Поз.
Артикул
Описание
5
SHAFT (DRIVE SHAFT)
8
FLANGE FRONT AXLE II 150 MM
8
FLANGE REAR AXLE 180 MM
8
FLANGE , Replaced By: A3553532345, +001A3553530391
8
FLANGE
11
PROTECTIVE PLATE
14
NUT PROPELLER SHAFT TO FOLLOWER FLANGE,5 091917
17
SCREW COLLAR THROUGH DRIVE SHAFT SETTING
20
SEAL RING
23
SEAL RING TRANSMISSION CASE REAR COVER,INSIDE 10MM
26
LOCK DIFFERENTIAL GEAR ADJUSTMENT
29
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
32
GROOVED BALL BEARING DRIVE SHAFT BEARING
35
FOLLOWER ,V 440534, Replaced By: A3553531236, +001A3553500824
35
FOLLOWER ,V 440534, Replaced By: A3553531236, +001A3553500824
35
FOLLOWER WHEEL HUB DRIVE GEAR,V 440535
38
THRUST WASHER THROUGH-SHAFT, AS REQUIRED 4.00 MM
38
THRUST WASHER DRIVE SHAFT,AS REQUIRED 3.65 MM, NOT USED
38
THRUST WASHER DRIVE SHAFT,AS REQUIRED 3.85 MM, NOT USED
38
THRUST WASHER DRIVE SHAFT,AS REQUIRED 4.20 MM
41
WHEEL HUB DRIVE WHEEL HUB DRIVE
41
WHEEL HUB DRIVE ,V 440534, Replaced By: A3553500824, +001A3553531236
41
SIDE GEAR ,V440534, Replaced By: A3553500824, +001A3553531236
41
SIDE GEAR ,V440534, Replaced By: A3553500824, +001A3553531236
44
BUSHING WHEEL HUB DRIVE
44
BUSHING WHEEL HUB DRIVE
47
DIFFERENTIAL CASE , MAN AXLE
50
SCREW DIFFERENTIAL CASE
53
DIFFERENTIAL SPIDER DIFFERENTIAL CASE
56
NUT DIFFERENTIAL SPIDER,V 151343
59
DIFFERENTIAL PINION THROUGH-DRIVE DIFFERENTIAL GEAR
62
BUSHING THROUGH-DRIVE DIFFERENTIAL GEAR,V 151343
65
WASHER , MAN AXLE
68
SPACER RING DIFFERENTIAL PINION
68
SPACER RING THROUGH-DRIVE DIFFERENTIAL GEAR,V 151343
71
SIDE GEAR P.T.O.
74
BUSHING SIDE GEAR
74
BUSHING SIDE GEAR
77
THRUST WASHER THROUGH DRIVE,AS REQUIRED 2.45 MM, NOT USED
77
THRUST WASHER THROUGH DRIVE,AS REQUIRED 2.35 MM, NOT USED
77
THRUST WASHER THROUGH DRIVE,AS REQUIRED 2.60 MM
77
THRUST WASHER THROUGH DRIVE,AS REQUIRED 2.80 MM
80
BALL BEARING OUTPUT GEAR
83
SHAFT REAR AXLE I
83
SHAFT P.T.O.
86
SCREW COLLAR OUTPUT SHAFT
89
SEAL RING ON FLANGE END
92
SEAL RING ON BEARING END, MAN AXLE
95
LOCK DIFFERENTIAL GEAR ADJUSTMENT
98
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
101
BALL BEARING MULTI-DISC COUPLING
104
LOCK PLATE THROUGH DRIVE SHAFT SETTING
107
NUT BALL BEARING TO OUTPUT SHAFT
108
REPAIR KIT INTER-AXLE DIFFERENTIAL IN INDIVIDUAL COMPONENTS
109
DIFFERENTIAL GEAR. REPAIR KIT INTER-AXLE DIFFERENTIAL,ASSEMBLED
999
LOCK RING LINE CONNECTION
999
LOCK SPRING LOAD ACCUMULATOR CYLINDER TO M10 / VOSS 230,D 259885
999
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 10
