Поз.
Артикул
Описание
7
INSULATION ENGINE COMPARTMENT,LEFT, 000,001,004,010,UP TO CHASSIS 130557,100,101,104,110,UP TO CHASSIS 225647
12
INSULATION , Replaced By: A1106822320
17
INSULATION ENGINE COMPARTMENT,RIGHT, 000,001,004,010,UP TO CHASSIS 130557,100,101,104,110,UP TO CHASSIS 225647
23
INSULATION , Replaced By: A0009832291
23
CARDBOARD BELOW INSTRUMENT PANEL, RIGHT, 000,001,004,010,UP TO CHASSIS 130557,100,101,104,110,UP TO CHASSIS 225647 STATE COLOR CODE NR.AND CHASSIS NO.WHEN ORDERING
29
INSULATION LEGROOM,FRONT RIGHT, 000,001,004,010 UP TO CHASSIS 099714,100,101,104,110 UP TO CHASSIS 210863
36
LEDGE LEFT,LUGGAGE COMPARTMENT
41
COVERING REAR SHOCK ABSORBERS
46
COVER FRONT SUBFRAME MOUNTING, 000,001,004,010 UP TO CHASSIS 029559 EXCEPT FOR,SEE FOOTNOTE 19,100,101,104,110 UP TO CHASSIS 040692 EXCEPT FOR,FOOTNOTE 20
52
LOCKING CAP TRANSMISSION OIL LEVEL CHECK, 000,001,004,010 UP TO CHASSIS 074402,100,101,104,110 UP TO CHASSIS 116802
57
GROMMET REAR SEAT CUSHION TO FLOOR
62
RUBBER BUFFER TO PLUG THE FREE CONNECTIONS
62
EXPANSION PLUG TO PLUG THE MOUNTING HOLE USED FOR GROUND CONNECTION IN CASE OF R.H.D.
68
EXPANSION PLUG ELECTRIC CABLE THRU FIRE WALL,4 9400475 187082
73
EXPANSION PLUG
78
COVERING FRONT,FOR JACK TAKE-UP DEVICE
78
COVERING , Replaced By: A1088990108
84
COVERING , Replaced By: A1088990008
84
COVERING REAR,FOR JACK TAKE-UP DEVICE
89
SCREW REAR PANEL,BELOW REAR SEAT
94
EXPANSION PLUG TO PLUG THE FREE HOLES FOR TELL-TALE LAMP
99
PLUG , Replaced By: A0009871840
99
RUBBER BUFFER TO PLUG THE MOUNTING HOLE USED FOR GROUND CONNECTION IN CASE OF R.H.D.
106
EXPANSION PLUG LOADING FLOOR,FRONT D55 MM
111
GROMMET WATER DRAIN IN SPARE WHEEL WELL
116
GROMMET ELECTRIC CABLE THRU FIRE WALL
121
COVER
121
COVER , Replaced By: A1236830010
126
COVER , Replaced By: A1236830010
126
COVER
132
SEAL , Replaced By: A0039895485
132
ADHESIVE TAPE (SEAL),BETWEEN OUTSIDE REAR PILLAR AND ROOF 560 MM, ORDER BY THE METER
137
RUBBER BUFFER HOLES IN REAR LID
143
LINING TUNNEL,FRONT FLOOR, WHEN ORDERING, STATE COL0R AND CHASSIS NO.
149
LINING , Replaced By: A1086840102
149
LINING TUNNEL,LEFT FRONT FLOOR, 000,001,004,010 FROM CHASSIS 130558,100,101,104,110 FROM CHASSIS 225684, STATE COLOR CODE NR.AND CHASSIS NO.WHEN ORDERING
154
LINING , Replaced By: A1086840202
154
LINING TUNNEL,RIGHT FRONT FLOOR, 000,001,004,010 FROM CHASSIS 099715-130557,100,101,104,110 FROM CHASSIS 210864-225647 STATE COLOR CODE NR.AND CHASSIS NO.WHEN ORDERING
161
LINING LUGGAGE COMPARTMENT FLOOR, 000,001,004,010 FROM CHASSIS 130558,100,101,104,110 FROM CHASSIS 225684,
161
LINING , Replaced By: A1086840105
168
LINING FOR TUNNEL,REAR COMPARTMENT FLOOR, 111.010 UP TO CHASSIS 044445 ALSO INSTALLED ON,SEE FOOTNOTE 65 WHEN ORDERING, STATE COL0R AND CHASSIS NO.
173
LINING LEFT AND RIGHT FOR REAR COMPARTMENT FLOOR, WHEN ORDERING, STATE COL0R AND CHASSIS NO.
178
FASTENER BUTTON , Replaced By: A0009888481
178
FASTENER BUTTON
184
RAIL BELOW FRONT DOOR, LEFT, 000,001,004,010 UP TO CHASSIS 160397,100,101,104,110 UP TO CHASSIS 285594,002,003,005,011 UP TO CHASSIS 016336 STATE COLOR CODE NR.AND CHASSIS NO.WHEN ORDERING
184
RAIL , Replaced By: A1106860936
189
RAIL , Replaced By: A1106860936
189
RAIL BELOW FRONT DOOR, LEFT, 000,001,004,010 UP TO CHASSIS 160397,100,101,104,110 UP TO CHASSIS 285594,002,003,005,011 UP TO CHASSIS 016336 STATE COLOR CODE NR.AND CHASSIS NO.WHEN ORDERING
194
LINING , 000,001,004,010 FROM CHASSIS 130558,100,101,104,110 FROM CHASSIS 225684, STATE COLOR CODE NR.AND CHASSIS NO.WHEN ORDERING
194
LINING , Replaced By: A1086860980
198
LINING , Replaced By: A1106862380
198
LINING , 000,001,004,010 FROM CHASSIS 130558,100,101,104,110 FROM CHASSIS 225684, STATE COLOR CODE NR.AND CHASSIS NO.WHEN ORDERING
203
LINING REAR ENTRANCE,INSIDE LEFT, 000,001,004,010 FROM CHASSIS 130558,100,101,104,110 FROM CHASSIS 225684, STATE COLOR CODE NR.AND CHASSIS NO.WHEN ORDERING
203
LINING , Replaced By: A1106862580
208
PANELLING FRONT PANEL, LATERAL LEFT
213
COVERING BELOW INSTRUMENT PANEL,LEFT, 000,001,004,010,UP TO CHASSIS 130557,100,101,104,110,UP TO CHASSIS 225647 STATE COLOR CODE NR.AND CHASSIS NO.WHEN ORDERING
217
COVERING BELOW INSTRUMENT PANEL, RIGHT, 000,001,004,010,UP TO CHASSIS 130557,100,101,104,110,UP TO CHASSIS 225647 STATE COLOR CODE NR.AND CHASSIS NO.WHEN ORDERING
222
CLIP , FROM CHASSIS: 010 000100 110 000057
999
COUNTERSUNK WASHER INSULATION TO FIRE WALL,INSIDE, 000,001,004,010 UP TO CHASSIS 099714,100,101,104,110 UP TO CHASSIS 210863
999
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
999
WASHER , Replaced By: N009021005205
999
WASHER COVERING TO CYCLONE AIR TRAP
999
WASHER , Replaced By: N009021004207
999
WOOD SCREW RUBBER BUFFER TO LID, 010 FROM CHASSIS 001292,012 FROM CHASSIS 002631 010 UP TO CHASSIS 017603 EXCEPT FOR,SEE FOOTNOTE 58,012 UP TO CHASSIS 036825 EXCEPT FOR,SEE FOOTNOTE 59
999
WOOD SCREW
999
SCREW CHROMIUM PLATED, 000,001,004,010,UP TO CHASSIS 130557,100,101,104,110,UP TO CHASSIS 225647
999
SCREW , Replaced By: N000000001933
999
SCREW GLOVE COMPARTMENT LID TO INSTRUMENT PANEL, 010 UP TO CHASSIS 017603 EXCEPT FOR,SEE FOOTNOTE 58,012 UP TO CHASSIS 036825 EXCEPT FOR,SEE FOOTNOTE 59
999
SHEET METAL SCREW , 000,001,004,010,UP TO CHASSIS 130557,100,101,104,110,UP TO CHASSIS 225647
999
SHEET METAL SCREW
999
SHEET METAL SCREW ELECTRIC CABLE TO CABLE DUCT
999
SHEET METAL SCREW
999
SHEET METAL SCREW (LAMP TO INTERIOR PLATE), UP TO CHASSIS: 113.042 012466, EXCEPT FOR: 012343-012352,012354-012366,012369-012376,012378-012387,012389-012412,012414-012422,012424-012444. UP TO CHASSIS: 111.021,023 082990 112.021,023 008909 UP TO CHASSIS: 110.010 130557 110.110 225647 111.010,012,014 069692
999
SHEET METAL SCREW
999
SHEET METAL SCREW ELECTRIC CABLE TO FIRE WALL
999
SHEET METAL SCREW
999
SHEET METAL SCREW WINDOW SILL GIRDER LOWER PART,4 273689
999
SHEET METAL SCREW ANTENNA CABLE TO REAR INSIDE PILLAR
999
SHEET METAL SCREW REFRIGERANT LINE TO CAB
999
SHEET METAL SCREW GEAR INDICATOR TO INSTRUMENT PANEL
999
TAPPING SCREW. SHEET METAL SCREW FUEL LINE
999
SHEET METAL SCREW BRACKET TO ELECTRICAL APPARATUS COMPARTMENT 4,8X19
999
SHEET METAL SCREW , Replaced By: N000000002062
999
SHEET METAL SCREW RELAY TO APPARATUS SUPPORT,K 182153K 239549
999
SHEET METAL SCREW SLIDING PLATE TO BODY
999
NUT TACHOGRAPH TO BRACKET
999
SPRING WASHER ALTERNATOR CONNECTION D+
999
LOCK WASHER 3/2-WAY SOLENOID VALVE TO BRACKET
999
LOCK WASHER
999
WASHER , FROM CHASSIS: 005,007,008,015,017 10/50,12/52 009573, ALSO INSTALLED ON: 009319,009323,009404,009444,009449,009450,009454-009456,009458,009459,009461-009472,009475-009477, 009479-009494,009496-009571. 010 10/50,12/52 013397, ALSO INSTALLED ON: 013289,013348,013354,013356,013358,013361-013367,013370-013381,013384-013388,013390-013395. 005,007,008,015,017 20/60,22/62 012727 010 20/60,22/62 015672
999
WASHER , 000855
999
SCREW
999
SCREW FUSE BOX TO SIDE MEMBER,5 097182
999
TAPPING SCREW SIDE REFLECTORS,K 057592
999
WASHER
999
LOCK FUEL LINE
999
WASHER , Replaced By: A1268850010
999
CUP , Replaced By: A1109870045
999
SCREW , 000,001,004,010 UP TO CHASSIS 098214 ALSO INSTALLED ON,SEE FOOTNOTE 25,100,101,104,110 UP TO CHASSIS 160504 EXEPT FOR,SEE FOOT NOTE 26,ALSO INSTALLED ON,SEE FOOTNOTE 27
999
WASHER , 10/50,12/52,000,001,004,010 UP TO CHASSIS 099714,10/50,12/52,100,101,104,110 UP TO CHASSIS 210863,AND FOOTNOTE 4
999
NUT , Replaced By: A0009900750
999
INSULATION ENGINE COMPARTMENT,LEFT OUTSIDE, 000,001,004,010,UP TO CHASSIS 130557,100,101,104,110,UP TO CHASSIS 225647
999
WASHER , Replaced By: A3019900042
999
COVER , 010 FROM CHASSIS 017604 ALSO INSTALLED ON,SEE FOOTNOTE 58,012 FROM CHASSIS 036826 ALSO INSTALLED ON,SEE FOOTNOTE 59
999
INSULATION , Replaced By: A0009832291
999
INSULATION , Replaced By: A0009832291
999
GROMMET , Replaced By: A0089971781
999
GROMMET TUNNEL,FRONT FLOOR, 000,001,004,010 FROM CHASSIS 130558,100,101,104,110 FROM CHASSIS 225684, ON SPECIAL REQUEST,FLOOR SHIFT STATE COLOR CODE NR.AND CHASSIS NO.WHEN ORDERING
999
LOCK TYPE DESIGNATION
999
WASHER
999
PLUG , Replaced By: A0009901222
999
PLUG , Replaced By: A1108990308
999
COVER , Replaced By: A1126890283
999
COVER , Replaced By: A1126890183
999
COVER , 010 UP TO CHASSIS 017603 EXCEPT FOR,SEE FOOTNOTE 58,012 UP TO CHASSIS 036825 EXCEPT FOR,SEE FOOTNOTE 59 010 FROM CHASSIS 013119,012 FROM CHASSIS 026643
999
COVER , 010 UP TO CHASSIS 017603 EXCEPT FOR,SEE FOOTNOTE 58,012 UP TO CHASSIS 036825 EXCEPT FOR,SEE FOOTNOTE 59 010 FROM CHASSIS 013119,012 FROM CHASSIS 026643
999
COVER , TO BE ADAPTED DURING ASSEMBLY 010 UP TO CHASSIS 000219,012 UP TO CHASSIS 000349, Replaced By: A1116890483
999
COVER , TO BE ADAPTED DURING ASSEMBLY 010 UP TO CHASSIS 000219,012 UP TO CHASSIS 000349, Replaced By: A1116890383
999
COVER INSTRUMENT PANEL, 010 UP TO CHASSIS 064589,012 UP TO CHASSIS 146540 010 FROM CHASSIS 013119,012 FROM CHASSIS 026643
999
SEAL
999
COVERING FRONT, ON SPECIAL REQUEST,FLOOR SHIFT 000,001,004,010 FROM CHASSIS 137795,100,101,104,110 FROM CHASSIS 238417,002,003,005,011 FROM CHASSIS 003349
999
SEAL , ON SPECIAL REQUEST,FLOOR SHIFT 000,001,004,010 FROM CHASSIS 137795,100,101,104,110 FROM CHASSIS 238417,002,003,005,011 FROM CHASSIS 003349
999
COVERING REAR, UP TO CHASSIS: 111.010 069657
999
PANELLING , Replaced By: A1116800287
999
PANELLING , Replaced By: A1116800187
999
PANELLING , Replaced By: A1116800187
999
PANELLING , Replaced By: A1116800287
999
PANELLING AT INSTRUMENT PANEL,BELOW GLOVE COMPARTMENT LID
999
PANELLING , Replaced By: A1116803483
999
PANELLING , Replaced By: A1116803383
999
PANELLING , Replaced By: A1116800287
999
PANELLING , Replaced By: A1116800187
999
PANELLING , USE UP THE OLD PARTS STILL CARRIED IN STOCK 000,001,004,010,UP TO CHASSIS 189334,100,101,104,110,UP TO CHASSIS 352416,002,003,005,011,017 UP TO CHASSIS 032036, Replaced By: A1116801406
999
LINING , UP TO CHASSIS: 111.010 069657 STATE COLOR NUMBER WHEN ORDERING
999
PANELLING , USE UP THE OLD PARTS STILL CARRIED IN STOCK 000,001,004,010,UP TO CHASSIS 189334,100,101,104,110,UP TO CHASSIS 352416,002,003,005,011,017 UP TO CHASSIS 032036, Replaced By: A1116801306
999
PANELLING RIGHT INSIDE INSTRUMENT PANEL, NOT USED
999
LINING , UP TO CHASSIS: 111.010 069657 STATE COLOR NUMBER WHEN ORDERING
999
PANELLING LEFT INSIDE INSTRUMENT PANEL, NOT USED
999
LINING TUNNEL,FRONT FLOOR, WHEN ORDERING, STATE COL0R AND CHASSIS NO.
999
PANELLING RIGHT OUTSIDE INSTRUMENT PANEL, NOT USED
999
PANELLING LEFT OUTSIDE INSTRUMENT PANEL, NOT USED
999
PANELLING , Replaced By: A1116801206
999
PANELLING RIGHT INSIDE INSTRUMENT PANEL, NOT USED
999
HINGE , Replaced By: A1116800251
999
PANELLING , Replaced By: A1116801206
999
PANELLING LEFT INSIDE INSTRUMENT PANEL, NOT USED
999
HINGE LEFT FOR GLOVE COMPARTMENT LID, 010 UP TO CHASSIS 017603 EXCEPT FOR,SEE FOOTNOTE 58,012 UP TO CHASSIS 036825 EXCEPT FOR,SEE FOOTNOTE 59
999
PANELLING , Replaced By: A1116801206
999
INSTRUMENT PANEL TWO-PART, 010 FROM CHASSIS 013119,012 FROM CHASSIS 026643
999
PANELLING RIGHT OUTSIDE INSTRUMENT PANEL, NOT USED
999
HINGE RIGHT FOR GLOVE COMPARTMENT LID, 010 UP TO CHASSIS 017603 EXCEPT FOR,SEE FOOTNOTE 58,012 UP TO CHASSIS 036825 EXCEPT FOR,SEE FOOTNOTE 59
999
LINING , Replaced By: A1116800141
999
PANELLING , Replaced By: A1116801106
999
PANELLING LEFT OUTSIDE INSTRUMENT PANEL, NOT USED
999
HINGE , Replaced By: A1116800351
999
LINING , Replaced By: A1116800345
999
PANELLING , Replaced By: A1116801106
999
LINING FOR TUNNEL,REAR COMPARTMENT FLOOR, 111.012 UP TO CHASSIS 044444 EXCEPT FOR,SEE FOOTNOTE 65 WHEN ORDERING, STATE COL0R AND CHASSIS NO.
999
PANELLING , Replaced By: A1116801106
999
SEAL RING , Replaced By: A1106830198
999
SPRING , Replaced By: A1109930901
999
EXPANSION PLUG IN FRONT PANEL PILLAR,OUTSIDE, FOR SLIDING ROOF HOSE
999
EXPANSION PLUG PAINT RUN-OFF IN FLOOR,LATERAL
999
EXPANSION PLUG , Replaced By: A1139870044
999
EXPANSION PLUG , Replaced By: A1139870044
999
RUBBER BUFFER
999
EXPANSION PLUG FOR HOLE IN FRONT PANEL PILLAR,ON CARS HAVING NO SLIDING ROOF, 111.010 UP TO CHASSIS 011682,111.012 UP TO CHASSIS 023491
999
RUBBER BUFFER RIGHT,BELOW FRONT SEAT TO PLUG WATER DRAIN HOLES IN FLOOR, NOT USED
999
EXPANSION PLUG , Replaced By: A1139870044
999
GARNISH MOULDING BOTTOM
999
GARNISH MOULDING BOTTOM FOR INSTRUMENT PANEL
999
GARNISH MOULDING TOP LEFT
999
GLOVE COMPARTMENT
999
GARNISH MOULDING TOP RIGHT
999
GARNISH MOULDING TOP CENTRAL
999
HANDLE
999
ESCUTCHEON , 010 UP TO CHASSIS 024214,012 UP TO CHASSIS 051199, Replaced By: A1106890180, +001A1106890098
999
GARNISH MOULDING , Replaced By: A1106800371
999
PANELLING FRONT PANEL,LATERAL RIGHT
999
PANELLING , Replaced By: A1106880406
999
PANELLING , Replaced By: A1106880306
999
CLIP
999
CAP
999
LINING REAR ENTRANCE,INSIDE RIGHT, 000,001,004,010,UP TO CHASSIS 130557,100,101,104,110,UP TO CHASSIS 225647 STATE COLOR CODE NR.AND CHASSIS NO.WHEN ORDERING
999
LINING , 000,001,004,010 FROM CHASSIS 130558,100,101,104,110 FROM CHASSIS 225684, STATE COLOR CODE NR.AND CHASSIS NO.WHEN ORDERING
999
LINING , Replaced By: A1086861080
999
LINING , Replaced By: A1106862680
999
LINING , Replaced By: A1106862480
999
LINING , Replaced By: A1106861880
999
LINING , Replaced By: A1106861780
999
LINING , 111.012 UP TO CHASSIS 044444 EXCEPT FOR,SEE FOOTNOTE 65, Replaced By: A1106861880
999
RAIL BELOW FRONT DOOR, RIGHT, 000,001,004,010 UP TO CHASSIS 160397,100,101,104,110 UP TO CHASSIS 285594,002,003,005,011 UP TO CHASSIS 016336 STATE COLOR CODE NR.AND CHASSIS NO.WHEN ORDERING
999
LINING , 111.012 UP TO CHASSIS 044444 EXCEPT FOR,SEE FOOTNOTE 65, Replaced By: A1106861780
999
LINING , TO BE ADAPTED DURING ASSEMBLY 110.010 UP TO CHASSIS 021371 EXCEPT FOR 021350,021362,021363,021364, Replaced By: A1106861880
999
RAIL , Replaced By: A1106861036
999
LINING , TO BE ADAPTED DURING ASSEMBLY 110.010 UP TO CHASSIS 021371 EXCEPT FOR 021350,021362,021363,021364, Replaced By: A1106861780
999
LINING , Replaced By: A1106861680
999
RAIL , Replaced By: A1106861036
999
LINING , Replaced By: A1106861580
999
LINING , Replaced By: A1106861480
