Поз.
Артикул
Описание
60
NUT HORN TO BRACKET M8
170
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
170
HEXALOBULAR BOLT BRACKET TO BRACKET M 10X30
180
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
205
CLAMP TAIL PIPE TO EXHAUST MUFFLER
210
SCREW BRACKET TO SIDE MEMBER M10X35
210
HEXAGON HEAD BOLT BRACKET TO BRACKET M10X35
220
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
270
HEXAGON HEAD BOLT BRACKET TO DISTRIBUTOR
275
HEXAGON HEAD BOLT. SCREW MOUNTING PARTS M12 X 1.5 X 40
290
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
320
PROTECTIVE PLATE AT MUFFLER
330
NUT RETAINER PROTECTIVE PLATE TO EXHAUST MUFFLER
330
NUTM8
330
SOCKET NUT. NUT RETAINER EXHAUST MUFFLER TO SUPPORT
335
SCREW SPEED SENSOR TO REAR AXLE
335
SCREW PIPE ELBOW TO BRACKET M8X12
370
HEXAGON HEAD BOLT. SCREW GUSSET PLATE TO FRAME M14 X 1.5 X 70
370
HEXAGON HEAD BOLT BRACKET TO SPRING SADDLE M14X1.5X110
370
HEXAGON HEAD BOLT SUPPORT TO FRAME M14X1.5X45
380
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
420
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
420
NUT SUPPORT TO FRAME
600
HEXAGON HEAD BOLT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER M14X1.5X40
610
NUT SUPPORT TO FRAME
610
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
