CRANKSHAFT BEARING PARTS KIT,REPAIR SIZE III 57.25 MM
119
CRANKSHAFT BEARING PARTS KIT,REPAIR SIZE II 57.50 MM
119
CRANKSHAFT BEARING PARTS KIT,REPAIR SIZE IV 57.00 MM
125
GUARD PLATE PARTS KIT 2.20 MM
125
GUARD PLATE PARTS KIT 2.25 MM
125
GUARD PLATE PARTS KIT 2.35 MM
125
GUARD PLATE PARTS KIT 2.40 MM
125
GUARD PLATE PARTS KIT 2.15 MM
