Поз.
Артикул
Описание
5
SUPPORT ACCOMMODATION BOX NEAR DRIVER'S SEAT, LEFT,227836, 228008
5
SUPPORT ACCOMMODATION BOX NEAR DRIVER'S SEAT, LEFT,227835, 228007 STATE COLOR WHEN ORDERING STATE IDENT NO. WHEN ORDERING
6
TAPPING SCREW3.5X16
7
CAP BLACK
8
BOX ACCOMMODATION BOX,227835, 228007 STATE COLOR WHEN ORDERING STATE IDENT NO. WHEN ORDERING
8
BOX ACCOMMODATION BOX,227835, 228007
8
BOX ACCOMMODATION BOX
8
BOX ACCOMMODATION BOX,227836, 228008
11
LOCK
12
TUMBLER WITH LOCK DEFINED, STATE LOCK NUMBER WHEN ORDERING
14
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
14
WASHER CAN NEUTRAL POINT ON EQUIPMENT PLATE
17
SCREW CONTROL UNIT
20
COVERING AT BOX
23
PANELLING AT BOX, STATE COLOR WHEN ORDERING STATE IDENT NO. WHEN ORDERING
26
COVERING LOCK
29
WASHER VALVE TO BRACKET,5 602406
29
WASHER BRACKET TO SUPPORT
32
SCREW
35
BALL PIVOT AT BOX
38
HINGE AT BOX
38
HINGE AT BOX
41
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
44
NUT SPRING-LOADED PUSH ROD
47
FASTENER ACCOMMODATION BOX
50
WASHER COLD START SYSTEM TO BRACKET
53
NUT
56
WASHER COVERING TO CAB
59
NUT SPRING-LOADED PUSH ROD
62
WASHER COLD START SYSTEM TO BRACKET
65
SCREW. HEXAGON HEAD BOLT ON AIR INTAKE PIPE BRACKET M 8X16
68
SCREW BRACKET TO PLATFORM FLOOR AM 6X12
71
WASHER FRAME MOUNTING
74
NUT SPRING-LOADED PUSH ROD
75
NUT RETAINER , Replaced By: A0019944745
76
NUT
77
BRACKET BOX TO BODY
78
BRACKET BOX TO BODY
79
ROPE ACCOMMODATION BOX
80
SCREW COVER PLATE TO COVER PLATE M 6 X 10
80
SCREW FAN SHROUD TO RADIATOR
83
WASHER MODULATOR TO ENGINE CONTROL SHAFT
86
NUT SPRING-LOADED PUSH ROD
89
SPRING (PNEUMATIC SPRING)
92
COVERING ACCOMMODATION BOX
95
TAPPING SCREW BRACKET TO CAB FLOOR 3.5X9.5
999
SHELL TRAY
