Поз.
Артикул
Описание
5
DIFFERENTIAL GEAR LESS FLANGE, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
8
AXLE HOUSING
11
CYLINDRICAL PIN
11
CYLINDRICAL PIN , Replaced By: N000007008101
14
SCREW DIFFERENTIAL GEAR BEARING
17
PIN AXLE HOUSING
20
SNAP RING25X1.2 MM, MAN AXLE
23
SPACER WASHER PINION HOUSING,AS REQUIRED 0.10 MM, NOT USED
23
SPACER WASHER DIFFERENTIAL HOUSING,AS REQUIRED 0.50 MM
23
SPACER WASHER PINION HOUSING,AS REQUIRED 1.00 MM, NOT USED
23
SPACER WASHER PINION HOUSING,AS REQUIRED 0.15 MM
26
HOUSING. OIL COLLECTOR (PINION HOUSING)
26
HOUSING , Replaced By: A3553530807, +001N000906020003
29
SEAL RING PINION HOUSING TO AXLE HOUSING
32
SCREW APPARATUS SUPPORT TO FRAME
32
SCREW , Replaced By: A9429901304
119
DIFFERENTIAL LOCK PARTS KIT
122
LOCK FOLLOWER
125
SHIFTING FORK DIFFERENTIAL LOCK
128
SPRING SHIFTING FORK
131
SHAFT SHIFTING ROD,232175
134
HEADLESS SETSCREWM 10X25,232175
137
NUT CLUTCH OPERATION
137
NUT , Replaced By: N304035010002
140
CYLINDER , Replaced By: A3463530655
140
CYLINDER TRANSVERSE DIFFERENTIAL LOCK
143
PISTON TRANSVERSE DIFFERENTIAL LOCK
143
PISTON TRANSVERSE DIFFERENTIAL LOCK
146
SEAL RING SHIFTING CYLINDER
149
GASKET SHIFTING CYLINDER TO INTERMEDIATE FLANGE
152
SCREW , Replaced By: N304014008001
152
SCREW FRONT AXLE REGULATING SOLENOID VALVE M 8X75
155
SWITCH , Replaced By: A0015455709
155
SWITCH
155
SWITCH
158
SEAL RING VALVE TO VALVE,K 025179
161
SCREW DIFFERENTIAL GEAR TO REAR AXLE CASING M 12X40
161
SCREW REAR AXLE HOUSING TO AXLE CASING M 12X35
164
SCREW BRACKET TO BRACKET
