Поз.
Артикул
Описание
6
RUBBER MOUNTING ENGINE FRONT SUSPENSION
6
RUBBER MOUNTING ENGINE FRONT SUSPENSION
6
RUBBER MOUNTING ENGINE FRONT SUSPENSION
12
RUBBER MOUNTING
12
RUBBER MOUNTING
18
RUBBER MOUNTING , Replaced By: A6152400218
18
RUBBER MOUNTING , Replaced By: A6152400318
24
ENGINE STAY RUBBER MOUNTING TO FRONT CROSS MEMBER
30
ENGINE STAY RUBBER MOUNTING TO ENGINE REAR SUPPORT
36
LOCK WASHER PROPELLER SHAFT TO REAR AXLES I AND II
42
HEX. NUT. NUT FUEL TANK TO CONSOLE,167609
48
SCREW SUPPORTING ARM TO FRONT RUBBER MOUNTING M 16X16
54
WASHER CONSOLE TO FRAME
60
BEARING BRACKET
60
BEARING BRACKET , Replaced By: A3442410035
66
LOCK
72
SCREW BATTERY CASE
72
SCREW ENGINE TO REAR RUBBER MOUNTING M 14X45,609836 345.300 UP TO IDENT NO. 704163 "1316"
72
SCREW BATTERY CASE TO SIDE MEMBER
84
WASHER CROSS MEMBER TO SUPPORT
90
INTERMEDIATE PIECE ENGINE MOUNTING TO CONSOLE
96
SCREW LEFT AND RIGHT CONSOLES TO FRAME M 12X1.5X50
96
SCREW SPACER TUBE BETWEEN STABILIZER SHACKLES 12X1.5X75,D 228765
102
LOCK WASHER FITTING TO BRACKET
108
SUPPORTING ARM LEFT
114
SUPPORTING ARM CLUTCH END
120
SCREW BEARING BRACKET AND PLATE TO FRAME M 16X1.5X40
126
LOCK WASHERROCKINGER TYP 59 G140,59 G150
132
SCREENING PLATE REAR RUBBER MOUNTING
138
SCREW , Replaced By: N308676014012
144
WASHER IN ITS PLACE,YOU MAY ALSO USE MERCEDES-BENZ PART NO.: 360 990 18 40
150
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
156
ROD
156
ROD , Replaced By: A3452407125
162
NUT
168
NUT L.H. THREAD TO 352 240 02 25
174
ROD ENDTO 345 240 71 25
174
ROD ENDTO 352 240 02 25
180
ROD ENDTO 345 240 71 25
180
ROD ENDTO 352 240 02 25
186
BUSHINGTO 345 240 71 25
192
RUBBER MOUNTINGTO 345 240 71 25
198
CLAMPTO 345 240 71 25
204
SCREW COVERING TO BRACKET
210
LOCK WASHER TAIL LAMP TO BRACKET
216
NUT
222
BRACKET ENGINE ALONGSIDE FIXING, USED WITH AIR BRAKE,FROM CHASSIS 588186 345.300 UP TO IDENT NO. 704163 "1316"
228
SCREW REAR CROSS MEMBER AND GUSSET PLATES TO SIDE MEMBERS M 12X30
228
SCREW FUEL LINE TO SIDE MEMBER
228
SCREW BEARING BRACKET TO SIDE MEMBER
231
LOCK WASHER PROPELLER SHAFT TO REAR AXLES I AND II
234
HEX. NUT. NUT FUEL TANK TO CONSOLE,167609
234
NUT BRACKET TO SIDE MEMBER
240
SCREW , Replaced By: N304017010002
246
NUT BRACKET TO SIDE MEMBER,XB209706
252
BEARING BRACKET
258
SCREW PULL ROD TO BEARING BRACKET
264
NUT PULL ROD TO BEARING BRACKET
270
COTTER PIN STRAP TO SUPPORT
999
RODTO 352 240 02 25
