Поз.
Артикул
Описание
3
PLASTIC PIPE RISING PIPE 4X6 MM
3
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
5
BUSHING , Replaced By: N915062004000
5
SLEEVE LEAK LINE
7
UNION NUT
9
SEAL CONE
9
GLAND , Replaced By: A0019901667
12
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
15
UNION NUT LINE CONNECTION
15
UNION NUT , Replaced By: N915017008100
18
GLAND LINE CONNECTION
20
VALVE EXHAUST BRAKE OPERATING MECHANISM BOSCH
20
VALVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 422115, Replaced By: A0004342101
25
CUPTO 000 434 10 01
30
REPAIR KITTO 000 434 10 01, FOR VALVE HAVING THE BOSCH CHARACTERISTIC NUMBER 428
33
TS DOUBLE FITTING SOLENOID VALVE
33
FITTING , Replaced By: A0039979072
33
FITTING , Replaced By: A0029906071
36
SEAL RING LINE CONNECTION
39
NUT SUCTION LINE TO OIL PUMP
41
SPRING WASHER AT CAB FLOOR
45
SWITCH EXHAUST BRAKE,K 251255
47
T-FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
49
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
51
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
53
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
999
SLEEVE LINE CONNECTION
999
STRAINERTO 000 434 21 01
999
VALVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 422115, Replaced By: A0004342301
999
CUP 3/2-WAY VALVE WABCO
999
BUSHINGTO 000 434 10 01
999
VALVE , Replaced By: A0004342301
999
VALVE EXHAUST BRAKE OPERATING MECHANISM WESTINGHOUSE
999
REPAIR KIT ADDITIONAL CLUSTER GEAR VALVE TO 000 434 06 01
999
SLEEVE , Replaced By: N915062006000
999
BANJO UNION , Replaced By: N915052006013
999
FITTING , Replaced By: A0019972572
999
HANDLETO 000 434 23 01
999
SPRINGTO 000 434 21 01
999
REPAIR KITTO 000 434 10 01, FOR VALVE HAVING THE BOSCH CHARACTERISTIC NUMBER 427
999
T-FITTING EXHAUST BRAKE 3/2-WAY VALVE
999
FITTING LINE CONNECTION, Replaced By: N000000006446
999
REPAIR KIT 3/2-WAY VALVE BOSCH
999
REPAIR KIT 3/2-WAY VALVE WABCO
999
SEAL RINGTO 000 434 21 01
999
SEAL RINGTO 000 434 23 01
999
SEAL RINGTO 000 434 23 01
999
PIPE SOCKET COMPRESSED AIR PIPING TO 3/2-WAY VALVE
999
BREATHER , Replaced By: A3933280065
999
SCREW-IN FITTING LINE CONNECTION
999
SEAL RING EXHAUST BRAKE CYLINDER,4 416299
999
SEAL CONE 3/2-WAY VALVE,CONNECTION "2",4 470248
999
HOLLOW SCREW FITTING PNEUMATIC CYLINDER,CONNECTION: "10",5 308944
999
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
