Поз.
Артикул
Описание
5
BRAKE VALVE SERVICE BRAKE KNORR
5
BRAKE VALVE SERVICE BRAKE WABCO
8
LOCKTO 345 431 70 05
11
SPRINGTO 345 431 70 05
11
SPRINGTO 345 431 70 05
17
SPRINGTO 345 431 71 05
20
PISTONTO 345 431 71 05
23
LOCK RINGTO 345 431 71 05
26
LOCK RINGTO 345 431 71 05
29
LOCK RING
29
LOCK RING PLANETARY CARRIER
32
REPAIR KIT SMALL SCOPE TO 345 431 70 05
32
REPAIR KIT SMALL SCOPE TO 345 431 71 05
35
REPAIR KIT , Replaced By: A0014300460
38
VALVE (QUICK BREATHER VALVE) VARGA
38
VALVE QUICK-RELEASE VALVE KNORR
38
VALVE (QUICK BREATHER VALVE) WABCO
40
REPAIR KITTO A 364 429 70 44
40
REPAIR KITTOA 382 429 70 44, A 693 429 71 44
41
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
42
O-RING CHECK VALVE TO AIR RESERVOIR
43
THRUST RING CHECK VALVE TO AIR RESERVOIR
44
VALVE (RELAY VALVE) KNORR
45
REPAIR KIT. VALVE REPAIR KIT TO 695 429 71 44
46
BRACKET QUICK-RELEASE VALVE
47
BRACKET (RELAY VALVE)
51
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
53
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
56
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
59
SCREW PLUG AT TANK
59
SCREW PLUG
86
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
92
GASKET BRAKE BOOSTER ASSEMBLY TO FIRE WALL
92
GASKET BRAKE SHOE WITH LINING
93
WASHER TRAILER PLUG SOCKET TO BRACKET
94
SCREW , Replaced By: N910143008002
95
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
96
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
98
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
110
VALVE (PARKING BRAKE VALVE)
110
VALVE (PARKING BRAKE VALVE)
113
PROTECTIVE CAPTO 384 430 76 09, NO.8650I.......I I I II .......INO.9985I I I II I
115
KNOB (PARTS KIT) TO 384 430 76 09, NO.8650I.......I I I II .......INO.9985I I I II I
117
REPAIR KITTO 384 430 76 09
117
REPAIR KITTO 384 430 73 09
120
FITTING PARKING BRAKE VALVE
122
SCREW. UNION SCREW , Replaced By: A0009973734
125
LOCK , Replaced By: A0009945448
127
SEAL RING , Replaced By: A0009940747
129
THRUST RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
131
SEAL RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
140
SCREW SHIFT LEVER TO BRACKET M8X30
143
SWITCH PARKING BRAKE VALVE,CONNECTION: "11"
147
LOOM TIE
150
HOSE WATER SEPARATOR
999
SCREW-IN FITTING OIL LINE CONNECTION
999
FITTING QUICK-RELEASE VALVE
999
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
