Поз.
Артикул
Описание
5
STEERING LOCK , F 120368
5
STEERING LOCK
11
IGNITION SWITCH , Replaced By: A1244620093
11
IGNITION SWITCH , Replaced By: A2025450104
11
IGNITION SWITCH , Replaced By: A1244620393
11
IGNITION SWITCH STARTING SWITCH
20
SCREW IGNITION SWITCH TO STEERING LOCK
20
SCREW SWITCH BOX TO STEERING LOCK
26
TUMBLER LESS KEY, STATE LOCK NUMBER WHEN ORDERING
26
TUMBLER , Replaced By: A1264600204
29
STEERING LOCK WITHOUT SPECIFIC LOCK,MAIN KEY, SEE GR OUP 72
29
TUMBLER , Replaced By: A1264600304
29
TUMBLER , Replaced By: A1264600604
32
COVER
32
COVER , F 120368
35
CLAMPING PIECE
38
SCREW
53
STEERING WHEEL , Replaced By: A1294600103
53
STEERING WHEEL , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. F031416, Replaced By: A2014602703
53
STEERING WHEEL , Replaced By: A1294600003
59
CONTACT RING , NOT FOR AIRBAG
59
CONTACT RING
65
SCREW
68
SCREW
74
SPRING
74
SPRING
77
BUSHING ,F 189738
92
WASHER , Replaced By: A1244640023
92
INSULATING PLATE
95
PAD , NOT FOR AIRBAGF 189737
98
BADGE STEERING WHEEL,K 072836 IINO.7B90 III
104
SCREW W HEXAGON SOCKET. SCREW STEERING WHEEL TO STEERING COLUMN
107
SENDER UNIT , Replaced By: A0095429817
107
SENDER UNIT (LOCK ANGLE SENSOR)
116
SWITCH,AUTOMATIC , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. F 032416, Replaced By: A1245401045
116
SWITCH BLINKER SWITCH
119
PLUG HOUSING 14-POLE
119
PLUG HOUSING , Replaced By: A0095455628, +001A0095455728
120
COVERTO 009 545 56 28
122
PLUG PIN ADDITIONAL CABLE TO SERIES CABLE
125
CONTACT PIECE
125
CONTACT PIECE , Replaced By: A1264641043
131
SWITCH,AUTOMATIC , Replaced By: A1245450924
131
SWITCH,AUTOMATIC , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. F 184895, Replaced By: A1245401244
131
SWITCH , Replaced By: A1245400544
131
SWITCH (TEMPOMAT SWITCH),IN ENGLISH
134
PLUG HOUSING
137
COVER
140
PLUG PIN ADDITIONAL CABLE TO SERIES CABLE
143
SCREW ADDITIONAL WORK ON FRAME MOUNTED CABLE HARNESS
146
SCREW FUSE TO BATTERY MASTER SWITCH AM 4X30
149
LOCK WASHER T-FITTING TO BRACKET
152
BRACKET
155
BRACKET ELECTRIC CABLE TO STEERING COLUMN BRACKET
155
BRACKET , Replaced By: A0005465843
155
BRACKET ELECTRIC CABLE TO STEERING COLUMN BRACKET
158
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
158
NUT , Replaced By: N910112006001
158
NUT , Replaced By: N913023006001
161
BOOT TEMPOMAT SWITCH
164
COVER ONLY USED W/TEMPOMAT (CRUISE CONTROL)
164
COVER USED WITHOUT TEMPOMAT (CRUISE CONTROL)
164
COVER , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. F012900, Replaced By: A1244623223
164
COVER , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. F012900, Replaced By: A1244623023
