Поз.
Артикул
Описание
5
AIR CLEANER (PAPER AIR CLEANER) MANN & HUMMEL
5
AIR CLEANERKNECHT,5 451580
14
FILTER ELEMENT AIR CLEANER
14
FILTER ELEMENT AIR CLEANER MANN & HUMMEL
14
FILTER ELEMENT AIR CLEANER MANN & HUMMEL
17
AIR BAFFLE AIR CLEANER
26
FASTENER ,5 451580
26
FASTENER AIR CLEANER BOWL MANN & HUMMEL
26
FASTENER
35
NUT , Replaced By: N913002008004
35
NUT SWITCH TO FLOOR PLATE
35
NUT
35
NUT
38
GASKET AIR CLEANER BOWL MANN & HUMMEL
38
GASKET ,5 451580
41
WASHER , Replaced By: N000125008443
41
WASHER EXHAUST MUFFLER TO STRAP
44
NUT , Replaced By: N913004008001
47
BRACKET ,5 451580
56
SCREW CONSOLE TO FRAME
56
SCREW , Replaced By: N308676016020
62
WASHER , Replaced By: N000125017016
62
WASHER BRACKET TO FRAME
68
NUT COMBINATION CYLINDER TO BEARING BRACKET
68
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
74
MUFFLER (INTAKE MUFFLER)
77
RUBBER MOUNTING BRACKET TO BEARING BRACKET
80
BRACKET , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 494909, Replaced By: A6735282440
80
BRACKET INTAKE MUFFLER
83
SCREW PIPE CLAMP
83
SCREW , Replaced By: N304017008021
86
WASHER , Replaced By: N000125008443
86
WASHER EXHAUST MUFFLER TO STRAP
89
NUT , Replaced By: N913004008001
92
RUBBER MOUNTING INTAKE MUFFLER TO BRACKET
95
SPACER TUBE PUMP TO FRAME SIDE MEMBER 12X21 MM
98
HEXALOBULAR BOLT. SCREW MANUAL PUMP BRACKET TO FENDER BRACKET
98
SCREW. HEXAGON HEAD BOLT , Replaced By: N910143008005
98
SCREW BRACKET TO SIDE MEMBER
98
SCREW , Replaced By: N304017008040
101
WASHER , Replaced By: N000125008443
101
WASHER EXHAUST MUFFLER TO STRAP
104
RETAINER INTAKE MUFFLER TO BRACKET
107
NUT , Replaced By: N913004008001
110
SCREW EXHAUST PIPE TO BRACKET
113
NUT STRAP TO BRACKET
113
NUT , Replaced By: N910113010000
125
AIR INTAKE PIPE
128
MUFFLER AIR INTAKE PIPE,INSIDE
131
LOCK ELECTRIC CABLE THRU CAB FLOOR
134
SHEET METAL SCREW MUFFLER TO AIR INTAKE PIPE,INSIDE
137
SEAL RING MUFFLER TO AIR INTAKE PIPE,INSIDE, DISCONTINUED,PART IS NO LONGER REQUIRED
140
BUFFER REFRIGERANT LINE TO CAB
140
BUFFER , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6739880511
143
WASHER , Replaced By: N009021008213
143
WASHER BRACKET TO LEFT SIDE MEMBER
146
NUT , Replaced By: N913004008001
149
BOOT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 034532, Replaced By: A0005280091
149
BOOT AIR INTAKE
152
CLAMP BOOT TO INTAKE PIPE
155
CLAMP BOOT TO AIR CLEANER,K 034532
158
SCREW BOOT TO AIR DUCT AND TO AIR CLEANER
161
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
164
HOSE ,5 451580
170
CLAMP FROM AIR CLEANER TO HOT AIR INTAKE PIPE
173
CLAMP , Replaced By: A0059970690
173
CLAMP HOSE TO AIR CLEANER AND TO INTAKE PIPE 100-120X13 MM
200
CAP INTAKE MUFFLER FITTING
203
LOOM TIE LINE MOUNTING 280 MM
221
HOSE FROM MUFFLER TO ENGINE
226
CLAMP HOSE TO RADIATOR,PIPE ELBOW,AND WATER PUMP 82 - 105 X 15.8 MM
226
CLAMP , Replaced By: N000000000675
226
CLAMP , Replaced By: A0059972990
229
CLAMP FROM AIR CLEANER TO HOT AIR INTAKE PIPE
