Поз.
Артикул
Описание
3
TRANSMISSION CASE FRONT PART
3
TRANSMISSION CASE , FIRST EXHAUST STOCK OF OLD PARTS UP TO TRANSMISSION 067656, Replaced By: A3872617202
3
TRANSMISSION CASE , Replaced By: A3872610508, +002N000960018018, +002N912004018101
7
EXPANSION PLUG TRANSMISSION CASE,SIDE
7
PLUG
12
SCREW PLUG TRANSMISSION CASE TOP COVER
27
TRANSMISSION CASE , Replaced By: A3872614103, +001A3859970130
27
TRANSMISSION CASE , Replaced By: A3872615203
27
TRANSMISSION CASE , Replaced By: A3872615303, +001A3859970130
27
TRANSMISSION CASE , Replaced By: A3872618103
27
TRANSMISSION CASE ,047923, Replaced By: A3872615303, +001A3859970130
27
TRANSMISSION CASE REAR PART
30
SCREW PLUG , Replaced By: A0009972632
33
SCREW PLUG HOUSING,BOTTOM,183596
33
SCREW PLUG HOUSING,BOTTOM,183596
36
PIN COVER TO P.T.O. CASE
39
SCREW TRANSMISSION CASE FRONT PART TO REAR PART M 10X60
39
SCREW P.T.O. TO TRANSMISSION M 10X60
42
SPRING WASHER STEERING COLUMN BRACKET TO CAB
45
TRANSMISSION CASE COVER FRONT DRIVE SHAFT,050225
45
TRANSMISSION CASE COVER , Replaced By: A3872610918
45
TRANSMISSION CASE COVER ,050224, Replaced By: A3872612218, +001A3872610382
48
SEAL RING , Replaced By: A0159970447
48
SEAL RING , Replaced By: A0159970347
48
SEAL RING DRIVE SHAFT
48
SEAL RING CASE COVER
48
SEAL RING CASE COVER
48
SEAL RING CASE COVER,000516
48
SEAL RING CASE COVER,000516
48
SEAL RING
48
SEAL RING TRANSMISSION CASE FRONT COVER,000516
51
SPACER WASHER OUTPUT SHAFT,AS REQUIRED 1.50 MM
51
SPACER WASHER OUTPUT SHAFT,AS REQUIRED 1.10 MM
51
SPACER WASHER DRIVE SHAFT,AS REQUIRED 1.30 MM
51
SPACER WASHER , Replaced By: A3872620252
51
SPACER WASHER , Replaced By: A3872620252
51
SPACER WASHER , Replaced By: A3872620452
51
SPACER WASHER , Replaced By: A3872620452
51
SPACER WASHER DRIVE SHAFT,AS REQUIRED 1.45 MM
51
SPACER WASHER , Replaced By: A3872621152
54
GASKET , Replaced By: A3872614480
54
GASKET CASE COVER
57
CAP
57
CAP ,050224, Replaced By: A3872610382, +001A3872612218
60
SCREW CYLINDER TO TRANSMISSION CASE
63
SPRING WASHER , Replaced By: N000137008212
63
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
66
COVER , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A3872611933
66
COVER
66
COVER , Replaced By: A3892611933, +006N914146010108
66
COVER TRANSMISSION CASE FRONT PART
69
SPACER WASHER AS REQUIRED 0.10 MM, UP TO IDENT NO. 4 477510 FROM IDENT NO. SEE UNIT MICROFICHE,MODEL 750.5
69
SPACER WASHER AS REQUIRED 0.10 MM
69
SPACER WASHER AS REQUIRED 0.20 MM
69
SPACER WASHER , Replaced By: A4063370352
69
SPACER WASHER AS REQUIRED 0.05 MM
69
SPACER WASHER , Replaced By: A4063370552
69
SPACER WASHER COUNTERSHAFT,AS REQUIRED 3.00 MM,375914
69
SPACER WASHER COUNTERSHAFT,AS REQUIRED 1.00 MM,375914
69
SPACER WASHER COUNTERSHAFT,AS REQUIRED 0.50 MM
69
SPACER WASHER AS REQUIRED 0.40 MM
69
SPACER WASHER COUNTERSHAFT,AS REQUIRED 2.00 MM,375914
72
GASKET , Replaced By: A3872614580
72
GASKET COVER TO TRANSMISSION CASE FRONT PART
75
SCREW COVER TO TRANSMISSION M10X22
78
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
81
TRANSMISSION CASE COVER ,068013
81
TRANSMISSION CASE COVER ,068015275844, Replaced By: A3872617720
81
TRANSMISSION CASE COVER ,068014 ALSO INSTALLED ON 066624,067571275844, Replaced By: A3872617720
81
TRANSMISSION CASE COVER ,068014
81
TRANSMISSION CASE COVER REAR,SPEEDOMETER DRIVE,275845
84
SEAL RING TRANSMISSION CASE REAR COVER,INSIDE 10MM
84
SEAL RING TRANSMISSION CASE REAR COVER,INSIDE 10MM
84
SEAL RING TRANSMISSION CASE REAR COVER,INSIDE 10MM
87
SEAL RING TRANSMISSION CASE REAR COVER,OUTSIDE 10MM
87
SEAL RING , Replaced By: A0129974447
87
SEAL RING , Replaced By: A0179977947
87
SEAL RING
87
SEAL RING
90
SCREW PLUG, FILLING HOUSING,BOTTOM M18X1.5
90
SCREW PLUG HOUSING,BOTTOM, Replaced By: N000908018011
93
DRIVE GEAR ,000367, Replaced By: A3872640131, +001A3872640432
93
DRIVE GEAR SPEEDOMETER DRIVE
96
SHAFT ,000367, Replaced By: A3872640432
96
SHAFT SPEEDOMETER DRIVE
99
THREADED BUSHING , UP TO CHASSIS 447270 FROM CHASSIS SEE SPARE PARTS LIST 817,INAPPLICABLE TO R.H.D.AND SUPERCHARGED ENGINE VEHICLES
102
SENDER UNIT ACTUATION OF ELECTRONIC SPEEDOMETER 25 MM
102
SENDER UNIT , Replaced By: A0105428217
102
SENDER UNIT , Replaced By: A0125424817, +001A3565400381
102
PULSE SENDER UNIT. SENDER UNIT (COUNTER WHEEL SENDER)
102
SENDER UNIT , Replaced By: A0155422417
105
SEAL RING , Replaced By: A0119976447
105
SEAL RING , Replaced By: A1152740060
105
SEAL RING , Replaced By: A0119976447
105
SEAL RING SPEEDOMETER DRIVE
108
PLUG
111
SPACER WASHER MAINSHAFT, AS REQUIRED 0.90 MM
111
SPACER WASHER COUNTERSHAFT,AS REQUIRED 0.95 MM
111
SPACER WASHER DRIVE SHAFT,AS REQUIRED 1.30 MM
111
SPACER WASHER , Replaced By: A3872620252
111
SPACER WASHER , Replaced By: A3872620252
111
SPACER WASHER , Replaced By: A3872620452
111
SPACER WASHER , Replaced By: A3872620452
111
SPACER WASHER DRIVE SHAFT,AS REQUIRED 1.45 MM
111
SPACER WASHER , Replaced By: A3872621152
111
SPACER WASHER OUTPUT SHAFT,AS REQUIRED 1.10 MM
111
SPACER WASHER OUTPUT SHAFT,AS REQUIRED 1.50 MM
114
SPACER WASHER AS REQUIRED 0.10 MM
114
SPACER WASHER AS REQUIRED 0.20 MM
114
SPACER WASHER , Replaced By: A4063370352
114
SPACER WASHER AS REQUIRED 0.05 MM
114
SPACER WASHER , Replaced By: A4063370552
114
SPACER WASHER COUNTERSHAFT,AS REQUIRED 3.00 MM,375914
114
SPACER WASHER COUNTERSHAFT,AS REQUIRED 1.00 MM,375914
114
SPACER WASHER COUNTERSHAFT,AS REQUIRED 2.00 MM,375914
114
SPACER WASHER COUNTERSHAFT,AS REQUIRED 0.50 MM
114
SPACER WASHER AS REQUIRED 0.40 MM
114
SPACER WASHER AS REQUIRED 0.10 MM, UP TO IDENT NO. 4 477510 FROM IDENT NO. SEE UNIT MICROFICHE,MODEL 750.5
117
GASKET , Replaced By: A3872613380
117
GASKET , Replaced By: A3872614380
117
GASKET TRANSMISSION CASE REAR COVER TO TRANSMISSION CASE
120
SCREW CLUTCH BOOSTER TO BELL HOUSING M 10X30,5 962907
123
COVER
123
COVER
129
SCREW CLUTCH SLAVE CYLINDER TO BELL HOUSING
132
UNIT IDENTIFICATION PLATE TRANSMISSION CASE
135
RIVET UNIT IDENTIFICATION PLATE TO TRANSMISSION CASE
135
GROOVED NAIL
