Поз.
Артикул
Описание
23
CLIP COVER TO PAD
64
SUPPORT
69
WASHER
70
BUFFER REAR SEAT BENCH BACKREST FRAME MOUNTING, 016 UP TO CHASSIS 043198,018 UP TO CHASSIS 044203,019 UP TO CHASSIS 044488
999
LOCK PLATE CONTROL SHAFT TO CAB
999
NUT BALL PIVOT TO LEVER
999
SEAT CUSHION LESS COVER , FROM CHASSIS:108.012 057777 108.014 045121 108.015 002600
999
PAD , FROM CHASSIS:108.012 057777 108.014 045121 108.015 002600
999
PAD , Replaced By: A1099240514
999
PAD
999
PAD
999
COVER , STATE COLOR NUMBER WHEN ORDERING,AND PLEASE STATE WHETHER FRONT SEAT BACKREST SHOULD BE MADE READY FOR INSTALLATION OF HEADRES T FROM CHASSIS:109.016 002411 109.018 002233 109.056 000023
999
COVER , STATE COLOR NUMBER WHEN ORDERING,AND PLEASE STATE WHETHER FRONT SEAT BACKREST SHOULD BE MADE READY FOR INSTALLATION OF HEADRES T FROM CHASSIS: 109.015 002152
999
COVER , STATE COLOR NUMBER WHEN ORDERING,AND PLEASE STATE WHETHER FRONT SEAT BACKREST SHOULD BE MADE READY FOR INSTALLATION OF HEADRES T FROM CHASSIS: 109.015 002152 UP TO CHASSIS: 109.016 002410 109.018 002232 109.056 000022
999
COVER , STATE COLOR NUMBER WHEN ORDERING
999
COVER , FROM CHASSIS:109.016 002411 109.018 002233 109.056 000023
999
BACKREST , STATE COLOR NUMBER WHEN ORDERING,AND PLEASE STATE WHETHER FRONT SEAT BACKREST SHOULD BE MADE READY FOR INSTALLATION OF HEADRES T FROM CHASSIS:109.016 002411 109.018 002233 109.056 000023
999
REAR SEAT CUSHION , Replaced By: A1099201520
999
REAR SEAT CUSHION , STATE COLOR NUMBER WHEN ORDERING,AND PLEASE STATE WHETHER FRONT SEAT BACKREST SHOULD BE MADE READY FOR INSTALLATION OF HEADRES T FROM CHASSIS: 109.015 001670
999
REAR SEAT CUSHION , STATE COLOR NUMBER WHEN ORDERING,AND PLEASE STATE WHETHER FRONT SEAT BACKREST SHOULD BE MADE READY FOR INSTALLATION OF HEADRES T UP TO CHASSIS: 109.016 002410 109.018 002232 109.056 000022
999
REAR SEAT CUSHION , STATE COLOR NUMBER WHEN ORDERING
999
BACKREST , STATE COLOR NUMBER WHEN ORDERING,AND PLEASE STATE WHETHER FRONT SEAT BACKREST SHOULD BE MADE READY FOR INSTALLATION OF HEADRES T FROM CHASSIS: 109.015 001670
999
REAR SEAT CUSHION , Replaced By: A1099201020
999
COVER , STATE COLOR NUMBER WHEN ORDERING,AND PLEASE STATE WHETHER FRONT SEAT BACKREST SHOULD BE MADE READY FOR INSTALLATION OF HEADRES T UP TO CHASSIS: 109.016 002410 109.018 002232 109.056 000022
999
BACKREST FRAME
999
BACKREST , STATE COLOR NUMBER WHEN ORDERING,AND PLEASE STATE WHETHER FRONT SEAT BACKREST SHOULD BE MADE READY FOR INSTALLATION OF HEADRES T UP TO CHASSIS: 109.016 002410 109.018 002232 109.056 000022
999
BACKREST , STATE COLOR NUMBER WHEN ORDERING
999
CUSHION FRAME , FROM CHASSIS:108.012 057777 108.014 045121 108.015 002600
999
REAR SEAT CUSHION , Replaced By: A1099200820
999
BACKREST LESS COVER , Replaced By: A1089200304
999
SEAT CUSHION LESS COVER
999
COVER , STATE COLOR NUMBER WHEN ORDERING
999
BACKREST FRAME , FOR RANGE OF DELIVERY,SEE STANDARD VERSION, Replaced By: A1099200432, +001A1099700931, +002A1159730820, +002N006799009002
999
CUSHION FRAME , Replaced By: A1099200122
999
BACKREST LESS COVER , 018 UP TO CHASSIS 004920 EXCEPT FOR 004913, 004914, 056 UP TO CHASSIS 002604 EXCEPT FOR, SEE FOOTNOTE 20
999
PAD , NOT FOR THE U.S.A.
999
BACKREST FRAME , 012 FROM CHASSIS 008417, 014 FROM CHASSIS 005864, 015 FROM CHASSIS 000722
999
BACKREST FRAME , 012 FROM CHASSIS 008417, 014 FROM CHASSIS 005864, 015 FROM CHASSIS 000722 016 UP TO CHASSIS 037564, 018,019 UP TO CHASSIS 038677, Replaced By: A1089200434, +001A1089703531, +002A1159730820, +002N006799009002
999
BACKREST LESS COVER
999
BRACKET , 018 FROM CHASSIS 092963 ALSO INSTALLED ON,SEE FOOTNOTE 007,067,068 FROM CHASSIS 007821 ALSO INSTALLED ON,SEE FOOTNOTE 008
999
BRACKET REAR SEAT CUSHION TO FLOOR, 010 FROM CHASSIS 162209, 011 FROM CHASSIS 017209, 110 FROM CHASSIS 289680
999
GROMMET REAR SEAT CUSHION TO FLOOR
