Поз.
Артикул
Описание
89
COUPLING (DOG COUPLING)
92
WIRE RING CLUTCH TO DIFFERENTIAL GEAR
95
FOLLOWER DIFFERENTIAL LOCK CONTROL
98
SPRING SHIFTING FORK TO SHIFTING SHAFT
101
SHIFTING FORK DIFFERENTIAL LOCK CONTROL
104
SHAFT TRANSVERSE DIFFERENTIAL LOCK CONTROL
107
HEADLESS SETSCREW TRANSVERSE DIFFERENTIAL LOCK
110
NUT
113
CYLINDER (OPERATING CYLINDER),TRANSVERSE DIFFERENTIAL LOCK
116
PISTON TRANSVERSE DIFFERENTIAL LOCK
116
PISTON TRANSVERSE DIFFERENTIAL LOCK
119
SEAL RING SHIFTING CYLINDER
122
GASKET SHIFTING CYLINDER TO INTERMEDIATE FLANGE
125
SCREW BRACKET TO BEARING BRACKET
128
SEAL RING. REPAIR KIT COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 10
128
REPAIR KIT , Replaced By: A0309971648
131
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M 10, VOSS 232, Replaced By: A0009975034
131
UNION SCREW SPRING LOAD ACCUMULATOR CYLINDER M10X1 / VOSS 230,D 259885
131
UNION SCREW PNEUMATIC CONNECTION,SUPPLY UNIT M 10, VOSS 232, SDF
131
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 10, VOSS 230
132
REPAIR KIT O-RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 10, SDF
134
SWITCH
134
SWITCH , Replaced By: A0015455709
137
SEAL RING ON OIL PUMP HOUSING
140
COVER
143
GASKET SHIFTING CYLINDER TO INTERMEDIATE FLANGE
146
SCREW BRACKET TO CAB REAR PANEL M 8X20
