Поз.
Артикул
Описание
23
29
HEXAGON HEAD BOLT MOUNTING PLATE TO SIDE MEMBER AND TO AUXILIARY FRAME M16X1.5X70
32
WASHER CONSOLE TO FRAME
35
ENGINE STAY RUBBER MOUNTING TO FRONT CROSS MEMBER
38
NUT SUPPORT TO SIDE MEMBER
44
47
47
50
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
50
NUT , Replaced By: N910113014000
56
62
ENGINE SUPPORT REAR LEFT
62
ENGINE SUPPORT REAR RIGHT
68
SCREW SUPPORT TO TRANSMISSION M 22X1,5X60
68
SCREW FRONT SPRING FRONT BRACKET TO SIDE MEMBER M 22X85
74
77
SCREENING PLATE
80
83
WASHER ENGINE MOUNTING TO SUPPORTING ARM
95
101
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
104
107
WASHER
110
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
122
125
PLATE ENGINE REAR SUPPORT
128
PLATE ENGINE REAR SUPPORT
131
SHIM SUPPORT
137
NUT BRACKET TO SIDE MEMBER M12X1.5
137
NUT SUPPORT TO FRAME
999
ENGINE CROSS MEMBER REAR,B 669058
